88 6100-02
Stackable Storage
x
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top
1 pc.
E.
Base
1 pc.
F.
Leg
4 pcs.
Hardware List
Screwdriver
1 pc.
Open Unit
B.
Side Panel
1 pc.
G.
Front Frame
1 pc.
Cam Lock Screw
16 pcs.(+1 extra)
Cam Lock
16 pcs.(+1 extra)
Casual Attire For Today's Home
C.
Side Panel
1 pc.
H.
Shelf
1 pc.
Wood Screw
for leg
16 pcs. (+1 extra)
Adjustable Pin
4 pcs.(+1 extra)
D.
Back Panel
1 pc.
Plastic Cap
16 pcs. (+1 extra)
