885333762 C
Computer Armoire
with writing board and pin board.(Top Unit)
3
3
23 / " X 34 / " X 56 / "
8
4
Thai Patent Pending Numbers 067952
Top Unit Part List
A.
Top
1 pc.
D.
Fixed Shelf
1 pc.
E.
F.
Divider
Divider
1 pc.
1 pc.
I.
Back Stretcher
1 pc.
K.
Pencil Box
1 pc.
Tools Required For Assembly : Philips screwdriver
3
8
Casual Attire For Today's Home
B.
Side Panel
1 pc.
G.
Back Panel CD
1 pc.
J.
Marker Storage
1 pc.
Assembly
Instructions
Carefully remove all the parts from
the carton and put them individually on
a soft cloth to prevent scratches or other
damages occuring to the wood parts.
We recommend that you
completely assemble the base unit before
We strongly recommend that
at least two people be used to lift or
Small scratches can be easily
repaired by using a black or dark brown marker.
We have taken great care
in the design of this product and request
that you carefully and strictly follow our
assembly instructions to ensure a completed
armoire as it was designed.
Hardware
Hex Wrench
1 pc.
Pull Handle
C.
2 pcs.
Side Panel
1 pc.
Machine Screw
for Pull Handle
2 pcs.
Magnet
H.
Back Panel
2 pcs.
1 pc.
L.
Wood Screw
Paper Box
for Magnet
1 pc.
4 pcs.(+1 extra)
IMPORTANT NOTE
assembling the top unit.
move the unit.
Cam Lock Screw
12 pcs.
(+1 extra)
Cam Lock
16 pcs.
(+1 extra)
Head Cap Bolt
M6 x 35
4 pcs.
(+1 extra)
Wood Screw (long)
for Pencil Box & Tray
6 pcs.(+1 extra)
Wood Screw
for Back Panel
6 pcs.(+1 extra)
Wood Plug
4 pcs.(+2 extra)
