Solid State Logic Duality Operator's Manual page 83

Duality Nuendo Control Button Layout
EFFECTS
CHANNEL
NAME
VALUE
RDY
The majority of Nuendo or Cubase functions are controlled via dedicated buttons, with virtually no reliance on
the 8x8 menu buttons located beneath the TFT screen. Full details are available in the Mackie Control manual,
which is available from the Nuendo download site:
When compared to the HUI protocol front panel, the major differences here are the new control set for assigning
processing parameters to the D-pots. Up and down page buttons for D-pot parameters are located within the
Shift button block. The rotary encoder will also output page up/down commands when turned left or right.
RDY and SEL control the function of the channel SEL buttons as with the HUI interface. The EDIT button is
used to open editing windows in Nuendo or Cubase for the current selection. Pressing EDIT together with SHIFT
will close an active window.
CHANNEL is unchanged and assigns Duality's channel gain element or DAW channel to the D-pot according to
the state of the Console Focus button. The encoder switch is used to 'flip' parameters onto the faders as before
but includes all processing parameters, not just send levels.
The Transport Control buttons are assigned to related transport functions as with the HUI interface:
Note that tallies for the CYCLE and PUNCH functions are displayed in the status area of the TFT display.
All manuals and user guides at all-guides.com
AUX2
INST MASTER
PLUG-IN
PAN
EQ
Push to Flip
SMPTE
EDIT SEL
BEATS
CHANNEL
http://www.steinberg.de/439_0.html
PREV ADD
LEFT RIGHT
ESC
ENTER
UNDO SAVE
SEND SHIFT
READ WRITE
NEXT
CYCLE PUNCH
Duality Operator's Manual
Duality Nuendo Control
SOLO
MOTORS
PROJ
MIX
3 - 3 3
