Solid State Logic Duality Operator's Manual page 101

C C r r e e a a t t i i n n g g A A N N e e w w M M i i x x P P a a s s s s
To create a new automated Mix Pass, press List Mix to access the screen shown below, use the lefthand
encoder to highlight the New Mix entry.
Project 16 :: Title 1
NEW MIX
Select
Proj Auto Lnks
TR
Trim Moff TLock Snap
The DAW should be positioned a few frames earlier than the required starting point, to allow the mix system to
lock to the incoming timecode.
The current automation status for each channel is displayed in the scribble strip above the fader, replacing the
standard 'Fader ##' label. Faders can be toggled between Absolute and Manual using the fader status button
located next to the fader, or globally using the FSM (Fader Status Master) soft key (see below).
Project 16 :: Title 1
***NEW MIX***
you may adjust status now.
Press Execute to continue
Execute FSM
Misc Lnks
TR Auto
Trim TLock Snap
Moff
Pressing the CANCEL button (in the 'AUTOMATION' group above the 'TRANSPORT' buttons) will return you to
the List Mix page. See Dedicated Automation Buttons for more information.
All manuals and user guides at all-guides.com
Mix Enabled
Delete
Misc SSL
CS
AT
Mix Enabled
Cancel
Misc SSL
AT CS
Creating a New Mix pass
Now press the encoder switch to select the New
Mix Setup page (see below). All the channel faders
will enter Absolute mode, as indicated by a red
LED next to each fader.
New Mix Pass modes for faders
Absolute mode: Red LED. All automated moves
are written at the current fader position.
Manual mode: No LEDs. The fader operates as a
monitor fader only, ie. no information will be written
to memory.
