Console Operator's Guide
The next four items in the Setup menu are concerned with DAW interconnection, but are included here for
completeness; see Section 3 for more details. Note that changes to any of these DAW settings will require a
console reboot before they take effect.
First Physical DAW Channel – Select the console channel number that is controlling the first DAW track
number.
DAW Channel Count – Select the total number of channels dedicated to DAW control (8-48 in steps of 8).
DAW Centre Section – Select the MIDI port that connects the console's centre section master controls to the
DAW; normally MIDI 1.
DAW Interface – Select from HUI, Logic Audio, Nuendo, Digital Performer, Sonar.
Console Channel Count – Should be set to the size of your console 48, 72 or 96. This setting determines the
range of channels selected by the Central Routing Panel's ALL button.
Turn Off Display After – Shuts off the TFT display after a predetermined time: 30 mins to 5 hours in 30 minute
increments.
DAW Control
Most of the left hand side of the centre section is taken up with a TFT screen and control panel dedicated to
use with your workstation. See Section 3 of this manual for full details.
