Insert
7
.6
KHz
EQ
The INS IN button routes the channel signal via balanced insert send and return points,
IN
Q
available on the rear of the console (D-connectors). The insert defaults to the channel
INS
IN
LMF
0
input (post the input trim); POST cycles the insert position through two alternative
POST
locations in the processing path: post EQ or post Dynamics; the centre section master
+
-
. 1.
dB
6 0
routing panel provides individual INS POST EQ and INS POST DYN buttons. When the
.3
.2 2.0 insert is active, the INSERT box on the channel TFT is highlighted.
KHz
220
15
Q
0
400
60
LF
0
40 600
Hz
BELL
- +
dB
CH OP
SRC
AFL
SEL
Channel Output (CHOP)
CUE ST
POST
The Channel Output (D-connector) is normally used to feed the DAW input. The default
CH OP
ALT
signal is a post channel fader feed, but the SRC SEL button can be used to select
L R
Cue B
alternative sources: pre channel fader (pre the SPLIT point – see below), the channel
EFX
ON
input (also pre the SPLIT point), or an active EFX send (see below). Each selection is
FX1
CH OP
graphically displayed on the channel TFT screen (see Channel Metering for more
EFX
ON
information). When either the channel input or pre fader source is selected, the SPLIT
FX2
CH OP
button activates the Split Monitoring function and routes the DAW return into the channel
EFX
signal path post the split point (see below).
ON
FX3
CH OP
EFX
Use the associated AFL button to monitor the channel output source as you toggle
ON
FX4
CH OP
through the options with the SRC SEL button. The central routing panel has single button
EFX
selection of the four channel output sources: INPUT, PRE FADE, POST FADE, EFX.
ON
SRC
SET EFX
/CUEB SEL
Signal Processor Routing
By now you will have realised that Duality features extremely flexible signal processor routing within each
channel. In addition, the channel output (CHOP) can be sourced from a number of different points in the
channel. Furthermore, the SPLIT function effectively offers two signal paths in one channel strip. A useful
graphic display on the channel bay TFT (see Channel Metering) makes clear, at any time, the current
arrangement for any channel.
