To return all faders to Absolute, use the JOIN or REVISE buttons until the 'global' rollback memory is reached,
at which point all faders will return to write either at their current position (REVISE), or at the levels they had at
the global rollback point (JOIN).
D D i i s s c c a a r r d d
If the system is in play or stopped following a rollback operation, pressing the Discard soft key, or the
dedicated DISCARD button, clears any data recorded since the start of the rollback pass, forces all channels in
write back to the read/write state they were in prior to the rollback operation at the point in time the Discard
function was operated, and restores the active rollback points from the previous pass.
U U p p d d a a t t i i n n g g a a M M i i x x P P a a s s s s
Project 16 :: Title 1 Project 16 :: Title 1
***NEW MIX*** MIX PASS 1:
you may adjust status now. you may adjust status now
Press Execute to continue Press Execute to continue
Execute Execute FSM FSM
Misc Misc
TR TR Auto Auto Lnks Lnks
Trim Trim TLock TLock Snap Snap
Moff Moff
P P r r o o t t e e c c t t i i o o n n M M o o d d e e s s
When you update a previously stored mix, three different data protection modes become available: Auto, Safe
and Manual.
Auto If moves need to be rewritten from scratch, faders can be dropped into write at the
start of a mix by pressing the fader status button. Alternatively, they can be
dropped into write once the mix is running, either by using the fader touch sensor
(motor faders on), or by pressing the fader status button.
Safe Existing fader and cut automation data can be protected with the Safe option.
When channels are in Safe, automation data is replayed but no data can be
written to these channels.
Manual Existing automation data is protected and the fader and cut switch act directly on
the channel audio. No automation is written or played back.
To select the different protection modes, press the ASM soft key, and then press the fader status button on the
desired channel to toggle between the modes, as displayed in the scribble strips above the faders. To select a
mode globally, press the ASM key and then press the FSM key until the required mode is selected.
All manuals and user guides at all-guides.com
Mix Enabled Mix Enabled
ASM
Cancel Cancel
SSL SSL
Misc Misc
AT AT CS CS
To update a Mix Pass, first select the desired mix
on the List Mix page by scrolling with the lefthand
rotary encoder and pressing the encoder switch.
***Mix Pass #*** will be displayed (see left), and
the selected mix will now become the reference
mix.
The FSM soft key will toggle all faders between
Absolute and Replay or Trim and Replay (see
below for more on Trim status).
Duality Operator's Manual
Updating a Mix Pass
5 5 - - 9 9
