CHARACTERISTICS:
The HD67671-IP-X-A1 and HD67671-MSTP-X-A1 are converters from BACnet slave to Modbus master and vice-versa.
They allows the following characteristics:
Up to 2000 BACnet objects (Read+Write);
Triple isolation between BACnet - Power Supply, BACnet - Modbus, Power Supply - Modbus.
Two-directional information between BACnet bus and Modbus bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67671 software on your PC in order to perform the following:
Define the parameter of BACnet line;
Define the parameter of Modbus line;
Define BACnet objects that contains the data read from the Modbus slaves;
Define BACnet objects that contains the data to send to the Modbus slaves;
Update the device.
