CONTENTS
I. INSTALLATION DIAGRAM / CONTROL PANEL / LEGEND .............................................................2
II. DATA PLATE and TECHNICAL DATA .................................................................................................22
III. INTRODUCTION ..................................................................................................................................23
IV. GENERAL INSTRUCTIONS ................................................................................................................25
V. INSTALLATION ....................................................................................................................................27
1. GENERAL INFORMATION...................................................................................................................27
2. TRANSPORT, HANDLING AND STORAGE ........................................................................................29
3. INSTALLATION AND ASSEMBLY ........................................................................................................29
4. CONNECTIONS ...................................................................................................................................29
VI. INSTRUCTIONS FOR OPERATOR FOR NORMAL MACHINE USE ..................................................32
1. VEGETABLE WASHER USE ................................................................................................................32
VII. CLEANING AND MAINTENANCE .....................................................................................................33
1. GENERAL SAFETY RULES ................................................................................................................33
2. NORMAL MACHINE USE ....................................................................................................................34
3. MACHINE CLEANING AND MAINTENANCE ......................................................................................35
4. MACHINE DISPOSAL ..........................................................................................................................37
5. ENCLOSED DOCUMENTATION ..........................................................................................................37
21
Advertisement
Table of Contents
Related Manuals for Electrolux Professional LV200
Summary of Contents for Electrolux Professional LV200
-
Page 1: Table Of Contents
CONTENTS I. INSTALLATION DIAGRAM / CONTROL PANEL / LEGEND .............2 II. DATA PLATE and TECHNICAL DATA ....................22 III. INTRODUCTION ..........................23 IV. GENERAL INSTRUCTIONS ........................25 V. INSTALLATION ............................27 1. GENERAL INFORMATION........................27 2. TRANSPORT, HANDLING AND STORAGE ..................29 3. INSTALLATION AND ASSEMBLY ......................29 4. -
Page 2: Data Plate And Technical Data
ATTENTION This handbook contains instructions relevant to various appliances. See the data plate located under the control panel to identify the appliance (see fi g. above). TABLE A - Electrical appliance technical data MODELS LV200 LV300 660031 660033 TECHNICAL DATA... -
Page 3: Introduction
III. INTRODUCTION The installation, use and maintenance Manual (hereinafter Manual) provides the user with information necessary for correct and safe use of the machine (hereinafter “machine” or “appliance”). The following must not be con- sidered a long and exacting list of warnings, but rather a set of instructions suitable for improving machine performance in every respect and, above all, preventing injury to people and animals and damage to property due to improper operating procedures. - Page 4 I ..........dust and water protection rating CE..........CE marking 0051 ..........notifi ed body EN 203-1 ........EU standard L..........Logo IMQ/GS Electrolux Professional SpA Viale Treviso, 15 33170 Pordenone (Italy)..........Manufacturer When installing the appliance, make sure the electrical con- nection is carried out in compliance with that specifi ed on...
-
Page 5: General Instructions
IV. GENERAL INSTRUCTIONS • Read the instruction handbook carefully before using the appliance. • Keep the instruction handbook for future reference. • RISK OF FIRE - Keep the area around the appliance free and clear of combustibles. Do not keep fl ammable materials in the vicinity of this ap- pliance. - Page 6 • Do not allow oil or grease to come into contact with plastic parts. • Do not allow grime, fat, food or other residuals to form deposits on the appliance. • Do not clean the appliance with direct jets of water. •...
-
Page 7: Installation
The drawings and diagrams Manufacturer given in the manual are not in scale. They supplement the Electrolux Professional SpA or any other assistance centre written information with an outline, but are not intended to be authorised by Electrolux Professional SpA. - Page 8 Electrolux Professional SpA declines any liability for inaccura- cies contained in the manual, if due to printing or translation errors.
-
Page 9: Transport, Handling And Storage
TRANSPORT, HANDLING AND ATTENTION! For machine lifting and anchoring, do not use STORAGE movable or weak parts such as: casings, electri- cal raceways, pneumatic parts, etc. 2.1. INTRODUCTION Transport (i.e. transfer of the machine from one place to 2.5. SHIFTING another) and handling (i.e. - Page 10 3.1. CUSTOMER RESPONSIBILITIES 3.4. DISPOSAL OF PACKING The tasks and works required of the Customer are: The packing must be disposed of in compliance with the current prearrange a high-sensitivity manual-reset differential regulations in the country where the appliance is used. All the thermal-magnetic switch.
-
Page 11: Connections
CONNECTIONS 4.2.1 POWER CABLE The power cable must be fl exible, having characteristics at Refer to the appliance data plate for the product code. least equal to the type with rubber insulation H07RN-F, and be See the installation diagrams for the position of connections protected by a metal or rigid plastic pipe. -
Page 12: Instructions For Operator For Normal Machine Use
• Load per cycle (Kg) and duration in minutes: during washing; • frequency of tank emptying (partial or total). With average LV200 LV300 Duration “dirt”, the tank should be emptied every 1 or 2 wash cycles. min. •... -
Page 13: Cleaning And Maintenance
1.2.2. SAFETY SIGNS TO BE PLACED ON THE MACHINE VII. C L E A N I N G A N D OR NEAR ITS AREA MAINTENANCE DANGER MEANING DANGER OF ELECTROCUTION GENERAL SAFETY RULES (placed on electrical parts with indication of voltage). ATTENTION! Machine maintenance operations must only be ATTENTION! -
Page 14: Normal Machine Use
1.2.6. RESIDUAL RISKS 2.2. CHARACTERISTICS OF PERSONNEL ENABLED TO OPERATE ON THE MACHINE The machine has several risks that were not completely eli- minated from a design standpoint or with the installation of The Customer is responsible for ensuring that persons assi- adequate protection devices. -
Page 15: Machine Cleaning And Maintenance
M A C H I N E C L E A N I N G A N D 3.4. PRECAUTIONS IN CASE OF LONG IDLE PERIODS If the appliance is not going to be used for some time, take MAINTENANCE the following precautions: •... - Page 16 3.6. LIMESCALE 3.9.1. MAINTENANCE INTERVALS STEEL SURFACES (when necessary) The inspection and maintenance intervals depend on the Remove any limescale (stains or marks) left by hard water on actual machine operating conditions and ambient conditions steel surfaces using suitable natural (e.g. vinegar) or chemical (presence of dust, damp, etc.), therefore precise time intervals cannot be given.
-
Page 17: Machine Disposal
MACHINE DISPOSAL ATTENTION! Machine maintenance, checking and overhaul ATTENTION! operations must only be carried out by a specialised DISMANTLING OPERATIONS MUST BE technician or the After-Sales Service, provided CARRIED OUT BY QUALIFIED PERSONNEL. with suitable personal protection equipment (safety shoes and gloves), tools and ancillary means.
