- Page 1 BARCO PROJECTION SYSTEMS R764081 - K REPLACEMENT KIT 2 EHT + SPLITTER IN BV508 WITH SINGLE EHT + SPLITTER Replacement kit for R774465 : EHT Transformer R107596 : Splitters ( with EHT Feedback connector ) R763021 : Splitters ( with Focus connection )
- Page 2 All rights reserved. Trademarks are the rights of their respective owners. BARCO n.v./Projection Systems Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com Visit Barco at the web : http://www.barco.com Printed in Belgium ___________________________________________________________________________________ R5976486.00 BARCO 17072002...
- Page 3 Remove R107596 (Splitter with PCB) and R763021 (Splitter without PCB) from BV508 assemply. Remove EHT R774465 and EHT cover Fix the single EHT with double diode (R7744865) on the EHT plate (R812671), with the help of washers (R367502 qty.04) and nuts (R366102 qty.04). R5976486.00 BARCO 17072002 __________________________________________________________________________________...
- Page 4 For the earthing cable, fix as shown to the EHT cover. Screw R3631259 (qty.01) Alternate Nuts R366103 (qty.02) Alternate Washers R367503 (qty.03) Fix the EHT plate & EHT to the EHT cover by 2 mounting Screws (V3621227) ___________________________________________________________________________________ R5976486.00 BARCO 17072002...
- Page 5 Replacement kit 2 EHT + Splitter in BV508 with single EHT + Splitter Guide EHT (Red) cable through circular wire. Fix the complete assembly to lens frame (R815589) through 4 nuts (R366102) and wash- ers (R367502) R5976486.00 BARCO 17072002 __________________________________________________________________________________...
- Page 6 Fix EHT Connector Z3440186 to the EHT with cable Ties Z348019 qty.04 as shown : 10. Cover unused hole of splitter with RTV 11. Fix the adapter plate (R819945) to the Frame Assy. by 04 screws (V3621217) ___________________________________________________________________________________ R5976486.00 BARCO 17072002...
- Page 7 12. Fix the splitter (R107595K) on Adapter using. V3621229 - Qty. 02 V3621227 - Qty. 01 13. Fix EHT and Focus cable (Z3496636). Route IR cable through hole in the EHT cover. 14. Fasten Feedback connector + Focus connector cable ties qty.03 R5976486.00 BARCO 17072002 __________________________________________________________________________________...
