P2127-810 PANEL PC User's Manual
Designed by the PC experts for PC professionals, the P2127-810 is
virtually the ultimate one-step solution for your space-limited
applications.
1.2

Specifications

1.2.1 Core System for P2127-810 system with
SBC83810
CPU: Intel Pentium M and Celeron M (Socket 479) FSB
System Chipset: Intel 855GME/852GM + 6300ESB
BIOS: Phoenix-Award BIOS, Y2K compliant
4Mbit Flash ROM, DMI, Plug and Play
System Memory: One 184-pin DDR DIMM Socket
L2 Cache: Integrated in CPU
Bus Clock: 400 MHz
Watchdog Timer: Interate Intel 6300ESB

1.2.2 I/O System

Standard I/O:
− 3 x serial ports with
power; 2 x RS-232, 1 x
RS-232/422/485 jumper
selectable
− 1 x parallel port,
SPP/EPP/ECP
− 1 x External FDD
Interface
2
400MHz
Maximum of 1GB DDR Memory
200/266/333MHz ECC/non-ECC DDR
supported
Up to 1024 levels as Reset/SMI features
− 1 x Keyboard Interface
− 1 x PS/2 Mouse Interface
− 1 x External IDE Interface
− 4 x USB Ports
− 1 x VGA Port
− 1 x RJ45 Port
− 1 x Audio in/out, MIC
