Chapter 1 Introduction; General Description - AXIOMTEK P2127-810 User Manual

This chapter contains the general information and detailed
specifications of P2127-810. Chapter 1 includes the following
sections:

General Description

Dimensions
Utilities Supported
1.1 General Description
The P2127-810 super slim industrial panel PCs are mainly designed
for industrial automation and some space-constricted embedded
applications. For some space-concerned industries, a traditional PC
with a separate main system, display monitor and keyboard is simply
not integrated enough.
Ruggedly designed, the P2127-810 is 100% IBM PC/AT compatible
and it integrates super I/Os, 12.1" TFT touchscreen, Ethernet, and
packs special industrial features like watchdog timer all in a single
system. The full PC functionality coupled with its industrial-grade
construction easily tailors the system for any embedded applications
-- allowing the system to endure continuous operation in any hostile
industrial environments where stability and reliability is a must.
The P2127-810 feature a versatile stand suited for a wide variety of
applications. With the pedestal kit assembled to the main unit, both
can transform into different positions such as desktop free standing,
30° table standing, panel mount and 30° wall mounting. Its cable
management device also trims the operation environment. The NEMA
4/12 water/dust-proof front panel is specially designed for the
continuous operation in outdoor environments. Common applications
of these PANEL PCs include POS, POI terminals, KIOSK, LAN,
Hospitality, Banking, Video Conferencing, Medical instrumentation,
Industrial and Office Automation - to name just a few.
Introduction
P2127-810 PANEL PC User's Manual
C h a p t e r
Introduction
System Specification
I/O Outlets
1
1
