ST X-NUCLEO-OUT13A1 User Manual page 10

Item
16 8
17 1
18 0
19 1
20 1
21 2
22 1
23 1
24 0
25 2
26 2
27 11
28 8
29 1
30 1
31 8
UM3081 - Rev 1
Q.ty Ref. Part/value
LED GREEN
D3 D4 D5 D6
0603 (1608
D7 D8 D9 D10
Metric) 20mA
RED LED 0603
D11 (1608 Metric)
20mA
ESDA7P60-1U1
D12
M 2-UDFN
SMBJ5.0A-TR
D13 DO-214AA,
SMB 600W
LED YELLOW
D15 0603 (1608
Metric) 20mA
JUMPER-con2-
J1 J2
strip-male
con6-2x3-strip-
J3
male
con6-2x3-strip-
J4
male
JUMPER-con2-
J5
strip-male
con8-2x4-strip-
J6 J7
male
JUMPER-con2-
J9 J10
strip-male
R1 R2 R3 R4 390 0402 (1005
R5 R6 R7 R8 Metric) 0.1W,
R9 R10 R11 1/10W 5%
R12 R13 R14 22k 0603 (1608
R20 R21 R22 Metric) 0.1W,
R23 R24 1/10W 1%
390 0603 (1608
R17 Metric) 0.1W,
1/10W 1%
1k 0603 (1608
R15 Metric) 0.1W,
1/10W 1%
R18 R19 R25 15k 0603 (1608
R26 R27 R28 Metric) 0.1W,
R29 R30 1/10W 1%
Description Manufacturer
LED GREEN
Wurth
CLEAR 0603
Electronics Inc.
SMD
LED RED
Wurth
CLEAR 0603
Electronics Inc.
SMD
TVS DIODE
5VWM 11.6VCL ST
1610 N.M.
TVS DIODE 5V
ST
13.4V SMB
LED YELLOW
Wurth
CLEAR 0603
Electronics Inc.
SMD
JUMPER-
CONN Wurth
HEADER .100 Electronics Inc.
STR 2POS
CONN
HEADER .100 Wurth
DUAL STR Electronics Inc.
6POS
CONN
HEADER .100 Wurth
DUAL STR Electronics Inc.
6POS
JUMPER-
CONN Wurth
HEADER .100 Electronics Inc.
STR 2POS
CONN
Wurth
HEADER VERT
Electronics Inc.
8POS 2.54MM
JUMPER-
CONN Wurth
HEADER .100 Electronics Inc.
STR 2POS
CHIP
RESISTOR
Panasonic
SMD 5% 1/10W
0402
RES SMD 22K
OHM 1% 1/10W Yageo
0603
RES SMD 390
OHM 1% 1/10W Yageo
0603
RES SMD 1K
OHM 1% 1/10W Yageo
0603
RES SMD 15K
OHM 1% 1/10W Yageo
0603
UM3081
Bill of materials
Order code
150060VS75000
150060RS75000
ESDA7P60-1U1M
SMBJ5.0A-TR
150060YS75000
61300211121
61300621121
61300621121
61300211121
61300821121
61300211121
ERJH2GJ391X
RC0603FR-0722KL
RC0603FR-07390RL
RC0603FR-071KL
RC0603FR-0715KL
page 10/19
