- Page 3 Interline Transfer CCD camera featuring Navitar’s acclaimed precision optics. To increase on-screen resolution even further, the VideoMate 2300 can be used with a scan doubler. The VideoMate 2300 outputs Y/C (S-Video) and composite signals. In addition, it has the ability to genlock into a video system.
- Page 4 VideoMate Slide-to-Video...
- Page 7 Keep the unit in the original moisture proof package while it warms up. (The goal is to prevent warm, moist air from striking the cold electronic and optical components, which will cause damaging condensation). Never operate a cold projector to warm it up.
- Page 8 Before starting, review the precautions on page 6. To “Quick Start” the VideoMate 2300, proceed as follows: 1. Unwind the cord under the base of the unit and plug it into a suitable power supply.
- Page 9 Before starting, review the precautions on page 6. To install the VideoMate 2300, proceed as follows: 1. Unwind the power cord under the base of the unit and plug it into a suitable power source. 2. Connect the cable to your peripheral equipment (TV monitor, video projector, etc.).
- Page 10 Due to transportation, the image position might shift from the factory setting. To correct this shift: 1. Remove two plugs as shown in the figure below. 2. Using a Phillips screw driver, rotate screw #1 to adjust the vertical position and screw #2 to adjust the horizontal position.
- Page 11 Load all slides and replace and lock the top lock ring. 1. Center the tray over the post on the projector. 2. Gently rotate the tray until the #0 slide slot is at the index mark and the tray will drop into position.
- Page 12 2. Push the select bar down and the slide should come up. If the tray is still jammed: 1. While holding the projector post release tab located at the center of the slide tray, grasp the tray on the side opposite the index mark and lift.
- Page 13 The entire illumination system is contained in a unit called a lamp module. This module is a drawer type configuration, which may be removed from the projector to change the lamp. Unfortunately, it takes 5 to 10 minutes to change the lamp, because it must first be allowed to cool down.
- Page 14 Connects to an internal single-pole, single-throw normally closed switch. Contacts are open when a slide is in the projector gate and the shutter is open. These leads connect only to the switch terminals. Do not exceed a switching load of 1 A at 30 V ac.
- Page 15 Supply is 25.5 V, 500 mA (1/2 A) maximum. Contact number 8 is common (return) for the remote-control circuit.
- Page 16 The VideoMate 2300 can be genlocked into any video system. In order to utilize the genlock feature, a second video source, a video switcher box and the appropriate input/output cables are required. We also strongly recommend the use of a vector scope for the best possible results.
- Page 17 Adjusting the Sub Carrier Phase 1. Set the arrow “ “ to SC PHASE by pushing the FUNCTION UP, FUNCTION DOWN buttons. 2. Adjust the sub carrier phase by pushing the DATA UP, DATA DOWN buttons. The values range from -99 to 99, DATA UP will increase the setting towards 99 and DATA DOWN will decrease it towards -99.
- Page 18 e l t e t f f e i u r r i t p . r e g i l . t h . p r " z i l i l r e . y l r " t e t t c u t l e r...
- Page 19 z i r l a t i t u l v i t i y t i o i t i t p j o r r o t s i r I o r t o r t i t a i t p ) l a Design and specifications are subject to change...
- Page 20 Parts not manufac- tured by Navitar carry only the warranty of their manu- facturer. Lamps and fuses carry no warranty. This warranty does not cover damage caused in transit;...
- Page 21 Ektagraphic and Kodak are both trademarks of the Eastman Kodak Company. VideoMate and Navitar are both trademarks of Navitar, Inc.
