SPR275OS2D
ADRD27
LD272D
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Model and Serial Numbers here:
Model No.:
Serial No.:
FROST-FREE DRAWER
REFRIGERATOR
User Manual
SPR3032D
ADRD30
ADRD30SS
LD302D
Felix Storch, Inc.
An ISO 9001:2015 registered company
770 Garrison Ave
Bronx, New York 10474
www.summitappliance.com
Advertisement
Table of Contents
Related Manuals for Summit SPR275OS2D
Summary of Contents for Summit SPR275OS2D
- Page 1 FROST-FREE DRAWER REFRIGERATOR SPR275OS2D SPR3032D ADRD27 ADRD30 LD272D ADRD30SS LD302D User Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Write Model and Serial Numbers here: Felix Storch, Inc. An ISO 9001:2015 registered company Model No.:...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Appliance Safety Important Safeguards Location of Parts Installation Instructions Before Using the Appliance Installation of your Appliance Electrical Connection Anti-tip Bracket Installation Installation of the Handle Panel Ready Installation Operating your Appliance 10-12 Control Panel ON/OFF Power / Mute Setting the Temperature Smart Control Mode ECO Mode... -
Page 3: Appliance Safety
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 Air the room in which the appliance is located for several minutes, and Contact the Service Department for advice. • The more coolant there is in an appliance, the larger the room in which it should be installed. In the event of a leakage, if the appliance is in a small room, there is the danger of combustible gases building up.
-
Page 5: Location Of Parts
LOCATION OF PARTS CALIFORNIA CARB/SNAP DISCLOSURE This product uses eco-friendly hydrocarbon refrigerant and fully complies with California CARB regulations. However, we are required by California law to provide the following disclosure statement in every product sold in California: "This equipment is prohibited from use in California with any refrigerants on the 'List of Prohibited Substances' for that specific end-use, in accordance with California Code of Regulations, title 17, section 95374. -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Before Using Your Appliance • Remove the exterior and interior packing. • Before connecting the appliance to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. -
Page 7: Anti-Tip Bracket Installation
The measurements for the anti-tip bracket installation are illustrated below: Models: SPR275OS2D, ADRD27, LD272D Models: SPR3032D, ADRD30, ADRD30SS, LD302D NOTE: If the appliance is relocated, the bracket must be removed and installed in the new location. -
Page 8: Installation Of The Handle
3. Prepare your panel with installation holes and holes for the bottom mounting brackets (20 x 6mm), then secure the mounting brackets to the panel with screws. Be sure to add handle holes to the panel. NOTE: The measurements listed in the graphic below are in millimeters. Models: SPR275OS2D, ADRD27, LD272D... - Page 9 Models: SPR3032D, ADRD30, ADRD30SS, LD302D 4. Set the panel against the drawer front, and secure it to the bottom of the drawer, with screws. Then, install the handle onto the drawer, through the panel.
-
Page 10: Operating Your Appliance
OPERATING YOUR APPLIANCE The appliance should be placed where the ambient temperature is between 10~38°C (50~100°F). If the ambient temperature is above or below this range, the performance of the appliance may be affected. Placing your appliance in extreme cold or hot conditions may cause interior temperatures to fluctuate. -
Page 11: Smart Control Mode
Force Quitting Smart Control Mode Press and hold the buttons simultaneously for 5 seconds, the small dot in the upper left corner of the LED will illuminate. • After quitting the smart control mode, the alarm will not sound when the door is open for more than 5 minutes. -
Page 12: Defrosting
Defrosting • The appliance defrosts automatically in normal operating conditions. • The evaporator behind the rear wall of the appliance defrosts automatically. The condensate collects in the drainage channel behind the rear wall of the appliance and flows through the drainage hole into the drip tray by the compressor where it evaporates. -
Page 13: Care And Maintenance
CARE AND MAINTENANCE Cleaning Your Appliance • Turn off the power, unplug the appliance, and remove all items. • Wash the inside surfaces with a warm water and baking soda solution. The solution should consist of about 2 tablespoons of baking soda to a quart of water. •... -
Page 14: Troubleshooting
TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM POSSIBLE CAUSE REMEDY Appliance does not The appliance defrosts automatically Connect the appliance. - Page 15 There is a difference The appliance is being turned on for This is normal, leave the appliance between the running for several hours and the the first time, after a restart, or a temperature inside the temperature will stabilize, if this does long period out of operation.
-
Page 16: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
