FROST-FREE DRAWER REFRIGERATORS,
REFRIGERATOR/FREEZERS
Refrigerators:
ASDR1524
SDDR1558
LDR2437
FF642D
Freezers:
ADFD243
Refrigerator/Freezers:
ADRF244
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Serial Nos. (on lower left side of
bottom drawer) here:
FREEZERS and
Models:
LADR1545
ASDR2414
SDDR2448
SPR627OS2D
SCFF532DADA
SPRF2D24ADA
User Manual
ASDR1554
SDR1529
LADR2433
ASDR2444
ADRD241
FF642DADA
LDF24A
SCFF532D
LDRF24A
SPRF34D
Felix Storch, Inc.
An ISO 9001:2015 registered company
770 Garrison Ave
Bronx, New York 10474
www.summitappliance.com
LDR1549
SDR2418
LDR24A
SPFF51OS2D

Advertisement

Table of Contents
loading

Related Manuals for Summit ASDR1524

Summary of Contents for Summit ASDR1524

  • Page 1 FROST-FREE DRAWER REFRIGERATORS, FREEZERS and REFRIGERATOR/FREEZERS Models: Refrigerators: ASDR1524 LADR1545 ASDR1554 SDR1529 LDR1549 SDDR1558 ASDR2414 LADR2433 ASDR2444 SDR2418 LDR2437 SDDR2448 ADRD241 FF642DADA LDR24A FF642D SPR627OS2D Freezers: ADFD243 SCFF532DADA LDF24A SCFF532D SPFF51OS2D Refrigerator/Freezers: ADRF244 SPRF2D24ADA LDRF24A SPRF34D User Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Appliance Safety Important Safeguards Location of Parts Installation Instructions Before Using your Appliance Installation of your Appliance Electrical Connection Anti-tip Bracket Installation Installing the Stainless Steel Handles Fully Overlay Panel Installation Adjusting the Kick Plate Operating your Appliance 11-16 Control Panel for Refrigerators 11-12...

  • Page 3: Appliance Safety

    APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others.
  • Page 4 • For every ounce of coolant at least 325 cubic feet of room space is required. The amount of coolant in the appliance is stated on the data plate inside the appliance. It is hazardous for anyone other than an Authorized Service Person to carry out servicing or repairs to this appliance. •...

  • Page 5: Location Of Parts

    LOCATION OF PARTS Refrigerators: ASDR1524 / LADR1545 / ASDR1554 / SDR1529 / LDR1549 / SDDR1558 / ASDR2414 / LADR2433 / ASDR2444 / SDR2418 / LDR2437 / SDDR2448 / ADRD241 / FF642DADA / LDR24A Freezers: ADFD243 / SCFF532DADA / LDF24A Refrigerator/Freezers: ADRF244 / SPRF2D24ADA / LDRF24A / SPRF34D...
  • Page 6 Refrigerators: FF642D / SPR627OS2D Freezers: SCFF532D / SPFF51OS2D NOTES: • Models SPR627OS2D, ADRD241, LDR24A, SPFF51OS2D, ADFD243, SCFF532DADA, LDF24A, ADRF244, LDRF24A,and SPRF2D24ADA are designed for outdoor as well as indoor use. They are equipped with a reinforced exterior and a power cord made to stand up to the elements.

  • Page 7: Installation Instructions

    INSTALLATION INSTRUCTIONS Before Using your Appliance • Remove the exterior and interior packing. • Before connecting the appliance to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation.
  • Page 8 Model No. (Inch/mm) (Inch/mm) (Inch/mm) (Inch/mm) (Inch/mm) (Inch/mm) 32⅛" / 816 ASDR1524 32" / 813 18" / 455 14¾" / 375 18" / 455 15" / 380 32⅛" / 816 23⅝" / 600 ASDR2414 32"...

  • Page 9: Anti-Tip Bracket Installation

    3. Models FF642DADA, LDR24A, ADFD243, SCFF532DADA, LDF24A, ADRF244, SPRF2D24ADA and LDRF24A have the same size as ADRD241. 4. Models FF642D, SCFF532D, SPFF51OS2D and SPRF34D have the same size as SPR627OS2D. Anti-tip Bracket Installation To reduce the risk of tipping the unit by abnormal usage or improper loading, the appliance must be secured by properly installing the anti-tip device packed with the appliance.

  • Page 10: Fully Overlay Panel Installation

    Cut the overlay panels with thickness 3/4” to the • following dimensions: 14.75” x 14.1” for models ASDR1524 / LADR1545 / ASDR1554 / SDR1529 / LDR1549 / SDDR1558; 23.43” x 14.1” for models ASDR2414 / LADR2433 / ASDR2444 / SDR2418 /...

  • Page 11: Adjusting The Kick Plate

    Adjusting the Kick Plate Only for models ASDR1524 / LADR1545 / ASDR1554 / SDR1529 / LDR1549 / SDDR1558 / ASDR2414 / LADR2433 / ASDR2444 / SDR2418 / LDR2437 and SDDR2448. The pre-fitted kick-plate of the appliance includes an adjustable kick-plate section that is initially seated behind the upper section.

  • Page 12: Control Panel For Freezers

    DOWN - Used to decrease (cool) the set temperature by 1°C/1ºF. ºF/ºC Selector Select the temperature display in Fahrenheit or Celsius degrees. For refrigerators FF642D and SPR627OS2D, to change the temperature from Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the LIGHT key for 5 seconds. Indicator Light The indicator light is the dot located at the bottom right corner of the display.
  • Page 13 SuperFreeze SuperFreeze is used to freeze fresh food quickly. The function overrides the thermostat control and will make the compressor operate continuously. It is not necessary to adjust the thermostat setting when using this function. When the function is selected, the SuperFreeze indicator (the dot at the bottom right of the display) will be ON.

  • Page 14: Control Panel For Refrigerator/Freezers

    Control Panel for Refrigerator/freezers ON/OFF Power To turn the appliance off, touch and hold the key for 5 seconds until the temperature display goes off. To turn the appliance on, touch and hold the key for 1 second until the temperature display lights up.

  • Page 15: Interior Light

    NOTES: • If the unit is unplugged or power is lost or turned off, you must wait 3 to 5 minutes before restarting the unit. If you attempt to restart before this time delay, the unit will not start. • When you use the unit for the first time or restart the unit after it has been shut off for a long time, there could be a few degrees variance between the temperature you select and the one indicated on the LED readout.

  • Page 16: Using The Freezer

    Using the Freezer (if available) • This unit is designed for the long-term storage of frozen food. Storage time is up to three months. • The storage life of frozen foods varies, and the recommended storage time should not be exceeded.

  • Page 17: Care And Maintenance

    CARE AND MAINTENANCE Cleaning Your Appliance • Turn off the power, unplug the appliance, and remove all items, including racks and dividers. • Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of baking soda to a quart of water).

  • Page 18: Troubleshooting

    TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM POSSIBLE CAUSE REMEDY Appliance is not connected to a power Connect the appliance.
  • Page 19 “E5” or “E7”. temperature sensor has failed. “E3” or “E4” indicates that the defrost sensor in the evaporator has failed. “E5” indicates defrost heater failure. “E7” indicates door switch failure. Has a drawer been open for longer than If yes, close the drawer. 60 seconds? If not, then the temperature has risen higher or fallen lower than the The alarm...

  • Page 20: Limited Warranty

    LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
