8 Technical data
8.5

Electrical data

Voltage supply
according to the ordered ver-
sion
Electrical safety
Power consumption
Type 701590
Type 701591
Accuracy of timer
Sampling rate
Electrical connection
Conductor cross section, mechani-
cal
Wire or stranded wire
(without ferrule)
Stranded wire with ferrule
Stripping length
Conductor cross section, electric
5 A load current
10 A load current
16 A load current
8.6

Environmental influences

Ambient temperature range
Storage
Operation
Site altitude
Climatic environmental influences
Resistance to climatic conditions
Storage
Operation
Mechanical environmental influences
Storage
Transport
Operation
Electromagnetic compatibility (EMC)
Interference emission
Interference immunity
a
The product is suitable for industrial use as well as for households and small businesses
26
02 AC 230 V -15/+10 %, 48 to 63 Hz
05 AC 115 V -15/+10 %, 48 to 63 Hz
30 DC 12 to 24 V, -15/+15 % SELV
acc. to DIN EN 61010, part 1
Overvoltage category II to 300 V mains voltage,
Pollution degree 2
Type AC 230 V:
Max. 2.1 W
Max. 2.1 W
1 %
250 ms
On the back via plug connectors with spring-cage terminals (PUSH IN tech-
nology)
2
Min. 0.2 mm , max. 1.5 mm
(terminal strips 3 and 4: max. 2.5 mm
Without plastic collar: min. 0.25 mm
(terminal strips 3 and 4: max. 2.5 mm
With plastic collar: min. 0.25 mm
(terminal strips 3 and 4: max. 2.5 mm
8 mm
2
Min. 0.75 mm
2
Min. 1.0 mm
2
Min. 1.5 mm
-30 to +70 °C
-10 to +55 °C
Max. 2000 m above sea level
According to DIN EN 60721-3 with extended temperature range
≤ 90 % rel. humidity without condensation
According to class 1K2
According to class 3K3
According to DIN EN 60721-3
According to class 1M2
According to class 2M2
According to class 3M3
Product family standard DIN EN 61326-1
a
Class B
Industrial requirement
Type AC 115 V:
Max. 3.3 W
Max. 3.3 W
2
2
)
2
, max. 1.5 mm
2
)
2
, max. 0.75 mm
2
)
Type DC 12 to 24 V:
Max. 1.2 W
Max. 1.2 W
2
2
