Trigger, Encoder, Mode Switching

The switching inputs of the multifunction port can either be used for encoder input, for
trigger input or for loading previously stored user modes.
The signal levels are switchable for all switching inputs between LLL (low-voltage-,
TTL logic) and HLL (high-voltage-, HTL logic):
- LLL level: Low 0 V ... 0.8 V, high 2.4 V ... 5 V, internal pull-up 10 kΩ to 5 V
- HLL level: Low 0 V ... 3 V, high 11 V ... 24 V (permitted to 30 V), internal pull-up 10
kΩ to 24 V
- Pulse duration: ≥ 5 µs
Multifunction Port
Designation
+Ub
GND
+Laser on/off
-Laser on/off
RS422
/RS422
In1
GND-In1
In2
GND-In2
In3
GND-In3
Shield
2
3
10
4
1
11
5
9
6
8
7
12
External Laser Switching
The sensors of the scanCONTROL 26xx/SI, scanCONTROL 29xx/SI series offer this
function.
Use a serial key switch inside the control circuit to switch off the laser.
You will find details for the wiring in the instruction manual, Chap. 5.2.6.
Sensor con-
nector pin PC2600/2900-x
9
2
3
1
12
11
6
4
5
8
10
7
Housing
12-pin screw connector, view on solder pin side
GND: galvanically isolated from 1, 2, 3, RS422, Laser on/
off
Laser on/off: Input galvanically isolated from GND,
IN1...3, RS422
IN1, IN2, IN3, RS422: Inputs galvanically isolated from
GND and Laser on/off
Cable color
red
blue
white
brown
red-blue
RS422, input respectively output
gray-pink
yellow
green
pink
gray
violet
black
black No galvanic connection to GND
Notes
+ 11 V - 30 V DC (rated value
24 V); max. 500 mA
0 V
optional
Digital Input 1
Ground In 1
Digital Input 2
Ground In 2
Digital Input 3
Ground In 3
