X-Box Ultra System Connections - Typical Installation
Key
ControlNet
connections
Serial
connections
Wireless Receiver
Foot Controller
Smart Combiner Box
ControlNet connection to a single wired
or wireless controller, or multiple
controllers via a smart combiner box.
USB
connection
Video
connections
USB-C
X-Box Ultra or
X-Box Ultra SDI
SRL-C
HC-1
Typically located
on desk with
WinPlus PC.
Installation
WinPlus Software PC
Prompter Monitors
Up to four directly
connected.
