Components and Connections
Front View
1
1
Fuse holder
2
AC power indicator LED
3
DC power indicator LED
4
Serial socket
5
USB socket
6
ControlNet/Genlock input
4
3
2
Rear View
4
5
7
Composite video/SDI* output sockets
8
DC power out socket
9
Power switch
10
DC power in socket
11
AC power in socket
*Optional X-Box Ultra SDI version only.
