Front Panel Description

The front panel consist of two (2) indicator lights that illuminate during usage:
1. Power: Indicates that the MRX-30 is powered when illuminated.
2. Ethernet: When the device has valid Ethernet connection, the
indicator light remains a solid blue.
3. Status Light: Two (2) possible states:
■ Status Light On: Connected to LAN and internet.
■ Status Light Off: Connected to LAN, no internet or Ethernet cable has
been unplugged.
4. Reset: Press once to power cycle the device.
