5560A/5550A/5540A
Remote Programmers Manual
RTD_TYPE_D
x
IEEE-488
(Resistance Temperature Detector Type Default command) Sets the default Resistance
Temperature Detector (RTD) at power on and reset, which is saved in the Calibrator non-volatile
memory. (While saving configuration data in the non-volatile memory, a period of about
2 seconds, the Calibrator does not respond to remote commands.)
Parameters: PT385
PT385_200
PT385_500
PT385_1K
PT3926
PT3916
CU10
CU50
CU100
NI120
Example:
RTD_TYPE_D PT3926
Set the RTD default type to a 100-ohm RTD with curve α=0.003926 ohms/ohm/°C.
RTD_TYPE_D?
x
IEEE-488
(Resistance Temperature Detector Type Default query) Returns the default Resistance
Temperature Detector (RTD) used at power on and reset.
Responses: PT385
PT385_200
PT385_500
PT385_1K
PT3926
PT3916
CU10
CU50
CU100
NI120
Example: RTD_TYPE_D? returns PT3926
Returns PT3926 when the RTD default type is a 100-ohm RTD with curve α=0.003926 ohms/
ohm/°C.
94
x x
x
USBTMC RS-232 Ethernet
(100-ohm RTD, curve α=0.00385 ohms/ohm/°C)
(200-ohm RTD, curve α=0.00385 ohms/ohm/°C)
(500-ohm RTD, curve α=0.00385 ohms/ohm/°C)
(1000-ohm RTD, curve α=0.00385 ohms/ohm/°C)
(100-ohm RTD, curve α=0.003926 ohms/ohm/°C)
(100-ohm RTD, curve α=0.003916 ohms/ohm/°C)
(10-ohm RTD, empirical curve)
(50-ohm RTD, empirical curve)
(100-ohm RTD, empirical curve)
(120-ohm RTD, empirical curve)
x x
x
USBTMC RS-232 Ethernet
(100-ohm RTD, curve α=0.00385 ohms/ohm/°C)
(200-ohm RTD, curve α=0.00385 ohms/ohm/°C)
(500-ohm RTD, curve α=0.00385 ohms/ohm/°C)
(1000-ohm RTD, curve α=0.00385 ohms/ohm/°C)
(100-ohm RTD, curve α=0.003926 ohms/ohm/°C)
(100-ohm RTD, curve α=0.003916 ohms/ohm/°C)
(10-ohm RTD, empirical curve)
(50-ohm RTD, empirical curve)
(100-ohm RTD, empirical curve)
(120-ohm RTD, empirical curve)
x
Sequential Overlapped
x
Sequential Overlapped
x
Coupled Lockout
Coupled Lockout
