Fluke Calibration 5560A Programmer's Manual page 62

5560A/5550A/5540A
Remote Programmers Manual
COILTURNS_D
x
IEEE-488
Sets the default custom external current coil turns used at power on and reset, which is saved in
the Calibrator non-volatile memory. (The Calibrator does not respond to remote commands for
about 2 seconds while it saves configuration data in the non-volatile memory.)
COILTYPE_D must be set to CUSTOM for COILTURNS_D value to be applied.
Parameters: 1. <value> number of turns in custom external coil.
Example: COILTURNS_D 20
Sets the custom coil turns to 20.
COILTURNS_D?
x
IEEE-488
Returns the default custom external current coil turns used at power on and reset.
Parameters: None
Example: COILTURNS_D? returns 30
The default custom external coil turns is set to 30.
COILTYPE_D
x
IEEE-488
Sets the default external current coil type at power on and reset, which is saved in the Calibrator
non-volatile memory. (The Calibrator does not respond to remote commands for about
2 seconds while it saves configuration data in the non-volatile memory.)
Parameters: 1.NONE
C5500A50T
C9100_10T
C9100_50T
C55XXA50T
C55XXA1T
C55XXA2T
C55XXA10T
C52120A25T
C52120A50T
CUSTOM
Example:
COILTYPE_D C55XXA10T
Sets the default external current coil type to the 55XXA 10 turn coil.
58
x x
x
USBTMC RS-232 Ethernet
x x
x
USBTMC RS-232 Ethernet
x x
x
USBTMC RS-232 Ethernet
x
Sequential Overlapped
x
Sequential Overlapped
x
Sequential Overlapped
x
Coupled Lockout
Coupled Lockout
x
Coupled Lockout
