Operation; Operate The Shade - Kirsch Cellular Shade Getting Started

Lift the bottom rail to locate the two pockets on the underside of the rail.
■ ■
NOTE: Side light shades that are 4" to 7
Fully insert the ⁄ " rail adjust key into the pocket. The key is fully inserted when the
■ ■ 7
64
base of the key abuts to the pocket.
Turn the key clockwise to increase the tension or counter-clockwise to decrease the
■ ■
tension.
Begin by turning the key one-quarter turn, in the same direction, for each pocket.
■ ■
IMPORTANT: The key must be fully inserted to avoid stripping the mechanism. Do
not pull down on the rail while turning the key.
After pocket adjustments are made, remove the key and install the bottom rail back
■ ■
into the specialty brackets.
Recheck the tension on both moving rails.
■ ■
If further adjustments are needed, repeat the above steps.
■ ■

Operate the Shade

For better support and smoother operation, use the handle when raising and lowering the shade.
Top-Down or Bottom-Up Shades: To Raise or Lower the Moving Rail
Slowly and steadily push up or down on the moving rail handle. Allow the fabric to stack evenly.
■ ■
Top-Down/Bottom-Up Shades: To Raise or Lower the Moving Rails
Slowly and steadily push up or down on the moving rail handles.
■ ■
Allow the fabric to stack evenly.
To completely lower the shade (fabric stack at the bottom), first lower
■ ■
the bottom moving rail fully, then lower the top moving rail.
To completely raise the shade (fabric stack at the top), first raise the
■ ■
top moving rail fully, then raise the bottom moving rail.
INSTALLATION
INSTALLATION
⁄ " wide only have one pocket.
7
8

OPERATION

7
Pocket
Underside of Bottom Rail
Decrease
Increase
Key
Top-Down Shade
Illustrated
