Step 2: Installing The Shade; Operation; Step 3: Operating The Shade; Step 4: Adjusting The Shade - Kirsch Basics Cellular Installation Instructions Manual

Extension Brackets (Optional)
Position the extension brackets to the desired wall location.
■
The bracket tops must be aligned and level to one another.
■
Mount the extension brackets through the back holes with two screws.
■
Attach the installation brackets to the extension brackets.
■
NOTE: Use the same holes for all brackets to ensure even projection from the surface.
Installation brackets attached to extension brackets with the included screws and nuts.

Step 2: Installing the Shade

Mount the Headrail
Hold the shade up near the brackets and insert the front clip of the bracket into the front groove of the rail.
■
Make sure the shade is centered in the window opening.
■
Push the rail back and up until the back clips of the bracket are inserted in the back groove of the rail.
■
To REMOVE shade, reverse the procedure.
■

Step 3: Operating the Shade

To Raise and Lower a Cordless Shade
Push and hold the button on the bottomrail handle.
■
Raise or lower the shade to the desired position.
■
Release the button to lock the shade into place.
■

Step 4: Adjusting the Shade

Raise and lower the shade several times.
■
If the length is incorrect or the bottomrail is not level, use the following steps to correct.
■
Shade Adjustment
Remove headrail from mounting brackets.
■
Use a screwdriver or dime.
■
Turn screw clockwise to lift that side of the shade.
➤
Turn screw counter clockwise to lower that side of the shade.
➤
Half a revolution is ⁄
1
➤
4
Intermediate Rail Shade Adjustment
Lift intermediate rail on side to be adjusted. This will take the weight off the cord.
■
Use a screwdriver or dime.
■
Turn screw clockwise to lift that side of the rail.
➤
Turn screw counter clockwise to lower that side of the rail.
➤
Half a revolution is ⁄
1
➤
4
" adjustment (maximum adjustment is
" adjustment (maximum adjustment is
INSTALLATION
INSTALLATION

OPERATION

⁄ ").
1
2
⁄ ").
1
2
4
