Mount The Specialty Brackets - Outside Mount - Kirsch Cellular Shade Getting Started

Mount the Specialty Brackets — Outside Mount
Your order will include four specialty brackets.
■ ■
Center the headrail over the window opening at the desired height. Use a pencil to lightly mark each end of the headrail.
■ ■
Alternatively, measure the width of the headrail and use that width to mark the rail end points at the top of the
➤ ■
window opening.
Measure from each end of the headrail to the center of the rectangular hole and mark the position of each specialty bracket for
■ ■
the headrail.
Repeat the above steps for the bottom rail.
■ ■
To center of
rectangular
hole in rail
Center the specialty brackets on your marks, then mark each of the screw holes.
■ ■
A minimum flat vertical surface of
➤ ■
The top of the specialty brackets or extension brackets should be at the desired shade height.
➤ ■
IMPORTANT: The specialty brackets must be level and aligned to each other.
CAUTION: The rear of the specialty brackets must be flush against a flat mounting surface. Do not mount brackets on
curved molding.
Specialty
Bracket
Drill the screw holes using a
■ ■
CAUTION: Use drywall anchors when mounting into drywall.
Attach the specialty brackets or extension brackets at the top and bottom of the window opening using the screws provided.
■ ■
IMPORTANT: The front edges of the specialty brackets must be level and aligned to each other.
INSTALLATION
INSTALLATION
Headrail End Marks
Window Opening
⁄ " is required to mount the brackets.
5
8
Extension
Bracket
⁄ " drill bit.
3
32
To center of
rectangular
hole in rail
4
