- Page 1 User Manual VEGA-2002 4Kp60 HEVC Real-time Encoder...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 We recommend the use of shielded cables. This kind of cable is available from Advantech. Test conditions for passing included the equipment being operated within an industrial enclosure. In order to protect the prod- uct from being damaged by ESD (Electrostatic Discharge) and EMI leakage, we strongly recommend the use of CE-compliant industrial enclosure products.
- Page 4 Warnings, Cautions and Notes Warning! Warnings indicate conditions, which if not observed, can cause personal injury! Caution! Cautions are included to help you avoid damaging hardware or losing data. e.g. There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to recharge, force open, or heat the battery.
- Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
- Page 6 VEGA-2002 User Manual...
-
Page 7: Table Of Contents
Contents Chapter Product Introduction ......1 General Introduction.................. 2 Packing List....................2 Product Specifications................3 Software Architecture................4 Module Board Dimension................5 Chapter Installing VEGA-2002 ......7 Start working with VEGA-2002..............10 2.1.1 Accessing the Module Across Wired Network Using the Web Browser.................. - Page 8 VEGA-2002 User Manual viii...
-
Page 9: Chapter 1 Product Introduction
Chapter Product Introduction... -
Page 10: General Introduction
General Introduction With video streaming thriving recently, new concepts such as social media and live streaming are gaining popularity among video professionals. The VEGA-2002 is able to leverage the ubiquity of mobile networks and the flexibility of over-the-top delivery without jeopardizing the video quality by providing a professional-grade 4K HEVC engine that can be easily integrated as a portable broadcasting solution. -
Page 11: Product Specifications
Product Specifications 4X3GS 12GS 1x 3G-SDI or HDMI 4 x 3G-SDI, up to 1 x 12G-SDI or Channels/ 2.0, up to 4Kp60 8/10 4Kp60 8/10 bit 4:2:2 HDMI2.0, up to interface bit 4:2:2 4Kp60 8/10 bit 4:2:2 HDMI 2.0 Interface BNC (3GS-SDI) Inter- HDMI 2.0 Interface 3840x2160:... -
Page 12: Software Architecture
Dynamic Video Stream Resolution Change Video Stream Features Streaming RTSP/RTP/RTMP/HLS/TS over IP/SRT/NDI HX2(option) Protocol I, IP, IPB, IBBP Definition Operation Embedded Linux System Management & Control Remote from Web GUI interface Interface Power Module Consumption Characteristic (Base on 10.7W 17.8W 9.4W 4Kp60 Video Encoding) -
Page 13: Module Board Dimension
Module Board Dimension VEGA-2002-12G SDI/HDMI VEGA-2002-4X3G SDI VEGA-2002-3G SDI/HDMI VEGA-2002 User Manual... - Page 14 VEGA-2002 User Manual...
-
Page 15: Chapter 2 Installing Vega-2002
Chapter Installing VEGA-2002... - Page 16 VEGA-2002 User Manual...
- Page 17 Following these steps below: Connect a video source to SDI or HDMI video inputs. Connect the power adapter to power jack.(When power on ,the power LED is Blue) Connect the LAN cable to the Internet HUB. Please make sure your PC's LAN cable is also connected to the HUB as well.(If you want your PC serves as a decoder) Connect your USB flash drive to the USB1 or USB2 for the recording function.
-
Page 18: Start Working With Vega-2002
The VEGA-2002 firmware can be automatically updated by connecting a USB flash drive to VEGA-2002 using the USB port. Prepare an empty USB flash drive (FAT32). Download or get firmware file from your Advantech contact. Put firmware file, “vega2002_XXXX.upd.xz” to the root directory of your USB flash drive. -
Page 19: Led For Video Source Connection
Note! Users can also use Web GUI to upgrade Firmware, please refer to chapter 3.2 2.1.3 LED for Video Source Connection There are two LED which can indicate connection status of video source. Below is LED behavior table for reference. LED Status Table ... - Page 20 – VEGA-2002-4X3GS – VEGA-2002-3GS VEGA-2002 User Manual...
-
Page 21: Chapter 3 Vega-2002 Web Gui
Chapter VEGA-2002 Web GUI... -
Page 22: Live Page
Live Page Live page display current screen from video source. It can be selected to get video source from SDI or HDMI. Right-up corner shows current detected resolution. It also provided the control of Snapshot, full-screen and audio energy bars at left-up side. System Page The System page shows the Information, Initialize, Time setting, System Log and Access Log. - Page 23 Note! Users can use “Firmware upgrade” function to upgrade Firmware, after finish upgrading, system will reboot automatically. “Firmware upgrade” function is available after v1.3.3b11540 Time setting Set the system clock Set system clock manually User can set system clock manually. (format: MMDDhhmmYYYY) Synchronize system clock to Network Time Protocol (NTP) ...
-
Page 24: Broadcast
Access Log Shows the web access log from GUI/CGI command. Broadcast 3.3.1 Wowza Live VEGA-2002 support Wowza live streaming protocol. User can fill parameters to setup streaming to your targeted Wowza streaming service. Here are the descriptions for each field, Field Description URL of server... -
Page 25: Espxmedia
3.3.2 ESPxMedia VEGA-2002 support ESPxMedia live streaming protocol. User can fill parametersto link ESPxMedia streaming service. User can press Authorize to start authorization of the username/email and password first, then press Submit to start sending chosen encoding configuration in Output to viewport to ESPxMedia service. -
Page 26: Stream Settings Page
Stream Settings Page Use this Stream page to set the encoding setting (Preset and Customize) and proto- cols (Protocol 1, Protocol 2 and Protocol 3) for output Channel1/ Channel2. Each Channel has only one Preset/Customize setting and there are up to three protocols in each channels, this means that one encoding setting can be transmitted by 3 differ- ent protocols. -
Page 27: Customize - Video Setting
3.4.1 Customize - Video Setting This menu provide alternative encoding setting, if the pre-defined setting in preset menu is unable to meet user’s requirement, the Customize setting have the individual options for detailed parameters. Field Description List of customized settings, those Profile name specified by user Profile list will be listed here. -
Page 28: Protocol
3.4.2 Protocol 3.4.2.1 HLS Protocol This module either provide HLS streaming as server with limited connections or have the ability to upload segmented stream to another HLS streaming server. Field Description Set the target segment length in seconds. Default value is 10. Seg- HLS - Duration ment will be cut on the next key frame after this time has passed. - Page 29 3.4.2.2 RTP Protocol VEGA-2002 provides End-to-End transport via RTP protocol which is used to trans- port media data over UDP. Once the setting is submitted, VEGA-2002 will send data to the target device. Field Description RTP – IP Target IP address. MPEG-2 TS Output segment files in MPEG-2 Transport Stream format.
- Page 30 3.4.2.3 SRT Protocol VEGA-2002 supports SRT streaming to SRT Server, users can use client software to connect to SRT Server to receive VEGA-2002 audio and video data Field Description SRT - URL Specify the URL of SRT server (ex. srt://192.168.0.66:1234) Type of service (0 ~ 255).
- Page 31 3.4.2.5 ZIXI Protocol VEGA-2002 provides ZIXI protocol which is a software-based platform enabling reli- able transmission of broadcast-quality HD video globally over unmanaged internet connections and private IP networks. Field Description ZIXI – Stream ID Specify the unique stream ID for this ZIXI stream. ZIXI –...
-
Page 32: Video/Audio
Video/Audio Use this Video/Audio page to set the video and audio details for the active stream Video Input Select User can set either SDI or HDMI inputs for Video Stream. Audio Stream Input Select User can set either SDI/HDMI or External Audio Jack inputs for Audio Stream. Sample Rate ... -
Page 33: Network Settings
Network settings Use the Network page to do the setting of Network. Status Show the Network status including MAC Address, Ethernet Status, Auto-MDI/MDIX, IP Address, Subnet Mask, Default Gateway, LinkLocal IP address, Primary DNS Server and Secondary DNS Server. IPv4 Setting To get IP settings automatically, please check the DHCP to obtain the IP ... -
Page 34: Record Settings
Record settings Use this Record page to record for Channel1/ Channel 2 Record Channel The default video setting is Channel 1(H265) / Channel 2(Off). Storage Path You can insert USB flash drive and press the “Reload page” button. It will show the information of the storage. -
Page 35: Osd (Under Development)
OSD (Under Development) Use this OSD page to set OSD in streaming of Channel 1. Check the OSD Enable to upload OSD file and set the position of OSD. Note! OSD file only support *.bmp 24/32 bit and maximum size of OSD file is VEGA-2002 User Manual... - Page 36 VEGA-2002 User Manual...
-
Page 37: Chapter 4 How To Stream
Chapter How to stream... -
Page 38: Rtsp/Rtp
RTSP/RTP Please make sure that SDI or HDMI cable is connected to VEGA-2002 correctly before starting, RTSP streaming will execute automatically. This section shows how to open RTSP streaming from VLC on a suitable player. Open Network Stream from VideoLAN VLC media player. Use this URL to open RTSP video, Launch VLC program for streaming video/ audio. - Page 39 This section shows how to open RTP streaming from VLC on a suitable player. Setup RTP on stream page of VEGA-2002 by using WebGUI. Use this URL to open RTP video, Launch VLC program for streaming video/ audio. rtp://@RTP-IP:port VEGA-2002 User Manual...
-
Page 40: Mpeg-Ts
MPEG-TS This section shows how to play MPEG-TS from VLC player. Please make sure that SDI or HDMI is connected to VEGA-2002 correctly before starting. Setup TS–Protocol ( UDP ), on stream page of VEGA-2002 by using WebGUI. Launch VLC program for UDP streaming video/audio. udp://TS-IP:TS-Port VEGA-2002 User Manual... - Page 41 Setup TS–Protocol ( TCP ), on stream page of VEGA-2002 by using WebGUI. Launch VLC program for TCP streaming video/audio. tcp://TS-IP:TS-Port?listen Note! “TS-IP” stands for PC IP. Multicast UDP streaming Address : 224.0.0.0 to 239.255.255.255. Please change Network setting to DHCP for Multicast stream. VEGA-2002 User Manual...
-
Page 42: Rtmp
RTMP This section shows how to play stream your video using RTMP as the steaming pro- tocol to the YouTube and Facebook. Please make sure that SDI or HDMI is con- nected to VEGA-2002 correctly before starting. Note! HEVC is not supported in flv. Only H.264 is supported. Youtube (1).YouTube Dashboard https://www.youtube.com/live_dashboard (2).You will get the Server URL: “rtmp://a.rtmp.youtube.com/live2”... -
Page 43: Http Live Streaming
HTTP Live Streaming HTTP Live Streaming (HLS) is an HTTP-based media streaming communications protocol implemented by Apple Inc. as part of its QuickTime, Safari, OS X, and iOS software. It operates by breaking the overall stream into a sequence of small HTTP- based file downloads, each download loading one short chunk of an overall poten- tially unbounded transport stream. -
Page 44: Zixi Live Streaming
Zixi Live Streaming If Use VLC as receiver, please refer to the notes to Installing the VLC Player. Run VLC and open the ‘Media’ menu. Select ‘Stream’ to open launch the ‘Open Media’ window Select ‘Network’, fill in ‘zixi://demo.zixi.com/demo’ as ZIXI host URL. Note! Users can follow Zixi VLC Plugin Setup Guide for Installation and ... -
Page 45: Appendix A Hardware/Software Support List
Appendix Hardware/Software Support List... -
Page 46: Vega2002 Video Encoding Performance
VEGA2002 Video Encoding Performance This section described the overall encoding performance limitation VEGA-2002 have. Each table shows maximum bitrate, encoding resolution and number of streaming outputs in different input resolution. These tables are evaluated and tested by Advan- tech, please follow these tables to configure your VEGA-2002. User could also use our Dashboard, Stream ->... - Page 47 VEGA-2002 User Manual...
- Page 48 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2021...
