Advantech VEGA-2001 Quick Start Manual

Advantech VEGA-2001 Quick Start Manual

4k hevc/h.264 real-time encoder box with 12g-sdi/hdmi
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
4K HEVC/H.264 Real-time Encoder
Box with 12G-SDI/HDMI
Author:
Status:
Document ID:
History
Version
0.1
0.2
0.3
0.4
Approved by
Date
VEGA-2001
Quick Start Manual
Thomas Lien (PM)
Version 0.4
Date
Software version
2017.08.01
2018.01.12
V1.0.6b10148
2018.01.25
V1.07b10255
2018.05.24
V1.1.0b11046
Page
Handled by
v1.0
Chiming.Lin
Alex Yu
Alex Yu
Thomas Lien
Approve
1
of
27
Comments

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEGA-2001 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech VEGA-2001

Summary of Contents for Advantech VEGA-2001

  • Page 1 VEGA-2001 4K HEVC/H.264 Real-time Encoder Box with 12G-SDI/HDMI Quick Start Manual Author: Thomas Lien (PM) Status: Version 0.4 Document ID: History Version Date Software version Handled by Comments 2017.08.01 v1.0 Chiming.Lin 2018.01.12 V1.0.6b10148 Alex Yu 2018.01.25 V1.07b10255 Alex Yu 2018.05.24 V1.1.0b11046...

  • Page 2: Table Of Contents

    ODULE CROSS IRED ETWORK SING THE ROWSER ............................9 PGRADING IRMWARE ......................10 IDEO OURCE ONNECTION 3. VEGA-2001 WEB GUI ................11 ..............................11 YSTEM ................................13 ROADCAST ............................. 14 TREAM ETTINGS ............................... 16 IDEO UDIO ............................17 ETWORK SETTINGS ...............................

  • Page 3: Product Introduction

    Ambarella’s H1 processor. The encoded video content can be streamed to the cloud server with several protocols such as RTSP, RTMP or even HLS. The VEGA-2001 can create multiple output streams from a single video input and encode it individually by using different codecs with different resolutions.

  • Page 4: Product Specifications

    Product Specifications 4-ch HEVC 4Kp30 encode 4-ch AVC 4Kp60 encode 1-ch SDI-12G & HDMI video inputs One audio phone jack input Features One USB 2.0 Type-A connector One gigabit Ethernet RJ-45 connector One SD Card connector Hardware One mini-USB console port Onboard 1GB DDR3 memory Form-factor Small form-factor (90x100 mm)

  • Page 5: Vega-2001 Provide Web Gui To Control Encode, Stream, Record And Other Parameters. Below Is Software Architecture For Reference

    Software Architecture VEGA-2001 provide Web GUI to control encode, stream, record and other parameters. Below is software architecture for reference. Module Board Dimension ⚫ Encoder Board of VEGA-2001 Page...
  • Page 6 ⚫ IO board of VEGA-2001 Page...

  • Page 7: Installing Vega-2001

    Installing VEGA-2001 Page...
  • Page 8 Following these steps below: Connect a video source to SDI or HDMI video inputs. Connect the power adaptor to power jack.(When power on ,the power LED is Blue) Connect the LAN cable to the Internet HUB. Please make sure your PC’s LAN cable is also connected to the HUB as well.(If you want your PC serves as a decoder) Connect your USB flash drive to the USB1 or USB2 for the recording function.

  • Page 9: Accessing The Module Across Wired Network Using The Web Browser

    2. Download or get firmware file from your Advantech contact. 3. Put firmware file, “vega2001_XXXX.upd.xz” to your USB flash drive. 4. Insert your USB flash drive to the VEGA-2001 and remove other devices (LAN & video input source, except the power adaptor) .Then, press the power button 5.

  • Page 10: Led For Video Source Connection

    [NOTE] ⚫ After turning on the power of VEGA-2001, if you insert the USB with the firmware file within 40 seconds, VEGA-2001 will execute the update firmware. After finishing the firmware update, VEGA-2001 will be powered off. 2.3 LED for Video Source Connection There are two LED which can indicate connection status of video source.

  • Page 11: Vega-2001 Web Gui

    VEGA-2001 Web GUI 3.1 System Page The System page shows the Information, Initialize, Time setting, System Log and Access Log Information Information includes Model Name, Serial Number and Software Version Initialize It provide option to restore factory default or backup setting to system and upgrade system firmware.
  • Page 12 Time setting Set the system clock ⚫ Set system clock manually User can set system clock manually. ( format: MMDDhhmmYYYY) ⚫ Synchronize system clock to Network Time Protocol (NTP) Check the NTP to set NTP Server and Time Zone. System Log Show /var/log/messages Access Log Page...

  • Page 13: Broadcast

    3.2 Broadcast VEGA-2001 support Wowza live streaming protocol. User can fill parameter to link Wowza streaming service. URL of server The URL of Wowza media server. Port Video streaming port number. User name Set the username. Password Set the password.

  • Page 14: Stream Settings Page

    3.3 Stream Settings Page Use this Stream page to set the items for the output Channel1/ Channel2/ Channel3 (Channel 2 &Channel3 are under development). The capabilities of each stream depend on the input resolution and the frame rate, please refer to the Appendix A for details Preset The preset menu provides basic settings.
  • Page 15 Encoding Select H.265, H.264 or off. Note that Channel 1 cannot be turned off. ⚫ Resolution Select the resolutions of encoded output stream. The VEGA-2001 will be scaled according to the setting. ⚫ Frame rate Set the frame rate of the output stream.

  • Page 16: Video/Audio

    3.4 Video/Audio Use this Video/Audio page to set the video and audio details for the active stream Video ⚫ Input Select User can set either SDI or HDMI inputs for Video Stream. Audio Stream ⚫ Input Select User can set either SDI/HDMI or External Audio Jack inputs for Audio Stream. ⚫...

  • Page 17: Network Settings

    3.5 Network settings Use the Network page to do the setting of Network. Status Show the Network status including MAC Address, Ethernet Status, Auto-MDI/MDIX, IP Address, Subnet Mask, Default Gateway, LinkLocal IP address, Primary DNS Server and Secondary DNS Server. IPv4 Setting ⚫...

  • Page 18: Record Settings

    3.6 Record settings Use this Record page to record for Channel1/ Channel 2/ Channel 3. ⚫ Record Channel The default video setting is Channel 1(H265) / Channel 2(Off) / Channel 3(Off). ⚫ Storage Path You can insert USB flash drive and press the “Reload page” button. It will show the information of the storage.

  • Page 19: Live Page

    3.7 Live Page Live page display current screen from video source. It can be selected to get video source from SDI or HDMI. [NOTE] ⚫ Live page has no screen output while resolution of video source is 3840x2160. It’s limitation from Encode IC.
  • Page 20 Check the OSD Enable to upload OSD file and set the position of OSD. [NOTE] OSD file only support *.bmp and maximum size of OSD file is 5M. Page...

  • Page 21: How To Stream

    4.1 RTSP/RTP This section shows how to open RTSP streaming from VLC on a suitable player. Please make sure that SDI or HDMI cable is connected to VEGA-2001 correctly before starting. 1. Open Network Stream from VideoLAN VLC media player 2.

  • Page 22: Mpeg-Ts

    (2) Uncompressing the file and put it into a property file path. (3) Set the system environment. 2. Set TS–Protocol ,TS–IP and TS–Port on stream page of VEGA-2001 by using WebGUI. 3. If TS–Protocol set as TCP, execute “FFplay -i tcp://TS-IP:TS-Port?listen” in Windows command line.

  • Page 23: Rtmp

    DHCP for Multicast stream. 4.3 RTMP This section shows how to play stream your video using RTMP as the steaming protocol to the Youtube and Facebook. Please make sure that SDI or HDMI is connected to VEGA-2001 correctly before starting. [NOTE] ⚫...

  • Page 24: Http Live Streaming

    (4) You will get the Server URL : “rtmp://rtmp-api.facebook.com:80/rtmp/” and Stream name/key : “xxxxxxxxxxxxxxxxx?ds=1&a=xxxxxxxxxxxxxxxx” (5) Fill in the corresponding RTMP Key and RTMP URL on stream page of VEGA-2001 WebGUI (6) Click the Submit button (7) You can start streaming your video to the Facebook Live.

  • Page 25: Appendix A: Hardware/Software Support List

    Appendix A: Hardware/Software Support List A1. Hardware support list Input selection mode Status A103 Board HDMI Supported 12G SDI Supported 3G SDI Supported X(Under development) Audio phone jack Supported X(Under development) A2. VEGA2001 Video Encoding Performance ◎ Input source：4Kp 60 Channel1 ( H265 ) : 20M Channel2 ( H265 ) :3M Channel3 ( H265 ) : 1.5M...
  • Page 26 3 streaming 1280x720 (60fps) 1280x720 (30fps) 720x480 (30fps) ◎ Input source：720p 50 Channel1 ( H265 ) : 6M Channel2 ( H265 ) :3M Channel3 ( H265 ) : 1.5M 1 streaming 1280x720 (50fps) 2 streaming 1280x720 (50fps) 1280x720 (50fps) 3 streaming 1280x720 (30fps) 1280x720 (30fps) 720x480 (30fps)

  • Page 27: A3. Copyright

    The documentation and the software included with this product are copyrighted 2018 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
