RF825-AP Cabling

Follow the cabling procedures for RF825, and then attach the wireless antenna. See the Back Panel section
earlier in this chapter for the location of the antenna connector.
Note: The antenna must be attached in order for the RouteFinder to be operational.
Antenna
Note: Units shipped with the universal AC power supply are not suited for installation in hazardous
locations.
Multi-Tech Systems, Inc. RouteFinder RF825/RF825-AP User Guide (Document Number S000422B)
Power Supply Cable
This part of the power supply
cable varies by the region of the
world to which the product is
shipped: NAM / EU / GB / IE
Chapter 2 – Cabling the RouteFinder
Ethernet Cable
