RouteFinder MTASR3 Quick Start Guide

Cabling your RouteFinder

Cabling your RouteFinder involves making the proper Ethernet,

WAN, Command Port, and Power connections. Figure 4 shows

the back panel connectors and the associated cable connections.

Table 2 details the procedures for connecting the cables to your

RouteFinder.

COMMAND PORT

LINK 3 RS232/V.35

ETHERNET

LINK 2 RS232/V.35

LINK 1 RS232/V.35

POWER

10BASE T

AUI

Power Connection

Ethernet Connection

T1 CSU/DSU or Comparable

Command Port Connection

Link Device

Figure 4. Cable Connections
