PREPARING THE GRAPHICS CARD

STEP 1

First, remove eight (8) screws from the backside of the Stock cooler

(using Phillips head screwdriver).

STEP 1

STEP 2

Unscrew three (3) screws from the I/O Bracket (using Phillips head

screwdriver). Unplug the connectors in order to remove the stock

cover from the GPU PCB.

STEP 2

- 8 -

Important! Before starting, make sure to have a clean, flat

surface to work on. It is recommended to put foam or soft

material to lay the graphics card on.
