ATTACHING THE WATER BLOCK (Option 2: GeForce RTX 4090 TUF)

Screws must be present in the places marked on the picture.

STEP 2

STEP 1

Carefully position the water block with preinstalled standoffs on the

graphics card. During this process, make sure you have aligned the

mounting holes of the PCB with the holes of the water block.

STEP 1

- 14 -

Pay attention not to use too much force when pressing

the block down to the PCB since chip dies are prone

to cracking.

Before attaching the PCB to the Water Block, make sure

all the Thermal Pads are placed correctly!
