- Page 1 SCT-1027 CAMERA CONTROL CODE TRANSLATOR KALATEL RS-422 TO PELCO RS-422 Ver 1.3 www.sennetech.net Sennetech, Inc. 6455 W. Bath Rd. Perry, MI 48872 U.S.A. Ph (517) 675-1150 Fax(517) 675-1151 SCT-1027 Ver 1.3...
-
Page 2: Product Description
PRODUCT DESCRIPTION The SCT-1027 is a Kalatel to Pelco control code translator designed to permit control of Pelco cameras from Kalatel controllers. It receives Kalatel RS-422 commands and re-transmits them as Pelco RS-422 commands. There are four independent Pelco outputs. -
Page 3: Installation
TX+ and TX- connections are not used. To install the case on the rack mount frame, remove the front panel and the plastic bezel. The rack mount frame takes the place of the bezel as shown below. SCT-1027 Ver 1.3... -
Page 4: Setting The Switches
SETTING THE SWITCHES Both Kalatel and Pelco have multiple code types and baud rates. The code translator must be configured to match the codes. To set the configuration switches, remove the back panel which is secured by two screws. Then slide the cover back to expose the switches. Set the selected switch to either ON or OFF. - Page 5 (For Pelco receivers that can't have addresses above 32 if configured for "P"code) GROUP 1 GROUP 2 GROUP 3 GROUP 4 GROUP 8 GROUP 5 GROUP 6 GROUP 7 PELCO PELCO PELCO PELCO PELCO PELCO PELCO PELCO SCT-1027 Ver 1.3...
-
Page 6: Operation
OPERATION Pan, tilt, zoom, focus, iris commands and presets 1 thru 16 are converted directly. For other commands, refer to the diagram for your controller type. For KTD-405 controllers use [Find] key instead of [Set] key to recall presets, use [Store] key to program presets, and press and hold [Tour] for Autopan. - Page 7 #01, use the supervisor's programming menu. Press and hold the return arrow key until you are prompted for a programming code. Enter [1][4][7][6][Seq] to access the menu and advance through the menu to "Lowest user prgmd preset", enter 001, then hold [Seq] down for three seconds to exit. SCT-1027 Ver 1.3...
- Page 8 KTD-301 NORMAL KEYBOARD OPERATION ALARM ACTIVATE STOP ACTIVATE FRAME PATTERN RANDOM SCAN RECORDING SCAN DECREASE INCREASE IRIS IRIS AUTO PAN PAN / TILT PAN / TILT OPEN CLOSE SPEED SPEED ZOOM ZOOM FOCUS FOCUS NEAR [Alarm] [Set] [#0] [Set] [#1] Run pattern 1 [Alarm] [Set] [#0] [Set] [#2] Run pattern 2...
- Page 9 [Alarm] [Set] [#08] [Zoom In] Set manual pan left limit [Alarm] [Set] [#08] [Zoom Out] Set manual pan right limit [Alarm] [Set] [#08] [Focus Near] Set auto pan left limit [Alarm] [Set] [#08] [Focus Far] Set auto pan right limit SCT-1027 Ver 1.3...
- Page 10 August 2005 SCT-1027 Ver 1.3...
