- Page 1 SCT-1045 CAMERA CONTROL CODE TRANSLATOR VICON RS-422 to VCL RS-485 Ver. 1.2 www.sennetech.net Sennetech, Inc. 6455 W. Bath Rd. Perry, MI 48872 U.S.A. Ph (517) 675-1150 Fax (517) 675-1151 SCT-1045 Ver. 1.2...
- Page 3 PRODUCT DESCRIPTION The SCT-1045 is a Vicon to VCL control code translator designed to permit control of cameras using VCL code from Vicon VPS series controllers. It receives Vicon RS-422 commands and transmits the appropriate commands in VCL RS-485 code format. There are four independent RS- 485 outputs.
- Page 4 To set the configuration switches, remove the back panel, which is secured by two screws. Then slide the cover back to expose the switches. The switches can be changed while the code trans- lator is powered up and the new settings will take effect immediately. SENNETECH 55-9702 High Address...
- Page 5 CAMERA ADDRESS SWITCH SETTING CHART -OFF SCT-1045 Ver. 1.2...
- Page 6 INSTALLATION REAR PANEL VICON VICON VCL DATA OUTPUTS POWER CMD IN RSP OUT 9V to 15V AC or DC Connect Connect output(s) to Connect Connect to to Vicon to power Vicon rcvr VCL camera inputs. command response supply data line out line in (if needed) FRONT PANEL...
- Page 7 [L/S] Auto Focus On [Aux1] Pan 180 Degrees [Aux2] Washer On [Aux3] Washer Off [Aux4] Wiper On [Aux5] Wiper Off [Aux6] Manual Change Over Presets Run PP 1~99 Seek Preset 1~99 Pgm PP 1~99 Define Preset 1~99 SCT-1045 Ver. 1.2...
- Page 8 December 2008 SCT-1045 Ver. 1.2...
