- Page 1 SCT-1047 CAMERA CONTROL CODE TRANSLATOR PELCO RS-422 to JAVELIN RS-232 Ver. 1.0 www.sennetech.net Sennetech, Inc. 6455 W. Bath Rd. Perry, MI 48872 U.S.A. Ph (517) 675-1150 Fax (517) 675-1151 SCT-1047 Ver. 1.0...
- Page 3 PRODUCT DESCRIPTION The SCT-1047 is a Pelco to Javelin control code translator designed to permit control of Javelin cameras from Pelco controllers. It receives Pelco RS-422 commands and transmits the appropri- ate commands in Javelin RS-232 format (9600 baud N81). There are four independent Javelin outputs.
- Page 4 SETTING THE SWITCHES To set the configuration switches, remove the back panel, which is secured by two screws. Then slide the cover back to expose the SENNETECH 55-9702 switches. The switches can be changed while the code translator is powered up and the new settings will take effect immediately.
- Page 5 If connecting to a J0310 SDU SCT-1047 Tx ------------------ pin 2 Com --------------- pin 5 If connecting to a Javelin Remote Receiver for control of JO208 ACUs via a JO107 multiplexer SCT-1047 RCVR Tx ------------------ pin 2 Com --------------- pin 7 SCT-1047 Ver. 1.0...
- Page 7 There are six Javelin "F" or "R" commands that can be used to control relays. Pelco Aux commands are converted to these commands. 1 On 2 On 3 On 4 On 5 On R5 or Auto Scan 6 On R6 or Random Scan SCT-1047 Ver. 1.0...
- Page 8 January 2006 SCT-1047 Ver. 1.0...
