- Page 1 SCT-1024 CAMERA CONTROL CODE TRANSLATOR PELCO RS-422 to VICON RS-422 Ver. 2.3 www.sennetech.net Sennetech, Inc. 6455 W. Bath Rd. Perry, MI 48872 U.S.A. Ph (517) 675-1150 Fax (517) 675-1151 SCT-1024 Ver. 2.3...
- Page 3 PRODUCT DESCRIPTION The SCT-1024 is a Pelco to Vicon control code translator designed to permit control of Vicon cameras from Pelco controllers. It receives Pelco RS-422 commands and re-transmits them as Vicon RS-422 commands. There are four independent Vicon outputs.
- Page 4 To access the configuration switches, remove the back panel, which is secured by two screws. Then slide cover back to expose the switches. The switches can be changed while the SENNETECH 55-9702 code translator is powered up and the new settings will take effect immediately.
- Page 5 Pelco "P" Code Address Conversion Chart for Groups of 32 GROUP2 GROUP1 GROUP3 GROUP4 GROUP5 GROUP6 GROUP7 GROUP8 VICON# VICON# VICON# VICON# VICON# VICON# VICON# VICON# PELCO# SCT-1024 Ver. 2.3...
- Page 6 INSTALLATION FRONT PANEL Power CODE TRANSLATOR Pelco Power Vicon indicator receive transmit indicator indicator BACK PANEL POWER PELCO VICON DATA OUTPUTS 9V to 15V AC or DC Connect to Connect output(s) to Connect Pelco RS-422 Vicon receiver com- to power data line mand data inputs.
- Page 7 (After sending this command, deflect the joystick in a pan direction. This will activate autopan and the speed will change with joystick deflection. When the desired autopan speed is reached, press any lens key. Then release the joystick and the dome will continue to autopan at that speed.) SCT-1024 Ver. 2.3...
- Page 8 July 2006 SCT-1024 Ver. 2.3...
