- Page 1 SCT-1066 CAMERA CONTROL CODE TRANSLATOR AD MANCHESTER to KALATEL RS-422 Ver. 1.0 www.sennetech.net Sennetech, Inc. 6455 W. Bath Rd. Perry, MI 48872 U.S.A. Ph (517) 675-1150 Fax (517) 675-1151 SCT-1066 Ver. 1.0...
- Page 2 PRODUCT DESCRIPTION The SCT-1066 is an American Dynamics to Kalatel control code translator designed to permit control of Kalatel cameras from AD controllers. It receives AD manchester format commands and transmits the appropriate commands in Kalatel RS-422 format. There are four independent Kalatel RS-422 outputs.
- Page 3 SW3-1 KALATEL CODE ON: Digiplex II OFF: Digiplex III (Default) SW3-2 KALATEL BAUD KALATEL XMTR ON: 2400 OFF: 4800/4167 (Default) AD RECEIVER SW3-4 ADDRESS OFFSET ON: ENABLED OFF: DISABLED (Default) LED1 LED2 LED3 SCT-1066 Ver. 1.0...
- Page 4 INSTALLATION FRONT PANEL Power CODE TRANSLATOR Power Kalatel indicator receive transmit indicator indicator REAR PANEL POWER KALATEL DATA OUTPUTS INPUT 9V to 15V AC or DC B W S A B S A B S A B S A B S Connect output(s) to Power Kalatel receiver RS-...
- Page 5 Activate Preset Tour 4 Call Shot 70 Auto Pan Call Shot 71 Auto Focus 1 Off Rcvr Off 1 On Rcvr On 2 Off Door 1 Open 2 On Door 2 Open 3 Off Face Video 3 On Badge Video SCT-1066 Ver. 1.0...
- Page 6 October 2006 SCT-1066 Ver. 1.0...
