- Page 1 SCT-1041 CAMERA CONTROL CODE TRANSLATOR VICON RS-422 TO DIAMOND RS-422 Ver. 1.2 www.sennetech.net Sennetech, Inc. 6455 W. Bath Rd. Perry, MI 48872 U.S.A. Ph (517) 675-1150 Fax (517) 675-1151 SCT-1041 Ver. 1.2...
-
Page 3: Product Description
PRODUCT DESCRIPTION The SCT-1041 is a Vicon to Diamond Electronics control code translator designed to permit control of Diamond cameras from Vicon controllers. It receives Vicon RS-422 commands and transmits the appropriate commands in Diamond Electronics RS-422 format. There are four inde- pendent Diamond outputs. -
Page 4: Setting The Switches
Some Diamond receivers require the auto iris status bits to be sent continuously along with the pan, tilt, zoom, and focus. If this switch is ON, the operator can change the SENNETECH global setting for the code translator. 55-9702 1 2 3 4... - Page 5 CAMERA ADDRESS SWITCH SETTING CHART -OFF SCT-1041 Ver. 1.2...
-
Page 6: Installation
INSTALLATION REAR PANEL VICON VICON POWER DIAMOND DATA OUTPUTS CMD IN RSP OUT 9V to 15V AC or DC Power Diamond Vicon Vicon input RS-422 outputs Data input Rsp output The output baud rate is 9600. Connect to the cmd data Connect to the response Connect to the Diamond receiver lines from the Vicon... -
Page 7: Operation
The Vicon [Aux] keys are converted according to the following table. Vicon Vicon Diamond Diamond Command Command Command Command [Aux4] [Aux1] Aux 1 Off Aux 1 On [Aux5] [Aux2] Aux 2 Off Aux 2 On [Aux3] Aux 3 Off [Aux6] Aux 3 On SCT-1041 Ver. 1.2... - Page 8 OPERATION WITH SW3-4 OFF If SW3-4 is OFF, Pre-positions [1~69] are converted directly to the equivalent Diamond com- mands. Higher Pre-positions are converted according to the following table. Vicon Diamond Vicon Diamond Store # Recall # Command Command [70] to [85] Run Vectorscan 0 to 15 [94] [94]...
-
Page 9: Ascii Conversion Table
If the on-screen menu does not give a number or letter option to finish, use the Diamond escape code [L/S] [Recall 1]. When the menu gives "Enter" as an option, that is the computer "Enter" key, [L/S] [Recall 20] on the Vicon controller, not the Vicon controller [Enter] key. SCT-1041 Ver. 1.2... - Page 10 December 2008 SCT-1041 Ver. 1.2...
