Sennetech SCT-CTX-Pelco-Panasonic v20 Quick User Manual

Pelco RS-422 to Panasonic coax Code Translator ver 2.0
The Code Translator receives Pelco RS-422 camera control code and converts it into Panasonic
up-the-coax code for a single Panasonic camera.
The removable mounting
clip can be snapped onto a
din rail or screwed to a
panel or wall.
Camera
Size: 5" x 3.5" x 1.25" Weight: 0.5 lb Power: 9Volt to 15Volt AC or DC at 75ma Environmental: Indoor use only
Sennetech, Inc. 6455 W. Bath Rd. Perry, MI 48872 U.S.A.
SCT-CTX-Pelco-Panasonic v20
Pelco
Rx
Address Switches Indicator
The range is 1~256 Flashes when
any data is de-
An invalid setting will
tected on the
cause the Error in- input.
dicator to light up
solidly.
n.c.
Pwr Pwr
+ _
Removable edge connector.
Insert a small screwdriver in
RS-422
the upper slot to force open the
Data In
wire clamp. Push all the way in
to open fully. Place stripped
wire end(s) in the open clamp
Connect power to the Pwr
and withdraw screwdriver.
inputs. Do not connect
power wires to the Gnd.
Video
RS-422 IN
P w r
SPECIFICATIONS
www.sennetech.net
Tx Error
Indicator Indicator
Flashes when Flashes for Illuminates
coaxitron data input code er- when video
is sent up the rors. Lights sync signal
video coaxial solidly for any is detected.
cable. invalid ad-
dress switch
setting.
SCT-CTX
Video
Video
Ph (517) 675 1150
Configuration Switches
Switch 1: Unassigned
Up:
Down:
Switches 2&3: Input baud rate
2 Down 3 Down
2 Up 3 Down
2 Down 3 Up
2 Up 3 Up
Switch 4: Input parity
Video Up: Even parity
Indicator
Down: No parity
Switch 5: Panasonic Code
Up: Old Two Speed Code
Down: New One Way Code
Switch 6: Coax Test Mode
Up: Test Mode On
Down: Test Mode Off
High impedance looping
coaxial video connectors.
Controller
Matrix
o r
DVR
Video
o r
Video Encoder
RS-422 Control
Fax (517) 675 1151
2400
4800
9600
19.2k
