- Page 1 SCT-1058 CAMERA CONTROL CODE TRANSLATOR VCL RS-485 to VICON RS-422 Ver. 1.0 www.sennetech.net Sennetech, Inc. 6455 W. Bath Rd. Perry, MI 48872 U.S.A. Ph (517) 675-1150 Fax (517) 675-1151 SCT-1058 Ver. 1.0...
- Page 2 PRODUCT DESCRIPTION The SCT-1058 is a VCL to Vicon control code translator designed to permit control of Vicon cameras from VCL controllers. It receives VCL RS-485 commands and converts them to the appropriate Vicon RS-422 commands. There are four independent Vicon outputs.
- Page 3 The switches can be changed while the code trans- lator is powered up and the new settings will take effect immediately. SENNETECH 55-9702 1 2 3 4 SW3-1 VICON BAUD RATE 9600 OFF: 4800 1 2 3 4 5 6 7 8 SCT-1058 Ver. 1.0...
- Page 4 INSTALLATION FRONT PANEL Power CODE TRANSLATOR Power Vicon receive indicator transmit indicator indicator BACK PANEL VICON RS-422 OUTPUTS POWER Diamond INPUT 9V to 15V AC or DC Connect to Connect output(s) Connect to Vicon receiver VCL controller to power output command in [+] supply command in [-].
- Page 5 To bring up the on-screen menu, press the camera setup button 3 times in succession. While the menu is displayed, the following control functions are in effect: Pan & Tilt Move the highlight bar AutoPan or Wiper Select the highlighted item Auto Iris Exit SCT-1058 Ver. 1.0...
- Page 6 September 2005 SCT-1058 Ver. 1.0...
