Thermal Image Scope
HIKMICRO STELLAR Series
User Manual V5.5.54 202212
Contact Us

Advertisement

Table of Contents
loading

Related Manuals for Hikmicro STELLAR Series

Summary of Contents for Hikmicro STELLAR Series

  • Page 1 Thermal Image Scope HIKMICRO STELLAR Series User Manual V5.5.54 202212 Contact Us...

  • Page 2: Table Of Contents

    Thermal Image Scope User Manual Table of Contents Chapter 1 Overview........................1 1.1 Device Description ......................... 1 1.2 Main Function ........................1 1.3 Appearance ..........................1 Chapter 2 Preparation ........................ 3 2.1 Cable Connection ........................3 2.2 Install Battery ........................3 2.2.1 Battery Instruction .....................
  • Page 3 Thermal Image Scope User Manual 4.3 Correct Reticle ........................17 Chapter 5 Measure Distance ..................... 19 Chapter 6 General Settings ....................... 20 6.1 Set OSD ..........................20 6.2 Set Brand Logo ........................20 6.3 Burning Prevention ......................21 6.4 Capture and Video ....................... 21 6.4.1 Capture Picture ......................

  • Page 4: Chapter 1 Overview

    ● Client Software Connection: The device can capture snapshots, record videos, and set parameters by HIKMICRO Sight app after being connected to your phone via hotspot. ● Image Correction: The device supports DPC (Defective Pixel Correction) and FFC (Flat Field Correction) which can optimize the image quality.
  • Page 5 Thermal Image Scope User Manual Table 1-1 Description of Buttons and Components Component Function Lens Cover Protects the lens. Focus Ring Adjusts focus to obtain clear targets. To connect the device to power supply or transmit data Type-C Interface with a type-C cable. Battery For holding the battery.

  • Page 6: Chapter 2 Preparation

    Thermal Image Scope User Manual Chapter 2 Preparation 2.1 Cable Connection Connect the device and power adaptor with a type-C cable to charge the device. Alternatively, connect the device and PC to export files. Figure 2-1 Cable Connection 2.2 Install Battery 2.2.1 Battery Instruction ●...

  • Page 7: Power On/Off

    Thermal Image Scope User Manual Figure 2-2 Loosen the Cover 2. Insert the battery into the battery compartment with the positive mark inward. Figure 2-3 Install the Battery 3. Turn the battery cover clockwise to tighten it. Figure 2-4 Tighten the Cover Note Remove the battery if the device is not used for a long time.

  • Page 8: Menu Description

    In the menu, you can rotate the wheel to select functions, press the wheel to configure the selected function, and hold the wheel to exit the menu. Figure 2-5 Menu Interface 2.5 Firmware Status 2.5.1 Client Software Connection Connect the device to the HIKMICRO Sight app via hotspot, and then you can capture picture,...

  • Page 9: Check Firmware Status

    ● Hotspot Name: HIK-IPTS Serial No. ● Hotspot Password: Serial No. 4. Search the HIKMICRO Sight app on App Store (iOS System) or Google Play™ (Android System) to download it, or scan the QR code to download and install the app.

  • Page 10: Upgrade Device

    2.5.3 Upgrade Device Upgrade Device via HIKMICRO Sight Before You Start Install HIKMICRO Sight on your phone and connect your device to the app. Steps 1. Tap the device series to enter the device information interface. 2. Tap Device Upgrade to enter the firmware upgrade interface 3.

  • Page 11: Zeroing

    Thermal Image Scope User Manual Steps 1. Connect the device to your PC with cable, and then turn on the device. 2. Open the detected disk, copy the upgrade file and paste it to the root directory of the device. 3.

  • Page 12: Chapter 3 Image Settings

    Thermal Image Scope User Manual Chapter 3 Image Settings 3.1 Adjust Diopter Steps 1. Power on the device. 2. Open the lens cover. 3. Hold the device and make sure the eyepiece covers your eye. 4. Adjust the focus ring until the OSD text or image is clear. Figure 3-1 Adjust Diopter Note When adjusting diopter, DO NOT touch the surface of lens to avoid smearing the lens.

  • Page 13: Adjust Brightness

    Thermal Image Scope User Manual 3.3 Adjust Brightness In the menu mode, rotate the wheel to select and press the wheel to adjust brightness. In white hot mode, the higher the value of brightness is, the brighter the image is. The image effect in white hot mode is showed as picture below and effect in black hot mode is opposite.
  • Page 14 Thermal Image Scope User Manual Black Hot The hot part is black-colored in view. The higher the temperature is, the darker the color is. Red Hot The hot part is red-colored in view. The higher the temperature is, the redder the color is. Fusion From high temperature to low temperature, the image is colored in from white, yellow, red, pink to purple.

  • Page 15: Correct Defective Pixel

    Thermal Image Scope User Manual 3.7 Correct Defective Pixel The device can correct the defective pixels on the screen. Steps 1. Hold the wheel to show the menu. 2. Rotate the wheel to select , and press the wheel to enter the DPC setting interface. 3.

  • Page 16: Flat Field Correction

    Thermal Image Scope User Manual and the menu at the upper left can be mirrored to the upper right of the interface. Figure 3-5 Mirror Effect 3.8 Flat Field Correction This function can correct non-uniformity of display. Steps 1. Hold the wheel to enter the menu. 2.

  • Page 17: Adjust Digital Zoom

    Thermal Image Scope User Manual Figure 3-6 Set Picture in Picture Mode Note ● When reticle is enabled, the PIP view is the detail of reticle. When reticle is not enabled, the PIP view is the detail of central part. ●...

  • Page 18: Chapter 4 Zeroing

    Thermal Image Scope User Manual Chapter 4 Zeroing 4.1 Select Reticle Group If different users use the same device, the users can configure and save the reticle settings in their respective reticle group. Steps 1. In the live view mode, hold the wheel to show the menu. 2.
  • Page 19 Thermal Image Scope User Manual position for the reticle. Before You Start Select a reticle group first. Steps 1. In the live view mode, hold the wheel to show the menu. 2. Rotate the wheel to select , and press the wheel to enter the reticle setting interface. 3.

  • Page 20: Correct Reticle

    Thermal Image Scope User Manual Figure 4-2 PIP Effect in Reticle Mode ● In black hot mode, if you set the reticle color as white, the reticle will display black automatically. Figure 4-3 White Reticle in Black Hot Mode 4.3 Correct Reticle Correcting the reticle can help you aim at the target with high accuracy by marking the offset between the big reticle and small reticle.
  • Page 21 Thermal Image Scope User Manual 4. Set the distance to the target. 1) Rotate the wheel to select Distance. 2) Press the wheel to select the number you want to change. 3) Rotate the wheel to change the number. 5. (Optional) Rotate the wheel to select Freeze, and press the wheel to enable the function. Note When enabling the freeze function in reticle, you can adjust the position of the cursor on a frozen image.

  • Page 22: Chapter 5 Measure Distance

    Thermal Image Scope User Manual Chapter 5 Measure Distance The device can detect the distance between the target and the observation position. Before You Start When measuring the distance, keep the hand and the position steady. Otherwise, the accuracy may be affected. Steps 1.

  • Page 23: Chapter 6 General Settings

    Thermal Image Scope User Manual Chapter 6 General Settings You can manually record video or capture picture when displaying live view. 6.1 Set OSD You can choose whether to display the OSD information on the live view mode. Steps 1. Hold the wheel to show the menu. 2.

  • Page 24: Burning Prevention

    Thermal Image Scope User Manual 6.3 Burning Prevention Steps 1. Hold the wheel to show the menu. 2. Rotate the wheel to select , and press the wheel to enable or disable the burn-prevention function. 3. Hold the wheel to save the settings and exit. Note Avoid direct sunlight and enable the Burning Prevention function to reduce the risk of sensor damage from the heat.

  • Page 25: Record Video

    Thermal Image Scope User Manual 6.4.3 Record Video Steps 1. In the live view mode, hold and start recording. Figure 6-2 Start Recording The left top of image displays the information of recording time. 2. Hold again to stop recording. What to do next For exporting recording files, refer to Export Files.

  • Page 26: Hot Tracking

    Thermal Image Scope User Manual 6.5 Hot Tracking The device can detect the highest temperature spot in the scene and mark it on display. Steps 1. Hold the wheel to show the menu. 2. Rotate the wheel to select , and press the wheel to mark the spot of highest temperature. 3.
  • Page 27 ● When you connect the device to PC for the first time, it installs the drive program automatically. ● You can also export files via HIKMICRO Sight. See the user manual of the app for detailed operation.

  • Page 28: Chapter 7 System Settings

    Thermal Image Scope User Manual Chapter 7 System Settings 7.1 Synchronize Time Steps 1. Hold the wheel to show the menu. 2. Rotate the wheel to select , and press the wheel to enter the time setting interface. 3. Press the wheel to switch the time system, and rotate the wheel to select the time and date to be synchronized.

  • Page 29: Restore Device

    Thermal Image Scope User Manual 2. Select , and press the wheel. You can view the device information such as version, and serial 7.5 Restore Device Steps 1. Hold the wheel to show the menu of device. 2. Rotate the wheel to select , and press the wheel to restore the device to defaults according to the prompt.

  • Page 30: Chapter 8 Frequently Asked Questions

    Thermal Image Scope User Manual Chapter 8 Frequently Asked Questions 8.1 Why is the monitor off? Check whether the device is off-battery. Check the monitor after charging the device for 5 minutes. 8.2 The image is not clear, how to adjust it? Adjust the diopter adjustment knob until the image is clear.

  • Page 31: Chapter 9 Appendix

    Chapter 9 Appendix 9.1 Device Command Scan the following QR code to get device common serial port commands. Note that the command list contains the commonly used serial port commands for HIKMICRO thermal cameras. 9.2 Device Communication Matrix Scan the following QR code to get device communication matrix.

  • Page 32: Safety Instruction

    Thermal Image Scope User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. Laws and Regulations ● Use of the product must be in strict compliance with the local electrical safety regulations. Symbol Conventions The symbols that may be found in this document are defined as follows.
  • Page 33 Thermal Image Scope User Manual VDC/2 A and 1600 mAh. Dispose of used batteries in conformance with the instructions provided by the battery manufacturer. ● Use the battery provided by a qualified manufacturer. Refer to the product specification for detailed battery requirements. ●...

  • Page 34: Legal Information

    INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKMICRO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.

  • Page 35: Regulatory Information

    Thermal Image Scope User Manual Regulatory Information These clauses apply only to the products bearing the corresponding mark or information. FCC Information Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 36 Thermal Image Scope User Manual Directive 2012/19/EU (WEEE Directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info.
  • Page 37 Thermal Image Scope User Manual (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. ce matériel est conforme aux limites de dose d'exposition aux rayonnements, CNR-102 énoncée dans un autre environnement.
  • Page 38 Website: www.hikmicrotech.com E-mail: support@hikmicrotech.com UD31318B...
