Field Controls CUV Series Manual page 14

EMT Conduit Magnetic
Mounting Bracket
Figure 13: Single Lamp Support Rod Assembly for Single/Dual Lamp Models (Standard)
EMT Conduit Magnetic
Mounting Bracket
Figure 14: Dual Lamp Support Rod Assembly for Dual Lamp Models (Optional)
OPTIONAL LAMP AND ½" EMT CONDUIT MOUNTING ACCESSORIES:
The following optional mounting accessories are sold separately to assist installation process.
Tri Magnet, Infi nite 180°, Rod Support Bracket, Qty 2
Tri-Foot Magnet, 45° Dual, Rod Support Bracket, Qty 2
Tri-Foot Magnet Base Bracket, Qty 2
Single Magnet, 90° Dual,
Rod Support Bracket, Qty 2
Single Magnet, Lamp Support Bracket, Qty 2
½" Conduit/Lamp Support Bracket, Qty 2
P/N 780108800 Rev A 10/22
(6" Longer than Lamp length)
1/2" EMT Conduit
(6" Longer than Lamp length)
Description
page 14 of 20
1/2" EMT Conduit
Part Number
60261 1304
60261 1302
60261 1303
60261 1301
60261 1305
60261 1306
Inverted U-Shaped
Lamp Bracket
Inverted U-Shaped
Lamp Brackets
