FRONT
EV Charge Controller
for socket 1
(Front Layer)
EV Charge Controller
for socket 2
(Rear Layer)
RCBO – Socket 1
MID Meter –
Socket 1
Incoming Mains
Power Terminals
(Single phase version shown)
EVBM-V01-R1 Installation and Operation Manual
December 2022
Figure 3 Internal Components - Typical Locations
Product Specification
MID Meter –
Socket 2
RCBO – Socket 2
Lighting Head
Switchgear
BasicCharge Intelligent EV Charging Pedestal
REAR
Smart
Communications
Module
RFID Sensor
(Front mounted
on single
socket models)
Page 10 of 36
