Grouser Products AG240 Owner's Manual & Parts Book

Dozer with fh-440 front hitch
Hide thumbs Also See for AG240:

Advertisement

Quick Links

Download this manual
with FH-440 Front Hitch
Owner's Manual & Parts Book
Grouser Products
755 2nd Ave NW - West Fargo, ND 58078
Phone: 1-800-747-6182
Fax: 1-701-282-8131
E-mail: grouser@grouser.com
Website: www.grouser.com
PN: 63-41663
AG240 Dozer
Serial #:10205555-...
Purchase Date
Serial Number
Model Number
Tractor Model
Dealer
Date 4-8-2019

Advertisement

loading
Need help?

Need help?

Do you have a question about the AG240 and is the answer not in the manual?

Questions and answers

Related Manuals for Grouser Products AG240

Summary of Contents for Grouser Products AG240

  • Page 1 AG240 Dozer with FH-440 Front Hitch Owner’s Manual & Parts Book Purchase Date Serial Number Grouser Products 755 2nd Ave NW - West Fargo, ND 58078 Model Number Phone: 1-800-747-6182 Fax: 1-701-282-8131 Tractor Model E-mail: grouser@grouser.com Dealer Website: www.grouser.com PN: 63-41663 Serial #:10205555-...
  • Page 2 Description Page Welcome To The Owner Decals 10’-16’ No Angle-No Tilt Blade Assembly 12’-16’ Hydraulic Angle-Hydraulic Tilt Blade Assembly 10’-16’ Hydraulic Angle-No Tilt Blade Assembly Hydraulic Angle-Hydraulic Tilt or Hydraulic Angle No Tilt System 10-11 12-13 Tractor Side Hydraulics Blade Options 16-17 Replacement Parts HAHT Hydraulic Multi-Coupler Option...
  • Page 3 A careful operator is the best operator. Most accidents can be avoided by observing certain precautions. To help all safety and operational instructions of your tractor manufacturer. The Dozer: 1. The should be operated only by those who are responsible and instructed to do so.
  • Page 4 WARNING INSURE THERE IS ADEQUATE CLEARANCE BETWEEN TIRES AND BACK OF BLADE SYSTEM SEE OWNER’S MANUAL FOR CORRECT EXTENSION TO GAIN ADEQUATE CLEARANCE 27-9503 27-40425 PN: 27-9503 PN: 27-2409 PN: 27-40425 See Page 15 for Extension...
  • Page 5 Due to the harsh environment this equipment operates in, the following tasks should be performed every 10 hours or less . • Inspect all equipment before operation for existing or potential damage. system. • If equipped with hydraulic multi-coupler, see page 19-20 for hydraulic multi-coupler maintenance. •...

  • Page 6: Skid Shoe Adjustment

    To Connect: Note: If necessary, use a spotter to help center the blade on the lift system. 6. Clean and connect hydraulic couplers on the top arm. Refer to Page #13 for proper locations of all functions. To Disconnect: 6. Continue to slowly lower the lift system to disengage the blade. Note: Do not remove all of the bolts at the same time.
  • Page 7 ITEM ITEM ITEM PART NO. DESCRIPTION PART NO. PART NO. DESCRIPTION DESCRIPTION QTY. QTY. QTY. QTY. QTY. QTY. QTY. QTY. QTY. QTY. QTY. QTY. 34-40852 34-40852 Retractable Spring Plunger, 3/8" Retractable Spring Plunger, 3/8" 11-11316 Arm, Blade Stand 15-41950-10 240 2-Way Blade Weld 34-40853 34-40853 Knob, 1-1/2"...
  • Page 8 ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION QTY. QTY. QTY. QTY. QTY. QTY. 34-40852 Retractable Spring Plunger, 3/8" 15-41815-12 240 Blade Weld - 12' 15-41518-14 240 Blade Weld - 14' 34-40853 Knob, 1-1/2" Ball 34-40859 Spring Clip, 1-3/16" 15-41815-16 240 Blade Weld - 16' 16-20560...
  • Page 9 ITEM ITEM NO. PART NO. QTY. DESCRIPTION PART NO. DESCRIPTION QTY. QTY. QTY. QTY. QTY. QTY. QTY. 34-40852 Retractable Spring Plunger, 3/8" 15-40860-10 240 HANT Blade Weld 15-40860-12 240 HANT Blade Weld 34-40853 Knob, 1-1/2" Ball 34-40859 Spring Clip, 1-3/16" 15-40860-14 240 HANT Blade Weld 15-40860-16...
  • Page 10 HAHT HANT Item Part No. Description Qty. Qty. 16-20040 5/16” x 2-1/2” Hex Bolt Gr 5 NC 16-20125 1/2” X 1-1/4” Hex Bolt Gr 5 NC 16-20134 1/2” x 3-1/2” Hex Bolt Gr 5 NC 16-20558 1” x 2” Hex Bolt Gr 8 NC 16-35C612 3/8”...
  • Page 11 DETAIL A...
  • Page 12 DETAIL A...
  • Page 13 Item Qty. Part No. Description 11-19000 FH-440 Lower Arm 11-19010 FH-440 Top Arm 16-20035 5/16” x 1-1/4“ Hex Bolt Gr 5 NC 16-20125 1/2” x 1-1/4“ Hex Bolt Gr 5 NC 16-20424 1/2” x 3-1/2” Hex Bolt Gr 8 NC 19-7954 2.25 x 2.00 x 2.00 Spring Bushing 19-16328...
  • Page 14 ITEM NO. QTY. PART NO. DESCRIPTION 11-16918 Pin Pulling Arm Assembly 16-17266 3/8" x 3/4" Flange Button Socket Cap Bolt 16-20011 1/4" x 2-3/4" Hex Bolt Gr 5 NC 16-21065 3/8" x 1-1/4" Carriage Bolt Gr 5 NC 19-40440 .378” ID x .503” OD x .375” Spacer 34-17799 Latch Spring 39-16931...
  • Page 15 Mounts May Vary Some parts hidden for clarity See Page 21 for hydraulic schematic. HAHT HANT Item Part No. Description Qty. Qty. 16-35C612 3/8” x 3/4” Flanged Bolt 16-20037 5/16” x 1-3/4 “ Hex Bolt Gr 5 NC 18-19311-03-P-087 Hose Clamp (TS-CLH-03-P-087) 18-19312-03 Twin Cover Plate (TS-TCP-03-Z) 18-19313-03...
  • Page 16 240 Box End Plates - 19350-K Item Qty. Part No. Description 16-20219 3/4” x 2-1/4” Hex Bolt Gr 5 NC 44-19350 240 - 1/2” Bent End Plates (Std Straight) 70-20607 3/4” Hex Center Lock Nut Gr 2 NC Top Ext. for Box End Plates - 19351-K Item Qty.
  • Page 17 240 - 1’ End Extension Kit - 17525-1-A Item Qty. Part No. Description 15-17525-1-L 1’ End Extension - Left 15-17525-1-R 1’ End Extension - Right 16-20218 3/4” x 2” Hex Bolt Gr 5 NC 16-21666 5/8” x 1-3/4” Plow Bolt Gr 5 NC 29-7950-1 1’- 5/8”...
  • Page 18 1’ - 5/8” x 6” Cutting Edge w/ Hardware Kit - 7950-1K Item Qty. Part No. Description 16-21666 5/8” x 1-3/4” Plow Bolt Gr 5 NC 29-7950-1 1’- 5/8” x 6” Double Bevel Cutting Edge 70-20646 5/8” Hex Top Lock Nut Gr 5 NC 2’...
  • Page 19 Some parts hidden for clarity Right Angle Extend & Left Angle Retract Red Spiral Band Right Angle Retract & Left Angle Extend Tilt Retract Red Spiral Band Green Spiral Band Tilt Extend Green Spiral Band Item No. Qty. Part No. Description 16-35C616 3/8”...
  • Page 20 Some parts hidden for clarity Right Angle Retract & Left Angle Extend Red Spiral Band Right Angle Extend & Left Angle Retract Red Spiral Band Item No. Qty. Part No. Description 16-812525 8mm x 1.25mm x 25mm Metric Hex Bolt Gr 10.9 18-19011 240 Quick Coupler Mount 25-19657...

  • Page 21: Before Each Use

    Before Each Use: Disconnect the mobile half from the parking station and the cap from the fixed half. Fixed Half Mobile Half Check that there is no contamination (salt, sand, dirt, etc.): On the pins. Inside the cam. In the locking mechanism area. On the face of the plates and couplings.
  • Page 22 Cleaning The Female Bushing: Cleaning The Male Interface Seal Make sure the coupling is securely Make sure the coupling is securely fastened into the plate or place in fastened into the plate or place in a vice. a vice. Using a blunt, non-marring tool, Using a non-marring tool, depress depress the valve face until the seal the outer ring to expose the...
  • Page 23 Tilt Cylinder Angle Cylinder Left Angle Cylinder Right Green Spiral Band Green Spiral Band Red Spiral Band Red Spiral Band & Green Cap & Green Cap & Red Cap & Red Cap Tilt Disconnects Angle Disconnects Green Spiral Band Green Spiral Band Red Spiral Band Red Spiral Band &...

  • Page 24: Warranty

    Contact Us Grouser Products 755 2nd Ave NW - West Fargo, ND 58078 Phone: 1-800-747-6182 Fax: 1-701-282-8131 E-mail: grouser@grouser.com Website: www.grouser.com Improvements the equipment sold previously. Warranty Products shall have no obligation to bear the cost of labor or transportation in connection with replacement or repair of any such defective parts in the setup process.
