- Page 1 3-5 - AG PRO PLUS NANT Owner’s Manual & Parts Book Purchase Date Serial Number Model Number Tractor Model Dealer PN: 63-40427 SN: 10204841-10204966 Date 8-1-2017...
- Page 2 Please have all operators read this manual carefully and keep the manual available for ready reference. If you have any questions or concerns, contact Grouser Products. Maintenance Due to the harsh environment your equipment operates in, the following tasks should be performed every 10 hours or less.
- Page 3 Warning When using the dozer blade, pay special attention to the area between the blade and the hood of the tractor. In the right conditions, material can build up. Grouser Products is not responsible for careless operation of the blade.
- Page 4 Unpacking Components Unstrap and remove the lift frame, hoses, top arms, and any boxes of hardware from the undercarriage. If any components are missing, call Grouser. Undercarriage Installation Install undercarriage per the tractor specific mounting instructions. Assembling Lift Components Some assembly of Lift system components is necessary. Follow the steps listed below. Refer to Page 5 for the correct hardware and orientation of parts.
- Page 5 Detail A: Scale 1:10 * Parts Not Shown Item #A for Claas Tractors (24-19606) Item #B for Steiger (24-19601), New Holland (24-19601), and JD 9R Tractors (24-19602, 24-19603 or 24-19609) Item #C for JD 9RX (24-19608), Versatile (24-19604) and Challenger Tractors (24-19607) QTY.
- Page 6 Hoses Not Drawn To Scale 2,18,21 1,22 Tilt Rod Angle Rod (2-Stick Only) Tilt Base Right Angle Base (2-Stick) or Angle Base (Electric) Left Angle Base (2-Stick) or Angle Rod (Electric) NOTE: 4 Spacers (#18) goes between plate on Top Arm and Coupler Bracket #17.
- Page 7 2,16,17 1,18 Left Rod (Blade Width) Right Base (Blade Width) Right Rod (Blade Width) Left Base (Blade Width) Multi-Coupler is shown on Page 18-19 Item #A & B for Claas Tractors. Item #C for Steiger, New Holland, Claas and JD 9R Tractors All Hoses Should Be Routed Item #D for JD 9RX, Versatile and Challenger Tractors.
- Page 8 Run the blade through all the functions. If any function does not work properly, bleed the air out of the system for that function again. If problem still persists, call Grouser Products. NOTE: If blade does not function to the operator’s liking or preferred direction, swap the couplers at the rear...
- Page 9 Connecting and Disconnecting the Blade To Connect: 1. Lift the locking latch and pull the quick attach lock handle on the left side of the system to open the quick attach system. Refer to Page #13 for further clarification on the quick attach system. 2.
- Page 10 * Part Not Shown ITEM QTY. PART NO. DESCRIPTION 15-18735R2 XAXT Blade Weld 15-18760-L 3-5 Slider End Weld - Left 15-18760-R 3-5 Slider End Weld - Right 16-16305 3/8" x 1.25" Flanged Elevator Bolt 16-18945 1" x 3" Hex Bolt Gr 5 NC - Short Thread 16-20538 7/8"...
- Page 11 ITEM QTY. PART NO. DESCRIPTION 34-17567 Handle, Ratchet Jack 43-18463 1” x 2.75” Pin (S57190400) 43-18943 3/16” x 1-1/2” Cotter Pin 43-7767 Cylinder Pin Clip 44-16401 R1 Plate, Top Cover Right 44-16402 R1 Plate, Top Cover Left 44-16403 Plate, 8" Cover 44-16404 R1 Plate, 10"...
- Page 12 ITEM NO. QTY. PART NO. DESCRIPTION 15-18760-L 3-5 Slider End Weld - Left 15-18760-R 3-5 Slider End Weld - Right 15-18795R2 NANT 3-5 Blade Weld 16-20560 1" x 2-1/2" Gr.8 NC Hex Bolt 16-20561 1" x 2-3/4" Hex Bolt Gr.8 NC 45-14710-L R2 Quick Attach - Female Left 45-14710-R R2 Quick Attach - Female Right 57-20819...
- Page 13 ITEM NO. QTY. PART NO. DESCRIPTION 11-3049R3 Bell Crank 16-20011 1/4" x 2-3/4" Hex Bolt Gr 5 NC 16-20125 1/2" x 1-1/4" Hex Bolt Gr 5 NC 16-20132 1/2" X 3" Hex Bolt Gr. 5 NC 16-21065 3/8" x 1.25 Carriage Bolt Gr 5 NC 18-19362R1 Bolt Bracket, Weld 18-19365...
- Page 14 ITEM ITEM QTY. PART NO. DESCRIPTION QTY. PART NO. DESCRIPTION 35-18938-1060 106" x 3/8" -8JIC x -8JIC Hose w/Cordura 16-20125 1/2" x 1-1/4" Hex Bolt Gr 5 NC 16-20126 1/2" x 1-1/2" Hex Bolt Gr. 5 NC 35-18938-1380 138" x 3/8" -8JIC x -8JIC Hose w/Cordura 43-16306 Cylinder Pin 18-12991...
- Page 15 Left Tilt Left Tilt Left Angle Left Angle Lift Up Lift Down Extend & Retract & Retract & Extend & Right Tilt Right Tilt Right Angle Right Angle Retract Extend Extend Retract Female Quick Connects At Rear Of Tractor...
- Page 16 * Parts Not Shown ITEM NO. QTY. PART NO. DESCRIPTION 16-21064 3/8" x 1" Carriage Bolt Gr 5 NC 44-18995 Ag Pro 3-5M Name Plate 44-15600 Custom Name Plate 70-20622 3/8" Flange Hex Nut Gr 5 NC...
- Page 17 3-5 Blade Cylinders Left Width Cylinder Right Width Cylinder Left Left Right Right Side Side Side Side Retract Extend Extend Retract Female Quick Connects At Rear Of Tractor...
- Page 18 2 Port Multi Coupler - NAHT or HANT Electric 4 Port Multi Coupler -HANT 2-Stick or HAHT Electric 4 Port Multi Coupler -12-20 or 3-5 Sliders...
- Page 19 ITEM HANT 2-Stick or NAHT or 12-20 or 3-5 NO. PART NO. HAHT 2-Stick DESCRIPTION HAHT Electric HANT Electric Blades 16-18957 5/16” x 3-1/4” Allen Head Screw 16-35C612 3/8" x 3/4" Flange Bolt 16-812525 8mm x 1.25mm x 25mm Metric Hex Bolt Gr 10.9 18-18430R1 Quick Coupler Mount 18-18514...
- Page 20 Website: www.grouser.com Improvements Grouser Products Inc. is continually striving to improve its products. We reserve the right to change prices, specification, or equipment at any time without notice. We also reserve the right to make improvements or changes when it becomes practical and possible to do so without incurring any obligation to make changes or additions to the equipment sold previously.
