- Page 1 AG PRO PLUS HD Owner’s Manual & Parts Book Purchase Date Serial Number Model Number Tractor Model Dealer PN: 63-18829 Date 9-25-2015...
- Page 2 Please have all operators read this manual carefully and keep the manual available for ready reference. If you have any questions or concerns, contact Grouser Products. Maintenance Due to the harsh environment many of our equipment operates in, the following tasks should be performed every 10 hours or less.
- Page 3 The Dozer: 1. The Ag Pro Plus HD Dozer should be operated only by those who are responsible and instructed to do so. 2. Read the owner’s manual carefully before using this equipment. Lack of operating knowledge can lead to accidents.
- Page 4 To disconnect the blade, see Page 6. Initial System Startup Start the tractor and run the blade thru all the functions. If any function does not work properly, bleeding of the system may be required. If problem still persists, call Grouser Products.
- Page 5 3/4” Flat Washer 31-6400-10-08 Straight JIC x O-Ring (6400-10-8) 57-20757 3/4” SAE Hardened Flat Washer - 1-1/2” OD 32-19120 Ag Pro Plus HD - Lift Frame 58-9369 Grease Zerk 1/8” NPT Straight 34-12932 Cylinder Saddle (ZR518) 70-20587 3/4” Hex Nut Gr 5 NC...
- Page 6 Connecting and Disconnecting the Blade To connect the blade follow Steps #18-25 on Page 4. To disconnect the blade, set the blade on the ground, unhook all of the couplers on the top arm and pull the 3/4” pin (Part #19 on Page 7) from the mushroom skid shoe link (#34 on Page 7) and store the pin in the empty hole on blade side of the skid shoe mount.
- Page 7 Detail View A * Parts Not Shown Item #A for Custom Name Plate and Item #B for AG Pro Plus Name Plate Refer to Pages 12-13 for Quick Attach System Blade Length 14’ 16’ 18’ Blade Length 14’ 16’ 18’ Item Part No.
- Page 8 Hydraulic Instructions Prior to operating the blade, bleed all air out of the hydraulic system. Start with the furthest location away from the remote until all air is out. Hydraulic Angle System Operating Instructions If your Grouser blade was purchased with the Hydraulic Angle Option, you will have the ability to angle the blade 30 degrees left or right.
- Page 9 If the angle system is not used correctly, frame damage may occur. Some damaged frames can be repaired, please contact Grouser Products for repair instructions if needed. Please contact Grouser Products with any questions by: Phone - 701-282-7710 or 800-747-6182;...
- Page 10 Angle / Tilt Function Abbreviation Key HAHT Hydraulic Angle - Hydraulic Tilt 6-Way HANT Hydraulic Angle - No Tilt 4-Way NAHT No Angle - Hydraulic Tilt 4-Way NANT No Angle - No Tilt 2-Way Item Qty. Part No. Description 16-20077 3/8”...
- Page 11 Item Qty. Part No. Description 16-20128 1/2” x 2” Hex Bolt Gr 5 NC 16-20220 3/4” x 2-1/2” Hex Bolt Gr 5 NC 18-14658 NAXT Center Bracket 19-13515 3/4” ID - Non Rotating Pin Bushing 26-34728 4 x 12 Cylinder w/ Tube Ends 32-17810 HD - NAHT Tilt Frame 43-16116...
- Page 12 Some Parts Hidden For Clarity Item #A for HAHT & HANT and Item #B for NAHT & NANT Item No. Qty. Part No. Description 11-3049 Bell Crank Weld 16-20040 5/16” x 2-1/2” Hex Bolt Gr 5 NC 16-20125 1/2” x 1-1/4” Hex Bolt Gr 5 NC 16-20132 1/2”...
- Page 13 Qty 2.
- Page 14 Item Qty. Part No. Description 11-12397 HD Stabilizer Arm 11-8082 Angle Arm Right 11-9039 Angle Arm Left 14-9366 Non Tilt Bar 16-20036 5/16” x 1-1/2” Hex Bolt Gr 5 NC 16-20132 1/2” x 3” Hex Bolt Gr 5 NC 16-20220 3/4”...
- Page 16 Hoses Not Drawn To Scale...
- Page 17 Configuration HAHT HANT Item No. Part No. Description Qty. Qty. 16-20036 5/16” x 1-1/2” Hex Bolt Gr 5 NC 16-20040 5/16” x 2-1/2” Hex Bolt Gr 5 NC 16-20043 5/16” x 3-1/4” Hex Bolt Gr 5 NC 18-3074 Hose Hold Down Clamp 18-3075 Hose Hold Down Clamp Plate 25-34342...
- Page 18 Hoses Not Drawn To Scale...
- Page 19 Item No. Qty. Part No. Description 16-20034 5/16” x 1” Hex Bolt Gr 5 NC 16-20036 5/16” x 1-1/2” Hex Bolt Gr 5 NC 16-20040 5/16” x 2-1/2” Hex Bolt Gr 5 NC 16-20048 5/16” x 5” Hex Bolt Gr 5 NC 18-14695 Bracket, Relief Valve 18-3074...
- Page 20 NOTE: Your top arms may be slightly different than the ones 2,20 in these pictures but the hose routing is still compatible. Hoses Not Drawn To Scale 1,21 Tilt Rod Angle Rod (2-Stick Only) Tilt Base Right Angle Base (2-Stick) or Angle Base (Electric) Left Angle Base (2-Stick) or Angle Rod (Electric)
- Page 24 Contact Us As always, if you have any questions about your Ag Pro Plus HD Dozer or other products made by Grouser, feel free to contact us. Grouser Products 755 2nd Ave NW - West Fargo, ND 58078 Phone: 1-800-747-6182 Fax: 1-701-282-8131 E-mail: grouser@grouser.com...
