The LCD Monitor's Control Panel

1. OSD Menu button
Press this button to display the OSD (On-Screen Display) menu.

2. Function button

This button lets you go through the various controls available in
the OSD (ex. Monitor Control, OSD Control, etc.)
3. Adjustment button 1
This button lets you go through the suboptions within a
particular OSD control (ex. Auto Adjust, H-Position, etc. under
"Monitor Control" in the OSD). Once you are within a suboption
(ex. in H-Position), you can also use this button to increase
values.
4. Adjustment button 2
This button lets you adjust the values for a particular suboption
(ex. Brightness or Contrast settings under "Graphic Control" in
the OSD). Once you are within a suboption (ex. in Brightness),
you can also use this button to decrease values.
5. Power Switch
This button lets you turn power for the LCD monitor ON or OFF.
This is also a "hot key" to close the OSD menu while it is on
display.

The Display Controls

Figure 2-1: The Control Panel
