1.2.1 Development Board
Representations of the layout of the development board included in the PIC32MZ EF
Starter Kit are shown in
The top assembly of the board includes these key features, as indicated in
1. PIC32MZ2048EFH144-I/PH (without Crypto Engine) or PIC32MZ2048EFM144-I/PH
(with Crypto Engine) MCU (U1).
2. Green power indicator LED (D7).
3. On-board crystal or oscillator (Y1) for precision microcontroller clocking (24 MHz).
4. USB connectivity for on-board debugger communications.
5. Green debug indicator LED (D6).
6. Three push button switches for user-defined inputs (S1, S2, and S3).
7. Three user-defined indicator LEDs (D3, D4, and D5).
8. USB Type A receptacle connectivity for PIC32 host-based applications.
9. USB-to-UART/I
10. Daughter board connectors for flexible Ethernet PHY options.
11. 32 kHz oscillator (Y2) for RTCC and Timer1 (optional).
12. External 4 MB SQI memory for expanded memory applications (U9).
13. Jumper for using or disconnecting the on-board debugger.
14. Connector for an external debugger such as MPLAB
15. 40-pin expansion connector for adding external boards.
16. Three USB-to-USART/I
Note: When running self-powered USB device applications, open the jumper JP1
to prevent possibly back-feeding voltage onto the V
the host to another (or from one host to another).
For details on these features, refer to
PIC32MZ EF STARTER KIT LAYOUT (TOP VIEW)
10
9
9
16
10
5
8
Figure 1-1 and Figure
2
C communication (U8).
2
C communication indicator LEDs (D8, D9, and D11).
Chapter 2.
14
13
16
16
1
3
2
1-2.
®
REAL ICE or MPLAB ICD 3.
from one port on
BUS
"Hardware".
6
7
6
7
6
7
11
12
 2015 Microchip Technology Inc.
Figure 1-1:
15
