Page 1 SDS6000L Series Low Profile Digital Oscilloscope User Manual EN01A...
Page 3: Table Of Contents
SDS6000L User Manual Contents CONTENTS ..........................1 INTRODUCTION ........................ 9 IMPORTANT SAFETY INFORMATION ................10 ....................10 ENERAL AFETY UMMARY ....................13 AFETY ERMS AND YMBOLS ......................14 ORKING NVIRONMENT ....................... 15 OOLING EQUIREMENTS ................16 OWER AND ROUNDING EQUIREMENTS ..........................
Page 4 SDS6000L User Manual 5.5.6 Reference Input and Output ....................35 5.5.7 Waveform Generator ......................35 5.5.8 Logic Probe ........................... 35 ..........................36 OWER ON ..........................36 HUT DOWN ......................37 YSTEM NFORMATION ........................37 NSTALL PTIONS REMOTE CONTROL ....................... 38 ........................
Page 5 SDS6000L User Manual 12 ZOOM ..........................83 13 TRIGGER ......................... 85 13.1 O ..........................85 VERVIEW 13.2 T ........................86 RIGGER ETUP 13.3 T ........................87 RIGGER EVEL 13.4 T ........................88 RIGGER 13.5 T ........................89 RIGGER 13.5.1 Overview ..........................89 13.5.2 Edge Trigger ..........................
Page 6 SDS6000L User Manual 14.4.2 UART Trigger ........................130 14.4.3 UART Serial Decode ......................130 14.5 CAN T ..................131 RIGGER AND ERIAL ECODE 14.5.1 CAN Signal Settings......................131 14.5.2 CAN Trigger ........................131 14.5.3 CAN Serial Decode ......................132 14.6 LIN T ..................
Page 7 SDS6000L User Manual 16.3.1 Vertical Measurement ......................166 16.3.2 Horizontal Measurement ..................... 168 16.3.3 Miscellaneous Measurements .................... 169 16.3.4 Delay Measurement ......................170 16.4 T ..........................171 REND 16.5 T ..........................172 RACK 16.6 D ........................173 ISPLAY 16.7 M ....................
Page 8 SDS6000L User Manual 22.2 M ........................214 ETUP 22.2.1 Create Mask ........................214 22.2.2 Mask Editor ......................... 215 22.3 P ........................217 22.4 O ........................... 217 PERATION 23 DVM ..........................218 23.1 O ..........................218 VERVIEW 23.2 M ........................... 219 23.3 D ..........................
Page 9 SDS6000L User Manual 28.2 S ........................259 IGNAL ETTING 28.3 C ........................ 260 LOCK ECOVERY 28.4 M ........................261 EASUREMENT 28.5 M ........................... 263 28.6 O ....................... 263 THER PERATION 29 JITTER ANALYSIS ......................264 29.1 O ..........................264 VERVIEW 29.2 S .......................
Page 10 SDS6000L User Manual 33.5.2 Self-Calibration ........................301 33.5.3 Developer Options ......................302 33.6 S ..........................302 ERVICE 33.6.1 Web ............................. 302 33.6.2 Network Mapping ........................ 302 33.6.3 Emulation ..........................303 33.6.4 LXI ............................304 33.6.5 Share File ..........................305 34 TROUBLESHOOTING ....................306 i n t .
Page 11: Introduction
It is an indispensable tool for designing, manufacturing, and maintaining electronic equipment. This user manual includes important safety and installation information related to the SDS6000L series of low-profile oscilloscopes and includes simple tutorials for the basic operation of the instrument.
Page 12: Important Safety Information
SDS6000L User Manual Important Safety Information This manual contains information and warnings that must be followed by the user for safe operation and to keep the product in a safe condition. General Safety Summary Carefully read the following safety precautions to avoid personal injury and prevent damage to the instrument and any products connected to it.
Page 13 SDS6000L User Manual contains capacitors, power supply, transformers, and other energy storage devices, which may cause high voltage damage. The internal devices of the equipment are sensitive to static electricity, and direct contact can easily cause irreparable damage to the equipment. It is necessary to return to the factory or the company's designated maintenance organization for maintenance.
Page 14 SDS6000L User Manual replace the battery on the mainboard. Do not use the equipment for measurements on mains circuits. Do not use the equipment for measurements on voltages exceeding the voltage ranges described in the manual. The maximum additional transient voltage cannot exceed 1300 V. The responsible body or operator should refer to the instruction manual to preserve the protection afforded by the equipment.
Page 15: Safety Terms And Symbols
SDS6000L User Manual Safety Terms and Symbols When the following symbols or terms appear on the front or rear panel of the instrument or in this manual, they indicate special care in terms of safety. This symbol is used where caution is required. Refer to the accompanying information or documents to protect against personal injury or damage to the instrument.
Page 16: Working Environment
SDS6000L User Manual Working Environment The design of the instrument has been verified to conform to EN 61010-1 safety standard per the following limits: Environment The instrument is used indoors and should be operated in a clean and dry environment with an ambient temperature range.
Page 17: Cooling Requirements
SDS6000L User Manual Installation (overvoltage) Category This product is powered by mains conforming to installation (overvoltage) Category II. Note: Installation (overvoltage) category I refers to situations where equipment measurement terminals are connected to the source circuit. In these terminals, precautions are done to limit the transient voltage to a correspondingly low level.
Page 18: Power And Grounding Requirements
SDS6000L User Manual CAUTION: Do not allow any foreign matter to enter the scope through the ventilation holes, etc. Power and Grounding Requirements The instrument operates with a single-phase, 100 to 240 Vrms (+/-10%) AC power at 50/60 Hz (+/- 5%), or single-phase 100 to 120 Vrms (+/-10%) AC power at 400 Hz (+/-5%).
Page 19: Cleaning
SDS6000L User Manual The position of the oscilloscope should allow easy access to the socket. To make the oscilloscope completely power off, unplug the instrument power cord from the AC socket. The power cord should be unplugged from the AC outlet if the scope is not to be used for an extended period.
Page 20: Safety Compliance
SDS6000L User Manual Warning: Any use of the scope in a manner not specified by the manufacturer may impair the instrument’s safety protection. This instrument should not be directly connected to human subjects or used for patient monitoring. Safety Compliance This section lists the safety standards with which the product complies.
Page 21: Informations Essentielles Sur La Securite
SDS6000L User Manual Informations essentielles sur la sécurité Ce manuel contient des informations et des avertissements que les utilisateurs doivent suivre pour assurer la sécurité des opérations et maintenir les produits en sécurité. Exigence de Sécurité Lisez attentivement les précautions de sé curité ci - après afin d 'éviter les dommages corporels et de prévenir les dommages aux instruments et aux produits associés.
Page 22 SDS6000L User Manual Entretien du matériel. En cas de défaillance de l'équipement, ne pas dé monter et entretenir l'équipement sans autorisation. L'équipement contient des condensateurs, de l'alimentation électrique, des transformateurs et d'autres dispositifs de stockage d'énergie, ce qui peut causer des blessures à haute tension. Les dispositifs internes de l'équipement sont sensibles à...
Page 23: Termes Et Symboles De Securite
SDS6000L User Manual Le Circuit d 'alimentation électrique ne peut pas être mesuré à l' aide du dispositif, ni la tension qui dé passe la plage de tension dé crite dans le présent manuel. Seuls les ensembles de sondes conformes aux spécifications du fabricant peuvent être utilisés. L'organisme ou l'opérateur responsable doit se référer au cahier des charges pour proté...
Page 24: Environnement De Travail
SDS6000L User Manual Ce symbole est utilisé pour représenter un courant alternatif, ou "AC". Le symbole " CAUTION" indique un danger potentiel. Il attire l'attention sur une procédure, une pratique ou une condition qui peut être dangereuse si elle n'est pas CAUTION suivie.
Page 25 SDS6000L User Manual Humidité Fonctionnement: 5% ~ 90% HR, 30 ° C, 40 ° C ré duit à 50% HRHors fonctionnement: 5% ~ 95%, 65 ℃, 24 heures Altitude Fonctionnement: ≤ 3000 m À l'arrêt: ≤ 12,191 m Caté gorie d 'installation (surtension) Ce produit est alimenté...
Page 26: Exigences De Refroidissement
SDS6000L User Manual Exigences de refroidissement Cet instrument repose sur un refroidissement à air forcé avec des ventilateurs internes et des ouvertures de ventilation. Des précautions doivent être prises pour éviter de restreindre le flux d'air autour des ouvertures (trous de ventilateur) de chaque côté de la lunette. Pour assurer une ventilation adéquate, il est nécessaire de laisser un espace minimum de 15 cm (6 pouces) sur les côtés de l'instrument.
Page 27: Nettoyage
SDS6000L User Manual au châssis de l'instrument. Pour une protection adé quate contre les risques d'é lectrocution, la fiche du cordon d'alimentation doit être insérée dans une prise secteur correspondante contenant un contact de sécurité avec la terre. Utilisez uniquement le cordon d'alimentation spécifié pour cet instrument et certifié...
Page 28: Conditions Anormales
SDS6000L User Manual Conditions anormales Utilisez l'instrument uniquement aux fins spécifiées par le fabricant. N'utilisez pas la lunette s'il y a des signes visibles de dommages ou si elle a été soumise à de fortes contraintes de transport. Si vous pensez que la protection de l'oscilloscope a été altérée, débranchez le cordon d'alimentation et sécurisez l'instrument contre toute opération involontaire.
Page 29: First Steps
SIGLENT shall not be responsible for any defect, damage, or failure caused by any of the following: a) Attempted repairs or installations by personnel other than SIGLENT.
Page 30: Document Conventions
SDS6000L User Manual Document Conventions For convenience, italicized text with shading is used to represent the clickable menu/button/region on the display. For example, Display represents the "Display" menu on the screen: For the operations that contain multiple steps, the description is in the form of "Step 1 > Step 2 >...". As an example, follow each step in the sequence to enter the upgrade interface: Utility >...
Page 31: Getting Started
SDS6000L User Manual Getting Started Mechanical Dimension 4-channel model 8-channel model Front View Top View i n t . s i g l e n t . c o m...
Page 32: Front Panel Overview
SDS6000L User Manual Front Panel Overview Analog Input Connectors 1 MΩ: ≤ 400 Vpk (DC + AC), DC~10 kHz; 50 Ω: ≤ 5 Vrms, ± 10 V Peak Digital Input Connector USB 3.0 Host Ports Connect to USB storage devices for data transfer or USB mouse/keyboard for control Probe Compensation / Ground Terminal Power Standby Button...
Page 33: Rear Panel Overview
SDS6000L User Manual Rear Panel Overview AC Power Input and Power Switch SD Card Slot HDMI Video Output Connect the port to an external monitor. The resolution is 1280 * 800 1000M LAN Port Connect the port to the network for remote control USB 2.0 Hosts Connect with a USB storage device or USB mouse / keyboard USB 2.0 Device Connects with a PC for remote control Auxiliary Out Outputs the trigger indicator.
Page 34: To Install The Rackmount Flange Kit
Probes 5.5.2 The SDS6000L series oscilloscope supports active probes and passive probes. The specifications and probe documents can be obtained at int.siglent.com, www.siglentna.com, or www.siglenteu.com. i n t . s i g l e n t . c o m...
Page 35 SDS6000L User Manual Probe Compensation When a passive probe is used for the first time, you should compensate it to match the input channel of the oscilloscope. Non-compensated or poorly compensated probes may increase measurement inaccuracy or error. The probe compensation procedures are as follows: 1.
Page 36: Lan
SDS6000L User Manual 5.5.3 Connect the LAN port to the network with a network cable with an RJ45 connector for remote control. See the chapter “ Remote Control ” for detailed information on remotely controlling the instrument. Follow the steps below to set LAN connection: Utility >...
Page 37: Reference Input And Output
SDS6000L User Manual Reference Input and Output 5.5.6 The device can use the internal 10 MHz clock or a 10 MHz clock from another instrument or source using the 10 MHz In port as the reference. The reference clock is a 10 MHz square wave and can be output from the 10 MHz Out port for synchronizing other instruments.
Page 38: Power On
SDS6000L User Manual Power on The SDS6000L provides two ways to power on, which are: Auto Power-on When the “Auto Power-on” option is enabled, once the oscilloscope is connected to the AC power supply through the power cord, the oscilloscope boots automatically. This is useful in automated or remote applications where physical access to the instrument is difficult or impossible.
Page 39: System Information
SDS6000L User Manual System Information Follow the steps below to examine the software and hardware versions of the oscilloscope. Utility > Menu > System Info See the section "System Information" for details. Install Options A license is necessary to unlock a software option. See the section "Install Option" for details. i n t .
Page 40: Remote Control
SDS6000L User Manual Remote Control The SDS6000L provides a LAN port and a USB Device port which can be used for remote control in multiple ways. Web Browser A built-in web server provides an approach to interact with the oscilloscope by a web browser. It doesn’t require any additional software to be installed on the computer.
Page 41: Other Connectivity
SDS6000L User Manual Below is the instrument control interface: A. The display and control area of the instrument’s web control interface. The display in this area is a copy of the instrument display. Using the mouse to operate in this area is equivalent to directly operating the touch screen display of the instrument.
Page 42: Screen Display
SDS6000L User Manual Screen Display Overview When an external monitor is connected or a web server is used, the entire screen can be manipulated using a mouse. A. Menu Bar B. Grid Area C. Trigger Level Indicator D. Cursors E. Channel Descriptor Boxes Trigger Delay Indicator G.
Page 43: Menu Bar
SDS6000L User Manual Trigger Level Line (Vertical) and Trigger Delay Indicator (Horizontal) show the trigger position of the waveform. Cursors show where measurement points have been set. Move the cursors to quickly reposition the measurement point. Channel Descriptor boxes include analog channels (Cx), zoom traces (Zx), digital channels (D), math (Fx), memory (Mx), and reference (Ref).
Page 44 SDS6000L User Manual There are multiple indicators on the grid: Trigger Level Indicator shows the level where the waveform triggers on the vertical axis. Trigger Delay Indicator locates where the waveform triggers on the horizontal axis... When the trigger position is outside the screen, the direction of the triangle changes to point outside the screen.
Page 45: Channel Descriptor Box
SDS6000L User Manual Channel Descriptor Box Channel Descriptor boxes include analog channels (Cx), zoom traces (Zx), digital channels (D), math (Fx), memory (Mx), and reference (Ref). They are located under the grid area, showing the parameters of the corresponding traces. Clicking the boxes creates a dialog box. See the chapter “Vertical Setup” for more details.
Page 46: Timebase And Trigger Descriptor Boxes
SDS6000L User Manual ：Ground Vertical Scale: The scale of each grid in the vertical direction. For example, when the vertical scale is 1.00 V/div, the full scale of the oscilloscope is 1.00 V/div * 8 div=8 V. Vertical Offset: The offset of the channel in the vertical direction. When the vertical offset is 0, the channel offset indicator is located in the middle of the vertical axis.
Page 47 SDS6000L User Manual Trigger delay: The time offset of trigger position. When the trigger delay is 0, the trigger delay indicator is in the center of the horizontal axis of the grid area. Horizontal scale: Timebase, the time of each grid in the horizontal direction. For example, if the scale is 500us/div, the time of each grid is 500 us, and the full-screen time range of the oscilloscope is 500 us/div * 10 div = 5 ms.
Page 48 SDS6000L User Manual Trigger coupling: Coupling mode of the current trigger source. It is only valid when the trigger source is C1~C8, EXT, or EXT/5.  DC: All the signal’s frequency components are coupled to the trigger circuit for high-frequency bursts or where the use of AC coupling would shift the effective trigger level.
Page 49: Dialog Box
SDS6000L User Manual Dialog Box The dialog box on the right side of the screen is the main area for setting the parameters of the selected function. A. Title bar. Clicking the bar can hide the dialog box, and clicking again can open the dialog box.
Page 50 SDS6000L User Manual Let’s use the operation of setting the “deskew” of a channel as an example: If the expected value is 65 ns, input “65” on the virtual keypad, and then choose n as the unit “ns” to complete the operation. On the virtual keypad, clicking the button Max , Min , and Default quickly sets the parameter to the maximum, minimum, and default values.
Page 51: Mouse Control
SDS6000L User Manual Mouse Control Waveforms, cursors, and trigger levels can be adjusted using the mouse. It can also be used to define Zone Trigger areas as shown below: Click-and-drag the waveform left and right to move it on the horizontal axis Click-and-drag the waveform up and down to move it on the vertical axis Click-and-drag the cursor to move it...
Page 52: Choosing The Language
SDS6000L User Manual Choosing the Language Follow Utility > Menu > System Setting > Language to choose the language. See the section " Language " for details. i n t . s i g l e n t . c o m...
Page 53: Multiple Approaches To Recall Functions
SDS6000L User Manual Multiple Approaches to Recall Functions The oscilloscope can recall functions through different approaches. Menu Bar If you are familiar with common computer programs, you may first choose to access a function by the drop-down menu from the menu bar at the top of the display. For example, to open the trigger setup dialog box, you can follow the steps below: Trigger >...
Page 54: Vertical Setup
SDS6000L User Manual 9 Vertical Setup Turn on/off a Channel Click the + button and then select the expected channel to turn it on, and its channel descriptor box and a dialog box will appear on the display. Click the channel descriptor box and then click the Off button to disable it.
Page 55: Channel Setup
SDS6000L User Manual Channel Setup Click the channel descriptor box, a quick dialog will pop up. Vertical scale and offset can also be set from this dialog box. A. Click the region to set the vertical scale with the mouse wheel or virtual keypad B.
Page 56 SDS6000L User Manual Activating a channel recalls the channel dialog box, displaying more parameters: A. Turn the channel on/off B. Coupling (DC, AC, or GND) C. Bandwidth limit (Full, 200 MHz, or 20 MHz) D. Probe settings including attenuation (1X, 10X, 100X, or custom) and probe check.
Page 57 SDS6000L User Manual  GND: The channel is grounded by an internal switch. GND coupling is used to observe the zero- offset error of the analog channels or determine the source of noise in the waveform (from the signal or from the oscilloscope itself) Bandwidth Limit Full bandwidth passes through signals with high-frequency components, but it also means that noise with high-frequency components can pass through.
Page 58 SDS6000L User Manual For some active probes that need to be controlled from the UI, the Probe dialog provides the necessary setup. Below is an example of a current probe, of which the Degauss, Autozero, and Coupling options are accessible. i n t .
Page 59 SDS6000L User Manual Label Users can set the label text for channels. Open the label setting dialog box to select the source, customize the label text, and set the display. The source can be C1~C8, F1~F4, M1~M4, and RefA~RefH. The length of the label is limited to 20 characters. The characters beyond this length will not be displayed.
Page 60 SDS6000L User Manual time between the clock and data), it may be necessary to compensate for the skew between channels. The method of compensation: Probe the same signal simultaneously using two channels (including the cables or probes that you intend to use for measurements) and adjust the deskew parameter of one channel until the waveforms of the two channels observed on the screen coincide horizontally.
Page 61 SDS6000L User Manual Trace When the trace is hidden, the channel waveform is no longer displayed on the screen, while the acquisition is still running in the background. Trace visible Trace hidden i n t . s i g l e n t . c o m...
Page 62: Digital Channels
The equipment shall be used only for the purposes specified by the manufacturer. The SPL2016 probe is used only for SIGLENT's special series of oscilloscopes. Protection mechanisms can be compromised if the way the devices connected by the SPL2016 are not used for their intended purpose.
Page 63: Enable/Disable The Digital Channels
SDS6000L User Manual The software option adds the following functions to the oscilloscope:  Digital channel acquisition and analysis - Acquire and analyze the signals connected to the digital logic probe, including waveform display, save, parameter measurement, etc.  Trigger on a digital channel - Trigger with the digital channel as the trigger source, isolating events of interest.
Page 64: Digital Channel Setup
SDS6000L User Manual Click + at the bottom of the display and select the "Digital" to turn it on. Click the digital channel descriptor box, and select Off on the pop-up menu to turn it off. Refer to the operation in the chapter "Vertical Setup"...
Page 65 SDS6000L User Manual The quick menu only covers the height range and position of the digital channels display area. More settings can be found in the dialog box. A. Turn on/off the digital channels B. Labels can be set to data, address, or custom characters.
Page 66 SDS6000L User Manual The configurable logical level includes TTL, CMOS, LVCMOS 3.3 V, LVCMOS 2.5 V, and Custom. The setting range of the custom threshold is - 10.0 V to + 10.0 V. Bus Setting Click the Digital descriptor box on the bottom to open the Digital dialog box, click Bus to open the Digital Bus dialog box.
Page 67 SDS6000L User Manual Bus Data Setting The bus data setting supports setting the digital channel data by bit. Click Data to open the bus data setting dialog. In this dialog, the mapping relationship between the bus bits and the digital channels is shown as Bit.x[Dy].
Page 68: Horizontal And Acquisition Setup
SDS6000L User Manual 11 Horizontal and Acquisition Setup 11.1 Timebase Setup The timebase setup is used to adjust the scale and offset of the X (horizontal) axis. This setting applies to all analog, and digital channels as well as all math traces except FFT. Click the timebase descriptor box and the quick menu of the timebase settings will pop up.
Page 69: Acquisition Setup
SDS6000L User Manual 11.2 Acquisition Setup Overview 11.2.1 Click Acquire Menu on the quick menu of the timebase settings, or click the menu bar Acquire > Menu to recall the Acquire dialog box on the right side. A. Select the interpolation mode B.
Page 70 SDS6000L User Manual  X: Linear interpolation, the simplest way of interpolation, connects two original points with a straight line.  Sinc: Sin(x)/x interpolation, the original point is interpolated according to the Nyquist reconstruction formula, which has a good time-domain recovery effect for a sine wave. But for step signals / fast rise times, it will introduce false overshoot due to the Gibbs phenomenon.
Page 71: Acquisition
SDS6000L User Manual 12.5M 12.5M 12.5M 125M 125M 125M 250M 250M 500M Channels 1, 2, 3, and 4 (C1~C4) are in group 1 and 5, 6, 7, and 8 (C5~C8) are in group 2  Single-channel mode: In one group, only one channel is on and in the other group, one channel or less is on.
Page 72 SDS6000L User Manual Normal mode Peak mode Average: The oscilloscope accumulates multiple waveform frames and calculates the average as the result. If a stable trigger is available, the resulting average has a random noise component lower than that of a single-shot record. The more frames that are accumulated, the lower the noise is. For the SDS6000L, average processing is implemented by the hardware engine, so it can still maintain a high waveform update rate when the acquisition mode is set to average.
Page 73 SDS6000L User Manual Normal mode ERES mode (3-bit) ERES acquisition does not require the signal to be periodic, nor does it require stable triggering, but due to the digital filtering, the system bandwidth of the oscilloscope will degrade in ERES mode. The higher the enhanced bits, the lower the bandwidth.
Page 74: Memory Management
SDS6000L User Manual Memory Management 11.2.3 Memory Management controls how the instrument stores the acquired samples. Auto: The default acquisition setting. After setting the maximum memory in the Auto mode, the oscilloscope automatically adjusts the sample rate and memory depth according to the time base. The adjustment principle is to follow the formula: Sample rate = number of samples/time of acquisition Where the time of acquisition is the time corresponding to the full display (i.e.
Page 75: Roll Mode
SDS6000L User Manual Roll Mode 11.2.4 Click Acquire > Roll to enter roll mode. In this mode, the waveform moves across the screen from right to left, similar to a strip chart recorder. The horizontal delay control of the waveform will be disabled when roll mode is active.
Page 76 SDS6000L User Manual In addition to minimizing the dead time, another advantage of Sequence mode is that it can capture and record rare events over long periods. The oscilloscope can capture multiple events that satisfy the trigger conditions, ignoring the periods of no interest between adjacent events, thus maximizing the use of waveform memory.
Page 77 SDS6000L User Manual In normal mode, 5 pulses can be obtained on the screen with the sample rate of 1.25 GSa/s at the maximum memory depth. Set the trigger mode to "Single" and the timebase to 50 ns/div. Turn on the Sequence mode, and set the segments to maximum (46,378 in this example, up to 80,000 depending on the number of samples at the current time base).
Page 78: Esr
11.2.6 Each channel of the SIGLENT SDS6000L Oscilloscope employs a 5 GSa/s analog-to-digital-converter (ADC). After each ADC, a 2x interpolation process is applied that provides a 10 GSa/s ESR option for the users. The data flow and corresponding spectrum are shown in the figure below:...
Page 79 SDS6000L User Manual The 2x interpolation implemented is a classic sinx/x up-sampling processed by a high-speed Field Programmable Gate Array (FPGA) in real-time. The following figure shows the frequency response of the Finite Impulse Response (FIR) digital filter used in the interpolation. From the frequency response, we can see it has no attenuation at fmax = 2 GHz, and ~70 dB attenuation at 5 GHz –...
Page 80 SDS6000L User Manual Interpolation can significantly reduce this kind of error. Below is the same signal with an identical sample rate but followed by the 2x interpolation technique. From this figure, we can see points inserted between the raw data in the top/base area are closer to the real top/base of the analog input, which reduces the error.
Page 81 SDS6000L User Manual With the ESR enabled, in ERES acquisition mode, the bandwidth will be twice as scenarios without ESR: Table: ERES Bandwidth comparison between ESR disabled and enabled Enhanced Bandwidth with ESR = OFF Bandwidth with ESR = ON Resolution (5 GSa/s) (10 GSa/s)
Page 82: History
SDS6000L User Manual 11.3 History Click Analysis > History to recall the history dialog box. A. Turn on or off history mode B. Specify the frame index C. Set the playing mode D. Play backward, pause, and play forward E. Turn on or off the list List time type G.
Page 83 SDS6000L User Manual Observing the 5412th frame captured by Sequence in history mode Click the List area and turn on the list. The time label corresponding to the 5412th waveform is displayed. The time resolution is microseconds. Time label types include AcqTime or Delta T , AcqTime corresponds to the absolute time of the frame, synchronized with the real-time clock of the oscilloscope;...
Page 84 SDS6000L User Manual In addition to manually specifying a frame, history mode supports auto-play: Click the softkey to replay the waveform from the current frame to the first. Click the softkey to stop replay. Click the softkey to replay the waveform from the current frame to the last. Click the Interval Time area to control the speed of automatic play.
Page 85: Zoom
SDS6000L User Manual 12 Zoom The SDS6000L supports waveform zoom in the horizontal and vertical directions. Perform Acquire > Zoom to turn on Zoom, or click + at the bottom to add a zoom trace. When the Zoom function is on, the waveform area is divided into upper and lower parts. The area of about 1/3 height above is the main window, and the area of about 2/3 height below is the zoom window.
Page 86 SDS6000L User Manual Below is an example of changing the setting in the horizontal direction by different actions. The actions for changing the setting in the vertical direction are similar. Adjust the horizontal position of the zoom area by dragging left and right in the zoom area of the main window or waveform in the Zoom window.
Page 87: Trigger
SDS6000L User Manual 13 Trigger 13.1 Overview The oscilloscope only acquires waveforms of interest (i.e. the ones that satisfy the trigger condition) and aligns all trigger events at the trigger position to form a stable waveform display. The trigger is one of the most important features of an oscilloscope since we can only analyze a signal that we can trigger reliably and stably.
Page 88: Trigger Setup
SDS6000L User Manual 13.2 Trigger Setup Click the trigger descriptor box to display the quick menu of trigger settings. The trigger setup dialog box is displayed on the right side of the screen. A. Click the level region and roll the mouse wheel to adjust the trigger level.
Page 89: Trigger Level
SDS6000L User Manual Trigger Related Label Trigger level Indicator Horizontal 0 position Indicator Horizontal 0 position (out of screen) Indicator 13.3 Trigger Level Both analog and digital triggers must have a correct trigger level value. The oscilloscope judges whether a waveform satisfies the trigger condition when it crosses the trigger level. If it does, the crossing time is the trigger position.
Page 90: Trigger Mode
SDS6000L User Manual 13.4 Trigger Mode The trigger mode determines how the oscilloscope acquires waveforms. Auto: An internal timer triggers the sweep after a preset timeout period if no trigger has been found so that the oscilloscope continuously updates the display whether a trigger happens or not. Auto mode is suitable for unknown signals or DC signals.
Page 91: Trigger Type
SDS6000L User Manual 13.5 Trigger Type Overview 13.5.1 The trigger modes of the SDS6000L are digital designs. Compared with analog trigger circuits, digital triggers can not only greatly optimize trigger precision and trigger jitter, but also support multiple trigger types and complex trigger conditions. Edge -- Trigger on a rising edge, falling edge or both Slope -- Trigger when an edge crosses two thresholds that lie inside or outside a selected time range...
Page 92: Edge Trigger
SDS6000L User Manual Edge Trigger 13.5.2 Edge trigger distinguishes the trigger points by seeking the specified edge (rising, falling, alternating) and trigger level. The trigger source and slope can be set in the trigger dialog box. Click the Source area to select the trigger source, and click the Slope area to select rising, falling, or alternating.
Page 93 SDS6000L User Manual Click the Source area to select the trigger source, and click the Slope area to select rising or falling. Rising -- Only trigger on the positive slope Falling -- Only trigger on the negative slope Adjust the Upper/Lower Level The slope trigger requires upper and lower trigger levels.
Page 94: Pulse Trigger
SDS6000L User Manual Set Limit Range Click the Limit Range area in the trigger dialog box to select the time condition and set the corresponding time in the Upper Value / Lower Value area. Less than a time value（≤） -- Trigger when the positive or negative slope time of the input signal is lower than the specified time value.
Page 95 SDS6000L User Manual Less than a time value（≤）-- Trigger when the positive or negative pulse time of the input signal is lower than the specified time value. Below is an example of a trigger condition set to a positive pulse width <...
Page 96: Video Trigger
SDS6000L User Manual Video Trigger 13.5.5 Video trigger can be used to capture the complicated waveforms of most standard analog video signals. The trigger circuitry detects the vertical and horizontal interval of the waveform and produces a trigger based on the video trigger settings you have selected. The SDS6000L supports standard video signals for NTSC (National Television Standards Committee), PAL (Phase Alternating Line), HDTV (High- Definition Television), and a custom video signal trigger.
Page 97 SDS6000L User Manual The table below shows the parameters of the custom video trigger: Frame Rate 25Hz, 30 Hz, 50 Hz,60 Hz Of Lines 300 ~ 2000 Of Fields 1,2,4,8 Interlace 1:1, 2:1,4:1,8:1 Trigger Position Line Field (line value)/1(1:1) (line value)/2 (2:1) 1,2, 3, 4,5,6,7,8 (line value)/4(4:1) 1,2, 3, 4,5,6,7,8...
Page 98 SDS6000L User Manual For progressive scanning signals (e.g. 720p/50, 720p/60, 1080p/50, 1080p/60), only the specified line can be selected to trigger when the synchronization mode is “Select”. For interlaced scanning signals (such as NTSC, PAL, 1080i/50, 1080i/60, and Custom), when the synchronization mode is "Select", the specified line and the specified field can be selected to trigger.
Page 99 SDS6000L User Manual Trigger on a Specific Line of Video (NTSC) Use "Custom" to Trigger Video Signals Custom video trigger supports video signals with frame rates of 25, 30, 50, and 60 Hz respectively, and the specified row is within the range of 300 to 2000. The following describes how to trigger a "Custom"...
Page 100: Window Trigger
SDS6000L User Manual Window Trigger 13.5.6 The window trigger is similar to the edge trigger, except that it provides an upper and a lower trigger level. The instrument triggers when the input signal passes through the upper level or the lower level. There are two kinds of window types: Absolute and Relative.
Page 101: Interval Trigger
SDS6000L User Manual To set window trigger via the Relative window type When the window trigger type is set to "Relative", click the trigger descriptor box. The pop-up menu will show two user-defined parameters: “Level +/-Delta" and "Level Center". The above two parameters can be set in the following way: Select the parameter in the Level +/-Delta area of the quick menu, then set the parameter value by the virtual keypad or the mouse wheel.
Page 102: Dropout Trigger
SDS6000L User Manual Trigger source, slope (rising, falling), limit range, and time value can be set in the trigger dialog box. Holdoff, coupling, and noise reject can be set in interval trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. Dropout Trigger 13.5.8 Dropout trigger includes two types: Edge and State.
Page 103: Runt Trigger
SDS6000L User Manual Holdoff, coupling, and noise reject can be set in the dropout trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. Runt Trigger 13.5.9 Runt trigger looks for pulses that cross one threshold but not another as shown in the figure below: ...
Page 104 SDS6000L User Manual Logic (AND, OR, NAND, NOR), source, limit range, and time value can be set in the trigger dialog box. Source Setting Click the Source Setting area to recall the following dialog box and set up for each channel separately.
Page 105: Qualified Trigger
SDS6000L User Manual The logical setting of analog channels The logical setting of digital channels Limit Range This setting is particularly useful to filter the hazard signals of combinational logic. Holdoff can be set in pattern trigger, see the section "Holdoff" for details. Qualified Trigger 13.5.11 The qualified trigger is an edge trigger after a user-defined qualified condition is satisfied.
Page 106: Nth Edge Trigger
SDS6000L User Manual When the type is “Edge”, the oscilloscope triggers at the first edge after the specified edge (Rising or Falling) of the qualified source; when the type is “Edge with Delay”, a time limit condition is available. Click the Qualified Setting region to set the qualified source and threshold; Click the Edge Setting region to set the edge trigger source, threshold, and slope.
Page 107: Delay Trigger
SDS6000L User Manual Delay Trigger 13.5.13 A delay trigger is true when the edge of source B occurs after meeting the set conditions of source A and a user-defined delay time. The setting of source A is similar to that of the pattern trigger and can be used for logical "and"...
Page 108: Serial Trigger
SDS6000L User Manual Click the CLK Setting region to set the clock source, threshold, and slope; Click the Data Setting region to set the data source, threshold, and state. Serial Trigger 13.5.15 Refer to Chapter “Serial Trigger and Decode” for detailed information. 13.6 Trigger Source The trigger sources supported by each trigger type are different.
Page 109: Holdoff
SDS6000L User Manual 13.7 Holdoff Holdoff is an additional condition for triggers and can be used to stabilize the triggering of complex waveforms (such as a pulse series). It can be set to a time or number of events. Holdoff by Time Holdoff time is the amount of time that the oscilloscope waits before re-arming the trigger circuitry.
Page 110: Trigger Coupling
SDS6000L User Manual Acq Start -- The initial position of holdoff is the first-time point satisfying the trigger condition. In the example above, each holdoff starts from the first rising edge of the pulse sequence. Last Trig Time --The initial position of holdoff is the time of the last trigger. In the example above, the last trigger position is at the second rising edge of the pulse sequence and the second holdoff starts from that point.
Page 111: Noise Reject
SDS6000L User Manual 13.9 Noise Reject Noise Reject adds additional hysteresis to the trigger circuitry. By increasing the trigger hysteresis, the noise immunity becomes better but the trigger sensitivity degrades. Noise Reject = Off Noise Reject = On i n t . s i g l e n t . c o m 1 0 9...
Page 112: Zone Trigger
SDS6000L User Manual 13.10 Zone Trigger The SDS6000L includes a zone trigger to help isolate elusive glitches. There are two user-defined areas: Zone1 and Zone2. Users can set the property of each zone as “intersect” or “not intersect” as an additional condition to further isolate the interesting event quickly. “Intersect” only includes events that occur within the zone.
Page 113 SDS6000L User Manual Mouse When the zone trigger is turned on, click-and-hold on any position within the waveform area and draw a rectangular box, as shown in the following figure: When the finger moves out of the screen, a menu pops up for selecting the zone and setting the zone properties: i n t .
Page 114 SDS6000L User Manual Once a zone is created, it can be moved by dragging. Select C1 as the source, turn on zone1, Select C1 as the source, turn on zone1, and set the property as "Intersect" and set the property as "Not Intersect" Dialog Box Click Zone >...
Page 115 SDS6000L User Manual Below is an example in which we want to capture a waveform of bus contention using the SDS6000L: With a simple edge trigger, it is unlikely to trigger consistently on this anomaly. Thanks to the high waveform update rate of the SDS6000L, we can confirm there is bus contention happening by enabling the persistence display, as shown in the figure below: i n t .
Page 116 SDS6000L User Manual In this case zone trigger is a quick and simple way to capture the waveform. Enable the zone trigger, and draw a box to intersect with the bus contention part, as shown in the figure below: Now, we can accurately capture the exact bus contention waveform: 1 1 4 i n t .
Page 117: Serial Trigger And Decode
SDS6000L User Manual 14 Serial Trigger and Decode 14.1 Overview The SDS6000L supports serial bus trigger and decode on the following serial bus protocols: I2C, SPI, UART, CAN, LIN, FlexRay, CAN FD, I2S, MIL-STD-1553B, SENT, and Manchester. Click the trigger descriptor box, and then select the Type as Serial in the trigger dialog box to set the serial trigger: A.
Page 118 SDS6000L User Manual Perform Analysis > Decode to turn on the serial decode dialog box: A. Set the list of decoded results B. Select the bus to set, Bus1 and Bus2 C. Turn on/off the bus D. Set the bus display format (Binary, Decimal, Hex, and ASCII) E.
Page 119: I2C Trigger And Serial Decode
SDS6000L User Manual 14.2 I2C Trigger and Serial Decode This section covers triggering and decoding I2C signals. Please read the following for more details: "I2C Signal Settings", "I2C Trigger" and "I2C Serial Decode". I2C Signal Settings 14.2.1 Connect the serial data signal (SDA) and the serial clock signal (SCL) to the oscilloscope, set the mapping relation between channels and signals, and then set the threshold level of each signal.
Page 120: I2C Trigger
SDS6000L User Manual Copy Setting Click the Copy Setting in the decode dialog box to synchronize the settings between the trigger and decode. A. Copy the decode settings to trigger B. Copy the trigger settings to decode C. Return to the previous menu. Note: The synchronization is not automatic.
Page 121 SDS6000L User Manual Stop -- The oscilloscope will be triggered when the SDA line transitions from low to high while the SCL is high. Restart -- The oscilloscope will be triggered when another “Start” occurs before a “Stop". No Ack -- The oscilloscope will be triggered when the SDA line is high during any SCL’s ACK bit. EEPROM -- The trigger searches for EEPROM control byte value 1010xxx on the SDA bus.
Page 122 SDS6000L User Manual Frame (Start: 7-bit address: R/W: Ack: Data: Ack: Data2) -- If all bits match, then trigger on the Ack bit followed by the Data2. 10 Address & Data -- If all bits match, then trigger on the Ack bit followed by the Data. Frame (Start: Address 1st byte: R/W: Ack: Address 2nd byte: Ack: Data) 1 2 0 i n t .
Page 123 SDS6000L User Manual If you set the trigger condition to 7 address & data or 10 address & data:  Address can be selected in the hexadecimal range of 0x00 to 0x7F (7-bit) or 0x3FF (10-bit). If the address is selected as "0xXX (7-bit address)" or "0xXXX (10-bit address)", the address is ignored.
Page 124: I2C Serial Decode
SDS6000L User Manual I2C Serial Decode 14.2.3 The layout of the display when I2C decode is enabled is as follows: A. The waveform display area shows the original waveforms of the bus signals B. The bus display shows the decoding result of the bus. At most two buses can be decoded at the same time.
Page 125 SDS6000L User Manual  The address value is displayed at the beginning of a frame. The write address is displayed in green and the read address is in yellow.  W/R bit is represented by (W) and (R), followed by the address value. ...
Page 126 SDS6000L User Manual Configuration There is only one item Include R/W Bit in the configuration of the I2C decode. When it is disabled, the address is represented separately from the R/W bit, and when it is enabled, the R/W bit is represented together with the address.
Page 127: Spi Trigger And Serial Decode
SDS6000L User Manual 14.3 SPI Trigger and Serial Decode This section covers triggering and decoding SPI signals. Please read the following for more details: "SPI Signal Settings", "SPI Trigger" and "SPI Serial Decode". SPI Signal Settings 14.3.1 Connect the CLK, MOSI, MISO, and CS signals to the oscilloscope and set the mapping relation between channels and signals.
Page 128 SDS6000L User Manual The CS signal should be set to correct CS Type , including CS, ~CS, and Clock Timeout.  CS – Active high. The CS signal needs a complete rising edge in the screen to be regarded as active.
Page 129 SDS6000L User Manual When the CS type is set to Clock Timeout, turn on Cursor, measure the clock idle time between frames as 150 us, and measure the interval between clock pulses as 1.28 us, then set the timeout to a value between 1.28 us and 150 us.
Page 130: Spi Trigger
SDS6000L User Manual SPI Trigger 14.3.2 The trigger condition for the SPI trigger is mainly about data. Click Trigger Setting in the dialog box to set data: A. Trigger Type: MISO or MOSI B. Set the trigger position type. When set to Any, it will trigger on the specified data.
Page 131: Uart Trigger And Serial Decode
SDS6000L User Manual 14.4 UART Trigger and Serial Decode This section covers triggering and decoding UART signals. Please read the following for more details: "UART Signal Settings", "UART Trigger" and "UART Serial Decode". UART Signal Settings 14.4.1 Connect the RX and TX signals to the oscilloscope, set the mapping relation between channels and signals, and then set the threshold level of each signal.
Page 132: Uart Trigger
SDS6000L User Manual UART Trigger 14.4.2 Click Trigger Setting in the dialog box to set the trigger condition: A. Source Type: RX or TX B. Trigger Condition: Start, Stop, Data or Error C. When the "trigger condition" is Data, set the compare type to =, >, <...
Page 133: Can Trigger And Serial Decode
SDS6000L User Manual 14.5 CAN Trigger and Serial Decode This section covers triggering and decoding CAN signals. Please read the following for more details: "CAN Signal Settings", "CAN Trigger" and "CAN Serial Decode". CAN Signal Settings 14.5.1 Connect the CAN_H and CAN_L signals to the oscilloscope, set the mapping relation between channels and signals, and then set the threshold level of each signal.
Page 134: Can Serial Decode
SDS6000L User Manual  ID + Data -- The oscilloscope triggers on the data frame that matches the specified ID and data.ID, ID Bits (11-bit or 29-bit), Curr ID Byte (1st, 2nd, 3rd, or 4th byte), Data1, and Data2 can be set.
Page 135 SDS6000L User Manual  ID -- ID of the frame, 11-bits or 29-bits ID are automatically detected.  Length -- Data length.  Data -- Data values.  CRC -- Cycle redundancy check.  Ack -- Acknowledge bit. i n t . s i g l e n t . c o m 1 3 3...
Page 136: Lin Trigger And Serial Decode
SDS6000L User Manual 14.6 LIN Trigger and Serial Decode This section covers triggering and decoding LIN signals. Please read the following for more details: “LIN Signal Settings”, “LIN Trigger” and “LIN Serial Decode”. LIN Signal Settings 14.6.1 Connect the LIN signal to the oscilloscope, and then set the threshold level of the signal. The process of specifying the source and threshold is similar to “I2C Signal Settings”.
Page 137: Lin Serial Decode
SDS6000L User Manual LIN Serial Decode 14.6.3 The configuration of LIN decoding is similar to that of I2C decoding. On the bus:  ID is displayed in green  LEN (data length) and CHK are displayed in blue  DATA are displayed in white. In the list view: ...
Page 138: Flexray Trigger And Serial Decode
SDS6000L User Manual 14.7 FlexRay Trigger and Serial Decode This section covers triggering and decoding FlexRay signals. Please read the following for more details: "FlexRay Signal Settings", "FlexRay Trigger" and "FlexRay Serial Decode". FlexRay Signal Settings 14.7.1 Connect the FlexRay signal to the oscilloscope, and then set the threshold level of the signal. The process of specifying the source and threshold is similar to "I2C Signal Settings".
Page 139: Flexray Serial Decode
SDS6000L User Manual the repetition factor is also required. ✓ Click Cycle to set the cycle count by the mouse wheel or virtual keypad. The range of data values is 0 to 63.  Symbol -- The oscilloscope triggers on CAS/MTS (Conflict Avoidance Symbol/ Media access Test Symbol) or WUS (Wake-up Symbol) ...
Page 140 SDS6000L User Manual In the list view:  Time -- The horizontal offset of the current data frame head relative to the trigger position.  FID -- Frame ID, the symbol occupies a single line of the list.  PL -- Valid Data Length ...
Page 141: Can Fd Trigger And Serial Decode
SDS6000L User Manual 14.8 CAN FD Trigger and Serial Decode This section covers triggering and decoding CAN FD signals. Please read the following for more details: "CAN FD Signal Settings", "CAN FD Trigger" and "CAN FD Serial Decode". CAN FD Signal Settings 14.8.1 Connect the CAN FD signal to the oscilloscope, and then set the threshold level of the signal.
Page 142: Can Fd Serial Decode
SDS6000L User Manual Trigger Condition  Start -- The oscilloscope triggers at the beginning of the frame.  Remote -- The oscilloscope triggers on a remote frame with a specified ID. ID, ID Bits (11-bit or 29-bit), and Curr ID Byte (1st, 2nd, 3rd, or 4th byte) can be set. Curr ID Byte is used to specify the byte to be adjusted when using the mouse wheel.
Page 143 SDS6000L User Manual In the list view:  Time -- The horizontal offset of the current data frame head relative to the trigger position.  Type -- Type of the frame. The Standard CAN frame is represented by "Std", CAN FD frame is represented by "FD", the extended frame is represented by "Ext"...
Page 144: I2S Trigger And Serial Decode
SDS6000L User Manual 14.9 I2S Trigger and Serial Decode This section covers triggering and decoding I2S signals. Please read the following for more details: "I2S Signal Settings", "I2S Trigger" and "I2S Serial Decode". I2S Signal Settings 14.9.1 Connect the WS, BCLK, and Data signals to the oscilloscope, set the mapping relation between channels and signals, and then set the threshold level of each signal.
Page 145: I2S Trigger
SDS6000L User Manual I2S Trigger 14.9.2 Click Trigger Setting in the I2S trigger dialog box to set the trigger conditions : A. Audio Variant: Audio-I2S, Audio-LJ, Audio-RJ B. Trigger Condition: Data, Mute, Clip, Glitch, Rising Edge, Falling Edge C. Channel: Set the channel to trigger, Left or Right D.
Page 146: I2S Serial Decode
SDS6000L User Manual ✓ Click MNF to set the mute threshold by the mouse wheel or virtual keypad. The range of values is related to the number of Data Bits . ✓ Click Duration to set the value by the mouse wheel or virtual keypad. The range is 1-64 frames.
Page 147: Mil-Std-1553B Trigger And Serial Decode
SDS6000L User Manual 14.10 MIL-STD-1553B Trigger and Serial Decode This section covers triggering and decoding MIL-Standard 1553B signals. Please read the following for more details: "MIL-STD-1553B Signal Settings" and "MIL-STD-1553B Serial Decode". MIL-STD-1553B Signal Settings 14.10.1 Connect the MIL-STD-1553B signal to the oscilloscope, set the mapping relation between channels and signals, and then set the threshold level of each signal.
Page 148: Sent Trigger And Serial Decode
SDS6000L User Manual  Type— Type of the word  Data— Data values  Error— Error type 14.11 SENT Trigger and Serial Decode This section covers triggering and decoding SENT signals. Please read the following for more details: "SENT Signal Settings", "SENT Trigger" and "SENT Serial Decode". SENT Signal Settings 14.11.1 Connect the SENT signal to the oscilloscope, set the mapping relation between channels and signals,...
Page 149: Sent Trigger
SDS6000L User Manual SENT Trigger 14.11.2 When the protocol is set to SENT, the following trigger conditions can be set: Start, Slow Channel, Fast Channel, and Error. Click Trigger Setting in the SENT trigger dialog box to select the trigger condition: Start -- The oscilloscope will be triggered at the start of the message (after 56 synchronization ticks).
Page 150 SDS6000L User Manual Slow Channel -- the oscilloscope will be triggered on a Slow Channel Message. Frame (short serial message) -- The 16-bit message consists of a 4-bit Message ID nibble, 2 nibbles (1 byte) of data, and a CRC checksum nibble. If ID and data match, then trigger on the end of CRC bit. The serial message frame contains 21 bits of payload data.
Page 151 SDS6000L User Manual If you set the trigger condition to Slow Channel:  ID can be selected in the hexadecimal range of 0x0 to 0xF (short serial / enhanced serial with 4 bits ID) or 0x00 to 0xFF (enhanced serial with 8 bits ID). If it is selected as "0xXX", the ID is ignored.
Page 152: Sent Serial Decode
SDS6000L User Manual SENT Serial Decode 14.11.3 The configuration of SENT decoding is similar to that of I2C decoding. On the bus: For Fast Channel:  SYNC is displayed in pink  STATE is displayed in green  DATA is displayed in white ...
Page 153: Manchester Serial Decode
SDS6000L User Manual In the list view:  Time — The horizontal offset of the current data frame head relative to the trigger position. Sync — Sync pulse width (only fast channel)   State — Status & Communication nibble (only fast channel) ...
Page 154: Manchester Signal Settings
SDS6000L User Manual Manchester Signal Settings 14.12.1 Connect the Manchester signal to the oscilloscope, set the mapping relation between channels and signals, and then set the threshold level of the signal. The process of specifying the source and threshold is similar to "I2C Signal Settings" In the BusConfig menu of decode, the following parameters are available: A.
Page 155: Manchester Serial Decode
SDS6000L User Manual Manchester Serial Decode 14.12.2 The configuration of Manchester decoding is similar to that of I2C decoding. On the bus:  SYNC is displayed in pink  The header is displayed in green  DATA is displayed in white ...
Page 156: Cursors
SDS6000L User Manual 15 Cursors 15.1 Overview Cursors are important tools when measuring signals. Rapid measurements can be performed using cursors in both horizontal and vertical directions. The cursor types include X1, X2, X1-X2, Y1, Y2, and Y1-Y2, used to indicate X-axis values (time or frequency) and Y-axis values (amplitude) on a selected waveform (C1~C8/F1~F4/M1~M4/REF/Histogram).
Page 157 SDS6000L User Manual Cursors Mode Manual -- Manually sets the cursors’ position. Cursors type (horizontal, vertical, horizontal +  vertical) is available in this mode.  Track -- The cursor type is automatically set to "horizontal + vertical". In this mode, only horizontal cursors are adjustable, while the vertical cursors automatically attach to the cross-point of the cursor and the source waveform.
Page 158 SDS6000L User Manual Measure Mode Cursors Type X (horizontal) -- Vertical dotted lines that measure horizontal time (when the source is an FFT waveform, X cursors measure frequency). X cursors (time) X cursors (frequency)  X1 -- The left (default) vertical dotted line. It can be manually moved to any horizontal position on the screen.
Page 159 SDS6000L User Manual Y（vertical）-- Horizontal dotted lines that measure vertical voltage or current (depending on the unit of the selected channel). When the cursor's source is the math function, the units will match the math function.  Y1 -- The upper (default) horizontal dotted line. It can be manually moved to any vertical position on the screen.
Page 160 SDS6000L User Manual Display Mode Display Mode M1 Display Mode M2  M1 -- The position information of each cursor is attached to the cursor, and the difference information is between the two cursors with arrows connected to the cursors. This mode is more intuitive.
Page 161 SDS6000L User Manual Take the X cursors reference as an example to demonstrate the scaling effect of different settings: Timebase=50ns/div，X1=-50ns=-1div，X2=100ns=2div Fixed position, timebase is changed to 100 ns/div, and the grid number of X cursors (-1div, 2div) remains fixed. The value of X1 and X2 is changed to -100 ns, 200 ns. i n t .
Page 162: Select And Move Cursors
SDS6000L User Manual Fixed delay, timebase is changed to 100 ns/div, and the value of X cursors (-50 ns, 100 ns) remains fixed. The grid number of X cursors is changed to -0.5div, 1div. 15.2 Select and Move Cursors The cursors can be selected and moved directly by the mouse, in addition, they can be selected in the cursor’s value dialog box.
Page 163 SDS6000L User Manual Mouse Directly click the cursor and drag it, as shown below: Click the display area of △X (or △Y) in M1 mode and drag it to move the two cursors simultaneously, as shown in the figure below. This is equivalent to the operation on the cursor type X1-X2 or Y1-Y2. Dialog Box Click the cursor value area of the dialog box, and then roll the mouse wheel to adjust the position.
Page 164: Measurement
SDS6000L User Manual 16 Measurement 16.1 Overview The SDS6000L features a strong automatic measurement list. These parameters can be automatically measured without cursors and include common measurements such as rise time, fall time, peak-peak, and period. The SDS6000L can also measure multiple channels at the same time, showing up to 6 parameter measurements with statistics while in the M1 display mode and up to 12 parameters in the M2 mode.
Page 165: Set Parameters
SDS6000L User Manual Perform Measure > Menu to open the dialog box. A. Enable/disable measure B. Set the mode of measure: Simple or Advanced. "Simple" shows the specified basic measurement parameters of the selected channel. In "Advanced" mode, the measurement parameters can be added one by one as needed C.
Page 166 SDS6000L User Manual A. Set the source of the current setting. B. Measurement parameter classification tabs, including Favorite, Vertical, Horizontal, Miscellaneous, and CH Delay. Click a tab and the area will display the corresponding parameters C. Parameters. Click the parameter to be measured to activate it, and click it again to close the parameter.
Page 167 SDS6000L User Manual Once a parameter is selected, it will appear in the parameter and statistical display area below the grid: Click + in the blank area to add a parameter. Click – in the upper right corner of each parameter to close the parameter. Click ×...
Page 168: Type Of Measurement
SDS6000L User Manual 16.3 Type of Measurement Vertical Measurement 16.3.1 Vertical measurement includes 19 parameters:  Max: Highest value in the input waveform  Min: Lowest value in the input waveform  Pk-Pk: Difference between maximum and minimum data values ...
Page 169 SDS6000L User Manual  RMS: Root mean square of the data  Cycle RMS: Root mean square of the data in the first cycle  Median: Value at which 50% of the measurements are above and 50% are below  Cycle Median: Median of the first cycle ...
Page 170: Horizontal Measurement
SDS6000L User Manual  L@T: Level measured at trigger position Horizontal Measurement 16.3.2 Horizontal measurement includes 17 parameters:  Period: Time between the middle threshold points of two consecutive like-polarity edges.  Freq: Reciprocal of the period  Time@max: First time of maximum value ...
Page 171: Miscellaneous Measurements
SDS6000L User Manual  -Width: Time difference between the middle threshold of a falling edge to the middle threshold of the next rising edge of the pulse  +Duty: Positive Duty Cycle. The ratio of positive width to period  -Duty: Negative Duty Cycle.
Page 172: Delay Measurement
SDS6000L User Manual  Area@AC: Area of the waveform above the average minus the area of the waveform below average  AbsArea@AC: Area of the waveform above the average plus the area of the waveform below the average  Cycles: Number of cycles in a periodic waveform ...
Page 173: Trend
SDS6000L User Manual  FFFR: The time between the first falling edge of source A and the following first rising edge of source B at the middle threshold  FFFF: The time between the first falling edge of source A and the following first falling edge of source B at the middle threshold ...
Page 174: Track
SDS6000L User Manual A. Measurement parameter display area B. Trend plot display area C. Extend the range of time. Click it to expand the time range. D. Current value E. Maximum value Minimum value G. Average value H. Reset statistics Click Reset Statistics in the measure dialog box, or click the symbol in the statistics display area to clear and restart statistics.
Page 175: Display Mode
SDS6000L User Manual 16.6 Display Mode In advanced measurement mode, two display modes are supported: M1 and M2. In M1 mode, up to 6 parameter measurements are displayed at a time. When statistics are enabled, they are listed under the measurement items. Click a column to add or replace a measurement. In M2 mode, up to 12 parameter measurements are displayed at a time.
Page 176: Measurement Statistics
SDS6000L User Manual Note: In M2 mode histogram display is not supported. 16.7 Measurement Statistics Measurement statistics are based on the total number of captured waveforms. In Roll mode, measurement statistics increase over time. Click Statistics Setting in the measure dialog box to recall the Statistics Config dialog box: A.
Page 177: Statistics Histogram
SDS6000L User Manual  Value – The current measurement  Mean – Average of all historical measurements  Min – The minimum of all historical measurements  Max – The maximum of all historical measurements  Stdev – Standard deviation of all historical measurements ...
Page 178: Simple Measurements
SDS6000L User Manual Click the histogram area of a parameter to enlarge it for details. You can move the large histogram window position around the display by dragging. Click the histogram of another parameter to switch to the corresponding enlarged histogram. A.
Page 179: Gate
SDS6000L User Manual 16.10 Gate Sometimes the user may want to measure parameters for a certain specified time range of the signal and ignore signal parts that lie outside of that range. In this case, the Gate function can be helpful. Turn on the Gate, then two horizontal cursors A and B will appear in the grid area.
Page 180: Amplitude Strategy
SDS6000L User Manual 16.11 Amplitude Strategy According to different types of input signals, users can choose the corresponding amplitude calculation strategy which can measure top and bottom values with more accuracy. Perform Config > Amplitude Strategy in the measure dialog box to recall the amplitude strategy dialog box: A.
Page 181: Hardware Frequency Counter
SDS6000L User Manual A. Set measurement threshold source B. Set the type of threshold C. Set the upper value D. Set the middle value E. Set the lower value Return to the previous menu Threshold Type Percent: Set according to the percentage of the waveform. The setting range of lower value and upper value is 1% ~ 99%, and the low value shall not be greater than the middle value and high value Absolute: Set according to the vertical range.
Page 182: Math
SDS6000L User Manual 17 Math 17.1 Overview The SDS6000L supports 4 math traces and multiple operators. Arithmetic operators: Addition (+), subtraction (-), multiplication (x), division (/), average, ERES, identity, negation, maxhold, minhold. Algebra operators: differential (d/dt), integral (∫dt), square root (√), absolute (|y|), sign, exp, ln, interpolate;...
Page 183: Arithmetic
SDS6000L User Manual Math Operation Unit V, A, or U* Addition (+) or Subtraction (-) *(used when the units of two sources are not consistent) ∧ ∧ 2, A 2, or W Multiplication (x) None, Ω (Resistance unit Ohms), S (conductance unit Siemens) Division (/) dBVrms, Vrms, dBArms, Arms, dBm d/dt...
Page 184: Identity / Negation
SDS6000L User Manual The following figure shows an example of F1 = C1 + C2: Identity / Negation 17.2.2 The values of Source A are computed point-by-point when an identity or negation operation is chosen in any analog channel. The following figure shows an example of F1 = -C1: 1 8 2 i n t .
Page 185: Average / Eres
SDS6000L User Manual Average / ERES 17.2.3 Average / ERES can be set in acquisition mode and arithmetic function as well, but with different computing methods. Average and ERES in acquisition mode are computed by hardware with a higher speed than if they were computed by software in the arithmetic mode. Average and ERES in acquisition mode can only be based on data from analog channels, while the Average / ERES arithmetic function can use analog channels, zoom traces, math, and memory traces as the source.
Page 186: Integral
SDS6000L User Manual The differential equation is: Where: d = Differential result y = Values of source data i = Data point index dx = Differential interval The range of “dx” in the d/dt menu is 4~ number of samples pts. Note: Differentiation is sensitive to noise.
Page 187: Square Root
SDS6000L User Manual Square Root 17.3.3 Square root （√） calculates the square root of the selected source. If the waveform value is negative (the waveform is below the ground level), the result is displayed as zero. i n t . s i g l e n t . c o m 1 8 5...
Page 188: Absolute
SDS6000L User Manual Absolute 17.3.4 Absolute (|x|) calculates the absolute value of the selected trace. Sign 17.3.5 In mathematics, the sign function or signum function (from signum, Latin for "sign") is an odd mathematical function that extracts the sign of a real number. The sign function of a real number x is defined as follows: Sign(x) = -1 if x <...
Page 189: Exp/Exp10
SDS6000L User Manual exp/exp10 17.3.6 �� The exponential operation includes the exponential operation �� based on constant e and the �� exponential operation 10 based on 10. �� For example: y(x) = �� ln/lg 17.3.7 Logarithmic operation includes logarithm base e (ln) and logarithm base 10 (lg). In logarithmic operation, if the waveform value is negative (the waveform is below the ground level), the result is displayed as zero.
Page 190: Interpolate
SDS6000L User Manual Interpolate 17.3.8 Between the adjacent sampling points, the waveform is interpolated according to the selected interpolation method and interpolation coefficient. Click Acquire > Interpolation to set the interpolation method, and the interpolation coefficient can be set to 2, 5, 10, or 20. coefficient = 2 coefficient = 20 17.4 Filter...
Page 191 SDS6000L User Manual Adapt Sample Rate Unlike an ideal “brick wall” filter, the actual FIR filters have their roll-off from the passband to the stopband because of the limited number of taps. The 200-tap FIRs applied in the SDS6000L provide roll-off as fast as 0.01*fs (where fs is the sample rate), this means some limitations in the setting of corner frequency at a specified sample rate.
Page 192: Frequency Analysis
SDS6000L User Manual Professional users who have prior knowledge of FIR filters and are familiar with the operation of this instrument are encouraged to change the sample rate for the corner frequency of interest. Otherwise, we recommend using the “Adapt Sample Rate” option. In this mode, the scope forces the Memory Management Mode to be “Fixed Sample Rate”...
Page 193 SDS6000L User Manual A. Time-domain waveform display area B. Spectrum (FFT) waveform display area C. FFT parameter display area D. Dialog box Parameter Display Area The FFT parameters are displayed in the upper right of the spectrum waveform display area: ...
Page 194 SDS6000L User Manual Select Operation as FFT in the math dialog box and click Config to recall the configuration dialog box: A. Set the maximum points (2 , n = 10 ~ 23) B. Set the window type (Rectangle, Blackman, Hanning, Hamming, and Flattop) C.
Page 195 SDS6000L User Manual Window Characteristics Main lobe Side lobe Maximum width suppression amplitude error Rectangle The best frequency resolution The worst amplitude resolution 4π/N -13 dB 3.9 dB It is equivalent to the case of no window Hanning Better frequency resolution 8π/N -32 dB 1.4 dB...
Page 196 SDS6000L User Manual Full-Screen Mode Exclusive Mode FFT Mode  Normal: Displays the FFT result of each frame directly.  Max-Hold: Holds the maximum value in the historic frame on the display until cleared. This mode is suitable for detecting discontinuous waves, such as sporadic pulse signals, or frequency hopping signals.
Page 197 SDS6000L User Manual Click Vertical or Horizontal in the math dialog box to recall the FFT vertical or horizontal settings dialog box: A. Set the vertical scale and reference level B. Set the unit (dBVrms, Vrms, and dBm). When the unit is dBm, the oscilloscope will automatically calculate the dBm value based on the Ext Load value set in area...
Page 198 SDS6000L User Manual  Click Span to set the frequency span with the center frequency as the center by the mouse wheel or the virtual keypad.  Click Start to set the start frequency by the mouse wheel or the virtual keypad. ...
Page 199 SDS6000L User Manual When the FFT tool markers is selected, the dialog box is as follows: A. Control markers. Click to control the display and position of each marker B. Marker on peaks. It will automatically mark the peak that meets the conditions of Search Threshold and Search Excursion C.
Page 200: Formula Editor
SDS6000L User Manual The following screenshot shows the peaks of the FFT waveform: Measure the FFT waveform Turn on the cursor function, and then specify the source as "Fx". X1 and X2 cursors can be used to measure the frequency value at the cursor position. Only the “maximum”...
Page 201 SDS6000L User Manual A. Formula display text box B. Text box operation area, which can clear and modify the entered formula C. Special operators D. Operation source. Cx represents analog trace, Zx represents zoomed trace, Fx represents math trace and Mx represents memory trace E.
Page 202: Reference
SDS6000L User Manual 18 Reference Data from analog channels or math can be saved to the reference locations (REFA~H) in the built-in nonvolatile memory. The saved reference waveform can be recalled to be compared with the current waveform. A. Channel waveform B.
Page 203 SDS6000L User Manual Click + in the descriptor box region and select Ref to recall the ref dialog box. A. Select the location of the reference (REFA~REFH) B. Select the source (C1~C8 and F1~F4) C. Enable/disable the Display of the reference waveform D.
Page 204: Memory
SDS6000L User Manual 19 Memory Analog channels (Cx), zoom (Zx), math (Fx), memory waveforms (Mx), and waveforms in files can be imported to available memory waveforms (M1/M2/M3/M4) and displayed on the screen for comparison with the current waveforms. Differing from reference traces which are displayed data, the memory traces are in the format of raw data, which can be used as the source of Math and Decoding functions and can provide more accurate measurements than a reference waveform.
Page 205 SDS6000L User Manual Details of the dialog box are as below. A. Select the location of the memory (M1 ~ M4) B. Select the source (Cx / Zx / Fx / Mx / File) C. Import the trace of the selected source in to the memory location set in D.
Page 206: Search
SDS6000L User Manual 20 Search The SDS6000L can search for the specified events in a frame. The location of the events is displayed with white triangle indicators. In YT mode or Roll mode with the acquisition stopped, up to 1250 events are supported.
Page 207 SDS6000L User Manual Click the menu Analysis > Search to recall the search dialog box and turn it on. Setup Menu Select and set the search type in the Setup Menu . The SDS6000L provides five search conditions: Edge, Slope, Pulse, Interval, and Runt. i n t .
Page 208 SDS6000L User Manual Search Type Setup Description Edge Slope: Rising, Falling, or Either Slope Slope: Rising, Falling Limit Range setting is available Pulse Polarity: Positive, Negative Limit Range setting is available Interval Slope: Rising, Falling Limit Range setting is available Runt Polarity: Positive, Negative Limit Range setting is available...
Page 209: Navigate
SDS6000L User Manual 21 Navigate Click the menu Analysis > Navigate to recall the navigate dialog box. The SDS6000L provides three navigate types: Search Event, Time, and History Frame. Navigate by Time The oscilloscope automatically adjusts the trigger delay according to the direction set by the user. Click Type in the navigate dialog box to select the...
Page 210 SDS6000L User Manual Navigate by Search Event When the Search function is turned on and the acquisition is stopped, Navigate is usable to find search events (see the chapter "Search" for the search function). Click Type in the navigate dialog box to select the navigate type as “Search Event”.
Page 211 SDS6000L User Manual Navigate by History Frame When the history function is turned on, Navigate can be used to play history frames (see the chapter "History" for details of the history function). Click Type in the navigate dialog box to select the navigate type as “History Frame”.
Page 212 SDS6000L User Manual First, set the trigger type to Runt to trigger on the runt pulse. See the section “Runt Trigger” for details. Then turn on the Search function and operate Copy from Trigger in the search dialog box so that the oscilloscope searches for the dwarf pulses according to the same setting as the trigger.
Page 213 SDS6000L User Manual Turn on the Zoom function to observe the full view of the frame and the detail of the third dwarf pulse at the same time: Perform Acquire > Run/Stop to stop the acquisition, and then follow the steps Analysis >...
Page 214: Mask Test
SDS6000L User Manual 22 Mask Test 22.1 Overview Users can create masks and define the rule used to evaluate Pass/Fail operations. An event violating the rule is defined as a failure and a pulse can be generated from the "Aux Out" port on the back panel. This is very useful to find and quantify anomalies in production tests or similar batch measurements.
Page 215 SDS6000L User Manual Perform Analysis > Mask Test to open the Mask Test dialog box: A. Turn on/off the test B. Select the source（C1~C8） C. Select the rule（All In, All Out, Any In, and Any Out） D. Set the mask E.
Page 216: Mask Setup
SDS6000L User Manual 22.2 Mask Setup Click Mask Setup in the Mask Test dialog box to set the mask. There are two methods to create a mask, one is by setting horizontal and vertical values, and the other is by drawing a polygon mask. A.
Page 217: Mask Editor
SDS6000L User Manual Set the values for Mask X and Mask Y (in divisions of the display graticule), and then perform Create Mask to generate the mask. The horizontal and vertical adjustment range is 0.08~4.00 div. X = 0.2 div, Y = 0.2 div X = 1 div, Y = 1 div Saving and recalling mask files (*.msk) is similar to the operation of setup files, see the chapter "Save/Recall"...
Page 218 SDS6000L User Manual D. Toolbar E. Coordinate edit area. Set the X ordinate and Y ordinate by the virtual keypad and then click the “Input” button the perform the ordinate update Display or hide the coordinates of the polygon vertices on the display G.
Page 219: Pass/Fail Rule
SDS6000L User Manual Select a vertex (point) Select a side (line segment) Select a polygon 22.3 Pass/Fail Rule The Pass / Fail rule is specified at the Type region in the Mask Test dialog box.  All In: All data points must be inside the mask to pass the test. Even a single point outside the mask will cause a failure.
Page 220: Dvm
SDS6000L User Manual 23 DVM 23.1 Overview The DVM (Digital Voltage Meter) function can be used to measure parameters such as DC and AC amplitudes. The SDS6000L measures the specified parameter of the input signal and can display it in various formats, including Bar, Histogram, and Trend.
Page 221: Mode
SDS6000L User Manual Click the menu Analysis > DVM to open the DVM dialog box: A. Turn on or off the DVM B. Select the source (C1~C8) C. Select the Mode: DC Mean, DC RMS, AC RMS, Peak-Peak, and Amplitude D.
Page 222: Diagrams
SDS6000L User Manual  DC Mean: Average of the data  DC RMS: Root mean square of the data at DC coupling  AC RMS: Root mean square of the data at AC coupling  Peak-Peak: Difference between maximum and minimum data value ...
Page 223 SDS6000L User Manual A. Mode B. Histogram display area C. Current value D. The bin includes the maximum value and probability with which values fall into it E. Statistics counts Reset statistics Trend The trend diagram indicates the trend of the measured values over time. Click trend in the DVM dialog box to display it.
Page 224 SDS6000L User Manual A. Mode B. Trend display area C. Extend the range of time. Click it to expand the time range. D. Current value E. Maximum value Minimum value G. Average value H. Reset statistics Click the symbol in the histogram and trend display areas to restart statistics. When all the 3 diagrams are closed, there is a simple information bar on the top-left of the waveform display area to show the current value of the DVM: 2 2 2...
Page 225: Counter
SDS6000L User Manual 24 Counter 24.1 Overview The counter is used to measure the frequency and period of a signal or count the events happening within it. The counter is asynchronous to the acquisition system of the oscilloscope. It can work well even if the acquisition of the oscilloscope is stopped.
Page 226 SDS6000L User Manual Value – The latest count Mean – The average of all historical counts Min – The minimum of all historical counts Max – The maximum of all historical counts Stdev – The standard deviation of all historical counts, used to judge the distribution of historical count parameters Count –...
Page 227: Mode
SDS6000L User Manual 24.2 Mode The counter provides 3 modes. Click mode in the counter dialog box to open the mode selection window:  Frequency: Average frequency over a set period  Period: The reciprocal of the average frequency over a set period ...
Page 228: Histogram
SDS6000L User Manual 25 Histogram 25.1 Overview The SDS6000L supports waveform histograms for observing probability distributions of the waveform in the specified region. The statistics can be performed in both horizontal and vertical directions. The histogram continues to update as long as the acquisition is active. Click Analysis >...
Page 229 SDS6000L User Manual Horizontal Vertical Both Region Setting See the section “Region Setting” for details. Histogram Statistics When histogram statistics is turned on, the oscilloscope will show the statistical parameters of the histogram on the display. i n t . s i g l e n t . c o m 2 2 7...
Page 230: Region Setting
SDS6000L User Manual Sum – Total samples falling in the histogram region Peak – Samples in the highest bin Max – Maximum value of the samples Min – Minimum value of the samples Pk-Pk – Maximum - Minimum Mean – Mathematical expectation (or average) value of the samples Median –...
Page 231 SDS6000L User Manual A menu pops up at the end of the drawing action. Select "Histogram" in the menu: After the region is created, it can be moved by dragging action. Dialog Box Click Histogram > Region Setting to recall the dialog box. A.
Page 232: Power Analysis
Response, PSRR, Power Efficiency, Output Ripple, etc. Full use of the Power analysis requires a differential voltage probe like the SIGLENT DPB series, a current probe like the SIGLENT CP series, the SIGLENT DF2001A deskew fixture, and the power analysis activation license (part number SDS6000L-PA).
Page 233 SDS6000L User Manual ��−1 ∗ ∑ �� ∗ �� P: Active Power = ��=0 �� S: Apparent Power = Vrms * Irms Q: Reactive Power = √Apparent Power − Active Power φ: Power Phase Angle: Phase difference between voltage and current cos φ: Power Factor, which is the ratio of active power and apparent power.
Page 234 SDS6000L User Manual Signal Settings Click Signal to recall signal settings dialog box: A. Set the input voltage source B. Set the input current source C. Set the periods displayed D. View the connection guide E. Return to the previous menu Connection Guide Click Signal >...
Page 235: Current Harmonics
SDS6000L User Manual 26.3 Current Harmonics Current harmonics are used to analyze the input current harmonics. An FFT of the selected channel is performed to get the harmonic components. The signal settings and connection guide are the same as the power quality test. Configuration Click Config to recall the configuration dialog box: A.
Page 236 SDS6000L User Manual Parameter Description For the first 40 harmonics, the following values are displayed: Measured Value (RMS) -- The measured value displayed in the unit specified by the harmonic unit parameter Limit Value (RMS) -- Limits specified by the selected standard Margin (%) --The margin specified by selected standard parameters.
Page 237: Inrush Current
SDS6000L User Manual 26.4 Inrush Current A large current far greater than the stable current may flow through at the moment of switching on a power supply. The large current is called the inrush current. The current waveform when switching on is shown in the figure below: Signal Settings Click Signal to recall signal settings dialog box:...
Page 238: Switching Loss
SDS6000L User Manual 26.5 Switching Loss Switch loss analysis can be used to calculate the power dissipated in the switching period. Deskew Calibration A relatively small skew can cause a large measurement error of switching loss, especially during the on phase when the voltage is close to zero and the non-on phase when the current is close to zero. This is a typical oscilloscope dynamic range limitation when trying to measure weak voltage and (or) current in the presence of relatively large switching voltage and (or) current.
Page 239 SDS6000L User Manual C. Connect the voltage and current probes to the oscilloscope input channel D. Click Signal to enter the signal setting menu. Select the corresponding input channel, and then click Auto Deskew to perform the calibration. When the process completes, a message will pop up indicating whether the deskew operation was successful or not.
Page 240 SDS6000L User Manual Configuration Click Config to recall the configuration dialog box: A. Set the voltage reference, i.e. the switch level at the edge of the input switch. This value is a percentage of the maximum switching voltage. Adjusting the value to ignore background noise.
Page 241: Slew Rate
SDS6000L User Manual Connection Guide Click Signal > Connection Guide to recall the connection guide of switching loss, as shown in the figure below. Please follow the instructions in this figure for connection. Click the icon on the top right of the guide to close. 26.6 Slew Rate The slew rate measures the change rate of voltage or current during switching.
Page 242: Modulation
SDS6000L User Manual 26.7 Modulation Modulation analysis measures the control pulse signal of the switching device (MOSFET) and observes the pulse width, duty, period, frequency, and other trends of the control pulse signal in response to different events. Connection Guide Click Signal >...
Page 243: Turn On/Turn Off
SDS6000L User Manual 26.9 Turn On/Turn Off Turn-on analysis determines the time taken for the power supply to reach 90% of its steady-state output. Turn-off analysis determines the time taken for the power supply to fall to 10% of its maximum output voltage.
Page 244: Transient Response
SDS6000L User Manual Turn Off -- Determines the time it has taken for the power supply to be turned off to fall to a certain percentage of its maximum output voltage. The turn off time is between T2 and T1, where: T1 = When the input voltage finally falls to a certain percentage (usually 10%) of its maximum amplitude T2 = When the output DC voltage finally falls to a certain percentage (usually 10%) of its maximum amplitude...
Page 245 SDS6000L User Manual A. Set the output voltage source B. Set the output current source C. Set the duration. The oscilloscope will set the appropriate time base according to the duration D. Set the stable output voltage, i.e. the expected output DC voltage of the power supply in a stable state E.
Page 246: Psrr
SDS6000L User Manual Connection Guide Click Signal > Connection Guide to recall the connection guide of transient response, as shown in the figure below. Please follow the instructions in this figure for connection. Click the icon on the top right of the guide to close. 26.11 PSRR The power supply rejection ratio (PSRR) test is used to determine how the regulator suppresses ripple noise in different frequency ranges.
Page 247: Power Efficiency
SDS6000L User Manual 26.12 Power Efficiency Power efficiency analysis can test the overall efficiency of the power supply by measuring the output power and input power. Connection Guide Click Signal > Connection Guide to recall the connection guide of power efficiency, as shown in the figure below.
Page 248 SDS6000L User Manual Note: Perform a Deskew operation between the voltage and current input channels before the test. See the section “Switching Loss” for more details on deskewing. The test steps are as followed: In the Input Setup menu, assign the correct channels to Input Voltage and Input Current . Set Duration as the expected observed duration, then the oscilloscope will automatically set the timebase according to it.
Page 249 SDS6000L User Manual Below is an example of testing the power-up stresses on a MOSFET and judging if the stresses are safe for the MOSFET using the SOA: Voltage and current waveforms on the MOSFET at power-up SOA, in which the mask is created according to the voltage limit, current limit, and power limit.
Page 250: Bode Plot
At this time, either the built-in waveform generator or one of the SIGLENT SDG series arbitrary function generators are supported. During the sweep, the oscilloscope configures the generator output frequency and amplitude and then compares the input signal to the output of the DUT.
Page 251: Configuration
SDS6000L User Manual 27.2 Configuration Connection 27.2.1 A. DUT input and output channels B. Channel gain. When it is set to Auto, the oscilloscope will automatically adapt the vertical scale according to the signal amplitude; when it is set to Hold, it will always keep the vertical scale before the test operation C.
Page 252 SDS6000L User Manual C. Set the sweep frequency. The frequency mode can be linear or decade. When it is set to linear, the corresponding center frequency and span frequency need to be set; when it is set to a decade, the corresponding start frequency and stop frequency need to be set D.
Page 253 SDS6000L User Manual Click Nodes to set the signal node number through the mouse wheel, or click ▲ to increase the nodes and ▼ to decrease. Click the cell in the table area to set the frequency and amplitude of the corresponding node. Click to activate the cell, adjust the value through the mouse wheel, or click the cell again to call up the virtual keypad for setting.
Page 254: Display
SDS6000L User Manual 27.3 Display Bode plot display settings include amplitude, phase, cursors, and trace visibility. Amplitude Set the amplitude coordinate axis of the Bode plot. Click Display > Amplitude to recall the amplitude setting dialog box: A. Set the reference position to the center or top B.
Page 255 SDS6000L User Manual A. Set the reference position to the center or top B. Set the scale of the phase coordinate axis C. Set the reference level, the max value of the phase coordinate axis D. Set the phase unit (Degree or Rad) E.
Page 256: Data Analysis
SDS6000L User Manual Trace Visibility When multiple output signals are connected, the Bode plot interface will display the amplitude and phase curves of all output signals at the same time. Users can turn on/off other scanning curves to observe the details of specific curves. Click Display > Trace Visibility to recall the setting dialog box.
Page 257 SDS6000L User Manual Data List Click Data to recall the data setting dialog box: A. Turn on/off the data list B. Set the selected row in the list. Adjust the mouse wheel to set, or directly click the list display area to select a specific line.
Page 258 SDS6000L User Manual A. Set the position of measurement items, and support 5 measurement items at most B. Set the measurement source C. Measurement parameter area. Click each parameter area to activate the measurement parameter. In the figure above, "UF" is activated. D.
Page 259: Eye Diagram
SDS6000L User Manual 28 Eye Diagram 28.1 Overview An eye diagram is an oscilloscope display in which a high-speed digital signal is repetitively sampled and applied to the vertical input, while the data rate is used to trigger the horizontal sweep. It is called an Eye because the pattern looks like a series of eyes between a pair of rails.
Page 260 SDS6000L User Manual Eye Diagram Dialog Box: A. Turn on/off the eye diagram B. Quick view. The oscilloscope will automatically adjust its vertical/horizontal scale and trigger level after the corresponding channel source is set and the quick view option is active C.
Page 261: Signal Setting
SDS6000L User Manual 28.2 Signal Setting Click Signal Setting to open the signal setup dialog box. A. Signal Type: NRZ, 100Base-TX B. The source can be C1~C8. C. Set the trigger level manually D. The hysteresis of the trigger level has a unit of division in the vertical direction.
Page 262: Clock Recovery
SDS6000L User Manual 28.3 Clock Recovery Clock recovery is a feature that provides an ideal clock for comparison to actual signal edges. It is the key step in constructing an eye. The eye diagram can be constructed only when the reference clock is recovered from the data correctly.
Page 263: Measurement
SDS6000L User Manual Table 28.3 Description of Clock Data Rate Date Rate Description Automatic The clock is recovered using the signal edge database only. It is the recommended method in most cases. Manual The oscilloscope will perform clock recovery under the expected Data Rate as your input.
Page 264 SDS6000L User Manual Eye Height The vertical opening of an eye diagram. Estimated based on the vertical distribution of the measured high-voltage and measured low-voltage in the 40% to 60% UI interval.   EyeHeight= V -3 - V +3 1-level The high voltage corresponds to 1-level in the diagram.
Page 265: Mask Test
SDS6000L User Manual 28.5 Mask Test Click the Mask Test under the eye diagram menu to start the mask test configuration. Its principle and operation process are the same as the mask test in normal mode. Refer to “Mask Test” to see the details.
Page 266: Jitter Analysis
SDS6000L User Manual 29 Jitter Analysis 29.1 Overview Jitter — The time deviation from the ideal timing of a data-bit event — is one of the most important topics in high-speed digital data signals. The Jitter analysis application featured in this device can measure kinds of jitter features.
Page 267: Signal Configuration
SDS6000L User Manual Jitter Analysis Dialog Box A. Turn on/off the Jitter Analysis B. Set the display mode, including Waveform and Eye diagram C. The signal setting, including source and trigger level D. Quick view. After setting the channel source and performing a quick view, the oscilloscope will automatically adjust the vertical/horizontal scale and trigger level, the frequently-used measurement types...
Page 268: Clock Recovery
SDS6000L User Manual 29.3 Clock Recovery The setting of clock recovery is the same as Eye Diagram. Refer to the section "Clock Recovery" in the "Eye Diagram" chapter. 29.4 Jitter Decomposition Jitter typically consists of various jitter components that are caused by different jitter sources. For an analytical approach, a jitter model is frequently used, which splits jitter into two major categories of random and deterministic jitter.
Page 269: Jitter Measure
SDS6000L User Manual Click Jitter Decomposition to enter the jitter decomposition configuration menu. A. Set the pattern mode between Auto and Manual. In the Manual mode, the pattern length in bits, which represents the repetition period of the data sequence, can be set as user input.
Page 270 SDS6000L User Manual Table 29.1 Descriptions of jitter parameters Parameter Description Jitter Basics The time between the crossing points of two consecutive like-polarity Period edges. For clock data only. Frequency Reciprocal of the period. For clock data only. Time difference between the middle of a rising edge to the middle of +Width the next falling edge of the pulse.
Page 271 SDS6000L User Manual Random jitter (RJ) also called Gaussian jitter, is unpredictable electronic timing noise. RJ is caused by thermal noise in an electrical circuit or due to the central limit theorem. Random jitter is unbounded and commonly specified by the standard deviation σ. Due to its irregular nature, random jitter (RJ) is uncorrelated to any other signal and unpredictable in timing behavior.
Page 272: Other Operation
SDS6000L User Manual 29.6 Other Operation Some operations are supported under both the jitter analysis and normal mode. The compatible operations are similar to the eye diagram, take Table 28.5 as a reference. 29.7 System Effect on Jitter Measure The system's influence on the jitter measurement must be taken into consideration. It is important to evaluate the degree of error introduced in the jitter measurement according to the specifications of the measurement system itself.
Page 273: Display
SDS6000L User Manual 30 Display Display settings include display type of waveform, color, persistence, grid type, trace brightness, graticule brightness, etc. Click the menu Display > Menu to recall the display dialog box. A. Switch the waveform display type to Vectors (line display) or Dots B.
Page 274 SDS6000L User Manual Display Type There is no difference between the vector and dot display types when the number of samples of a frame is greater than 1250. When the sample number is below 1250, there are some differences.  Vectors: The samples are connected by lines (i.e.
Page 275 SDS6000L User Manual Note: In the Run state, due to the high waveform update rate of the oscilloscope, the waveform displayed is the superposition of multiple frames. Therefore, what is seen using the dots display is not the discrete sampling points, but the display effect similar to equivalent sampling. Stop the acquisition to view the original samples of each frame separately.
Page 276 SDS6000L User Manual Color grade On Color grade Off Set Persist With persistence, the oscilloscope updates the display with new acquisitions but does not erase the results of previous acquisitions in the specified period. All previous acquisitions are displayed with reduced intensity.
Page 277 SDS6000L User Manual  Infinite: Select “Infinite”, previous acquisitions will never be erased until a Clear Display operation is performed. Set Grid  Full Grid: Display 8*10 grid  Light Grid: Display 2*2 grid  No Grid: Display without grid Full Grid Light Grid i n t .
Page 278 SDS6000L User Manual No Grid Color Setting The color setting supports user-defined trace colors. Click the color rectangle box to set in the pop-up palette page. Click the Default area to restore the default color for all channels. 2 7 6 i n t .
Page 279 SDS6000L User Manual Select a color directly on the palette and preview its hue, saturation, light, and RGB values or directly modify the color parameters to customize the color. After the change, click OK to confirm. Axis Label Setting Turn on the axis label, the horizontal axis label will be displayed at the bottom of the grid, and the vertical axis label will be displayed at the left of the grid.
Page 280 SDS6000L User Manual Moving mode Fixed mode 2 7 8 i n t . s i g l e n t . c o m...
Page 281: Waveform Generator
SDS6000L User Manual 31 Waveform Generator 31.1 Overview The SDS6000L supports waveform/function generation by incorporating a built-in Waveform Generator accessory combined with the software activation using option SDS6000L-FG. The AWG functions include:  6 basic waveforms: Sine, Square, Ramp, Pulse, Noise, and DC ...
Page 282: Wave Type
SDS6000L User Manual 31.2 Wave Type The AWG function provides six standard waveforms and multiple arbitrary waveforms. The standard waveforms are Sine, Square, Ramp, Pulse, Noise, and DC. The following table shows all waveform types and corresponding parameters. Wave Type Parameters Sine Frequency, Amplitude, Offset...
Page 283: Other Setting
Common, Math, Engine, Window, and Trigo. Stored waveforms are located in the Stored menu. Users can edit arbitrary waveforms using SIGLENT EasyWaveX PC software, send the stored waveforms to the instrument through the remote interface, or import the stored waveforms through a U disk.
Page 284: System
SDS6000L User Manual Zero Adjust The output zero error of the AWG can be calibrated by using auto mode or manual mode. The object of the Zero Adjust is: when AWG outputs a 0 V DC signal, the measured mean value of the corresponding channel is within ±...
Page 285 SDS6000L User Manual Device Info – Includes Model, Serial Number, Firmware Version, and Hardware Version of the AWG module. Upgrade The firmware here refers to the firmware of the built-in AWG module. The SDS6000L supports firmware and configuration file upgrades for the AWG via a U disk. Follow the steps below: Copy the upgrade file (*.ADS) to the U disk.
Page 286: Save/Recall
SDS6000L User Manual 32 Save/Recall The SDS6000L supports saving setups, reference waveforms, screenshots, and waveform data files to internal storage, external USB storage devices (e.g. U disk), or network storage. Saved setups and reference waveforms can be recalled as needed. For details on network storage, refer to the section “Network Mapping”.
Page 287 SDS6000L User Manual Binary Data Saves the waveform data in binary (*.bin) format. CSV Data Saves the waveform data in ".csv" format. After selecting this type, you can click the ParaSwitch to determine whether to include the scope configuration parameter information (horizontal timebase, vertical scale, etc.) or not.
Page 288 SDS6000L User Manual The following table shows the relationship between the save types and save/recall operations. Type Save to External Recall √ √ Setup √ √ Reference √ × √ × √ × √ Binary Data × √ CSV Data ×...
Page 289: File Manager
SDS6000L User Manual 32.2 File Manager The SDS6000L's file manager has a similar style and operation to the Windows© operating systems. A. Address bar B. Navigation panel C. File list D. Toolbar E. File type Close the file manager Table 32.1 Description of icons in the file manager Icon Description Icon...
Page 290: Save And Recall Instances
SDS6000L User Manual Recall New directory New file Copy Paste Rename Delete 32.3 Save and Recall Instances Save the screenshot to the path “Udisk0\sds6l\” in the format of BMP First, Insert the U disk. Secondly, set the parameters of the Save operation: ...
Page 291 In step 4, if Save is selected instead of Save As , the system saves the file as the default file name SDS6xxxL_BMP_n.bmp, where n is an integer incrementing from 1. The default save path is \SIGLENT\. Note: When a file is saved successfully, a message will pop up to inform that it has been saved, and the filename of the next file to be saved is shown as well.
Page 292 SDS6000L User Manual Note: A saved picture can be browsed on the oscilloscope by opening it in the File Manager. Recall the setup file " Track.xml" stored in path “Udisk0\sds6l\” First, insert the U disk with the file " Track.xml" stored folder “\sds6l\”. Second, set the parameters of the Recall operation: ...
Page 293 SDS6000L User Manual Third, select the “ \Udisk0\sds6l\ ” directory in the file manager, and then select the setup file "Track.xml" Fourth, click the Recall icon and wait for the oscilloscope to finish recalling the setup. i n t . s i g l e n t . c o m 2 9 1...
Page 294: Utility
SDS6000L User Manual 33 Utility 33.1 System Information Operate Utility > Menu > System Info to check the system status. System information includes the contents shown below. 33.2 System Setting Language 33.2.1 The SDS6000L supports multiple languages, including Simplified Chinese, Traditional Chinese, English, French, Japanese, German, Spanish, Russian, Italian, Portuguese, and so on.
Page 295: Screen Saver
SDS6000L User Manual Screen Saver 33.2.2 The screen saver will be activated if the oscilloscope has not been operated for a period. At this time the output of the display is cut off to save power consumption. Operate Utility > Menu > System Setting > Screen Saver to specify the period before the screen saver activates, or select "Off"...
Page 296: Reference Position Setting
SDS6000L User Manual Click the text box of Hour, Minute, Second, Day, Month, and Year to edit these fields. Click the Modify Date/ Time button to perform the change. Click the text box of Time Zone to select the time zone.
Page 297 SDS6000L User Manual Vertical Ref  Fixed Offset: When the vertical scale is changed, the vertical offset remains fixed. As the vertical scale is changed, the waveform expands/contracts around the main X-axis of the display  Fixed Position: When the vertical scale is changed, the vertical offset remains fixed to the grid position on the display.
Page 298 SDS6000L User Manual Fixed position, timebase is changed to 5 ns/div, the grid number of delay (-2div) remains fixed, while the horizontal delay changes to -10 ns Fixed delay, timebase is changed to 5 ns/div, the horizontal delay value remains fixed, while the grid number of delay changes to -4div 2 9 6 i n t .
Page 299: Tips
SDS6000L User Manual Tips 33.2.7 When a file is saved successfully, a message will pop up to inform the user that the image has been saved. The Message box status can be set as shown below: Operate Utility > Menu > System Setting > Tips to open the tips dialog box: ...
Page 300: Clock Source
D. When is not checked, set the DNS IP address manually. E. When accessing more than two SIGLENT instruments through the web browser, it is necessary to set a different VNC port number for each instrument. The range is from 5900 to 5999.
Page 301: Install Options
SDS6000L User Manual 33.4 Install Options The SDS6000L provides a few options to enhance its functionality. Contact your local SIGLENT sales representative or SIGLENT technical support to get the corresponding option key. Perform the following steps to install the option: Utility >...
Page 302: Maintenance
SDS6000L User Manual 33.5 Maintenance Upgrade 33.5.1 The firmware is upgradeable through an external USB memory device/U disk. Make sure the U disk contains the correct upgrade file (*.ads) and is connected to the oscilloscope before performing the upgrade. Operate Utility > Menu > Maintenance > Upgrade to recall the upgrade dialog box: Click Browse to open the file manager, select the correct upgrade file and click the Recall icon 3 0 0 i n t .
Page 303: Self-Calibration
SDS6000L User Manual Click Upgrade in the upgrade dialog box to start the upgrade. The oscilloscope first copies the upgrade file (*.ads) to the local memory and parses it. If the parse succeeds, it will show the following dialog. Users can choose Cancel to cancel the upgrade or Reboot to restart the oscilloscope immediately and continue the upgrade.
Page 304: Developer Options
The oscilloscope will not respond to any operation until the self-cal is finished. After the self- cal is completed, click the screen to exit. Developer Options 33.5.3 This function is used for internal development by SIGLENT. 33.6 Service 33.6.1 The SDS6000L includes a web server function, you can access and control the oscilloscope using a web browser.
Page 305: Emulation
SDS6000L User Manual A. Network mapped drive letter. The default is I: B. Input the network storage directory in the text box. Check “Remember” to remember it. C. Check “Anonymous” to access the network directory in guest mode (Username: Guest, no password). This needs the server to permit anonymous access. D.
Page 306: Lxi
SDS6000L User Manual 33.6.4 This oscilloscope complies with LXI version 1.5, defined in LXI device specification 2016, which can be used to quickly build automated test systems. Click LXI to recall the LXI status box as below: Click LAN Reset to restore the LAN defaults to your oscilloscope. It will enable automatic IP, ICMP Ping responder, and Multicast DNS, and reset the webserver password which is set in Utility >...
Page 307: Share File
SDS6000L User Manual Share File 33.6.5 After setting the shared file, you can access the internal files of the device through Windows. Perform Utility > Menu > Service > Share File to open the share file dialog box: A. Set the working status of the share file. B.
Page 308: Troubleshooting
Check whether the power switch is on. Check whether the fuse is burned out. If the fuse needs to be changed, please contact SIGLENT timely and return the instrument to the factory for replacement by the maintenance personnel authorized by SIGLENT.
Page 309 Restart the instrument and then insert the USB storage device to check it. If the USB storage device still cannot be used normally, please contact SIGLENT. i n t . s i g l e n t . c o m...
Page 310 DC power supplies, electronic loads and other general purpose test instrumentation. Since its first oscilloscope was launched in 2005, SIGLENT has become the fastest growing manufacturer of digital oscilloscopes. We firmly believe that today SIGLENT is the best value in electronic test & measurement. Headquarters: SIGLENT Technologies Co., Ltd...

SIGLENT SDS6000L Series User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIGLENT SDS6000L Series

Summary of Contents for SIGLENT SDS6000L Series
