User Manual
SDS2000XSeriesDigital Oscilloscope
UM0102X-E01A
2015 SIGLENT TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDS2304X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIGLENT SDS2304X

Summary of Contents for SIGLENT SDS2304X

  • Page 1 User Manual SDS2000XSeriesDigital Oscilloscope UM0102X-E01A 2015 SIGLENT TECHNOLOGIES CO., LTD.
  • Page 3 Declaration SIGLENT products are protected by patent law in and outside of P.R.C. SIGLENT reserves the right to modify or change parts of or all the specifications or pricing policies at company‘s sole decision. Information in this publication replaces all previously corresponding material.

  • Page 4: Safety Information

    SIGLENT Safety Information General Safety Summary Carefully read the following safety precautions to avoid any personal injury or damage to the instrument and any products connected to it. To avoid potential hazards, please use the instrument as specified. Use Proper Power Cord Only the power cord designed for the instrument and authorized by local country should be used.
  • Page 5 If you suspect damage has occurred to the instrument, have it inspected by qualified service personnel before further operation. Any maintenance, adjustment or replacement especially to circuits or accessories must be performed by SIGLENT authorized personnel. Do Not Operate in Wet Conditions.

  • Page 6: Safety Terms And Symbols

    SIGLENT Safety Terms and Symbols Terms in this Manual. These terms may appear in this manual: WARNING Warning statements indicate the conditions or practices that could result in injury or loss of life. CAUTION Caution statements indicate the conditions or practices that could result in damage to this product or other property.

  • Page 7: Measurement Category

    SIGLENT Measurement Category Measurement Categories SDS2000X series digital oscilloscopes can make measurements in measurement category I. WARNING This oscilloscope can only be used for measurements within its specified measurement categories. Measurement Category Definitions Measurement category I is for measurements performed on circuits not directly connected to MAINS.

  • Page 8: Working Environment

    SIGLENT Working Environment Temperature Operating: 10℃ to +40℃ Non-operation:-20℃ to +60℃ Humidity Operating: 85%RH, 40℃, 24 hours Non-operating: 85%RH, 65℃, 24 hours WARNING To avoid short circuit inside the instrument or electric shock, please do not operate in humid environment.

  • Page 9: Ventilation Requirement

    SIGLENT Ventilation Requirement This oscilloscope uses fan-forced air cooling. Please make sure that the air intake and exhaust areas are free from obstructions and have adequate ventilation. When using the oscilloscope in a bench-top or rack setting, provide at least 10 cm clearance beside, above and behind the instrument for adequate ventilation.

  • Page 10: General Care And Cleaning

    SIGLENT General Care and Cleaning Care Do not store or leave the instrument in direct sunshine for long periods of time. WARNING To avoid damages to the instrument or probe, please do not leave them in fog, liquid, or solvents.

  • Page 11: Document Overview

    SIGLENT Document Overview This manual introduces how to use the SDS2000X series digital oscilloscope in detail. Quick Start Provide information about preparations before using the instrument and a brief introduction of the instrument. To Set the Vertical System Introduce the functions of the vertical system of the oscilloscope.
  • Page 12 SIGLENT Content Conventions in this Manual This manual uses the SDS2304X in examples and the descriptions shown list all the functions and performances of other models. SDS2000X series includes the following models: Model Analogy Bandwidth channels SDS2304X 300MHz SDS2204X 200MHz...

  • Page 13: Table Of Contents

    SIGLENT Table of Contents Copyright and Declaration ......................I Safety Information .......................... II General Safety Summary ......................II Safety Terms and Symbols ...................... IV Measurement Category ......................V Working Environment ......................VI Ventilation Requirement ......................VII General Care and Cleaning ....................VIII Document Overview ........................
  • Page 14 SIGLENT To Specify Amplitude Unit ...................... 28 To Invert a Waveform ......................28 Set the Horizontal System ......................29 Adjust the Horizontal Scale ..................... 30 Adjust Trigger Delay ........................ 31 Set the Roll mode ........................32 Use the Zoom Function ......................33 To Set the Sample System ......................
  • Page 15 SIGLENT IIC Serial Decode ......................83 SPI Triggering and Serial Decode ..................... 85 Setup for SPI Signals ....................85 SPI Triggering ....................... 88 SPI Serial Decode ......................90 UART/RS232 Triggering and Serial Decode................92 Setup for UART/RS232 Signals ................. 92 UART/RS232 Triggering ....................
  • Page 16 SIGLENT Display Setting ..........................127 To Set Display Type ........................ 128 To Set Color Display ....................... 129 To Set and Clear Persistence ....................129 To clear the display ........................ 130 To Select Grid Type ....................... 131 To Adjust Waveform Intensity ....................131 To Adjust Grid Brightness ......................
  • Page 17 SIGLENT Default Setup ..........................170 Troubleshooting ..........................176 SDS2000XUser Manual XV...
  • Page 18 SIGLENT Content of Figure Figure 1 Front View ........................3 Figure 2 Top View ........................3 Figure 3 Adjust the Supporting Legs ..................4 Figure 4 To Connect to Power Supply ..................5 Figure 5 Function Inspection ..................... 8 Figure 6 Front Panel Overview ....................10 Figure 7 Rear panel Overview ....................
  • Page 19 SIGLENT Figure 43 SPI TRIG SET Menu ....................88 Figure 44 SPI Trigger ........................ 89 Figure 47 SPI Decode function menu ..................90 Figure 46 SPI Decode ......................90 Figure 47 UART SIGNAL Menu ....................92 Figure 48 BUS CONFIG Menu ....................92 Figure 49 UART TRIG SET Menu ....................
  • Page 20 SIGLENT Figure 87 Option Information ....................161 Figure 88 History ........................162 Figure 89 Send Wave Dialogue ..................... 167 Figure 90 Save Waveform Successfully ................. 167 Figure 91 SETTING Function Menu ..................168 Figure 92 AWG Self Cal ......................169...

  • Page 21: Quick Start

    SIGLENT Quick Start This chapter introduces the preparations when using the oscilloscope for the first time, the front panel, rear panel and user interface of the oscilloscope, The contents of this chapter:  General Inspection  Appearance and Dimensions  To Prepare the Oscilloscope for Use ...

  • Page 22: General Inspection

    The consigner or carrier will be responsible for damages to the instrument resulting from shipment. SIGLENT does not provide free maintenance or replacement if the instrument has been damaged in shipment. 2. Inspect the instrument.

  • Page 23: Appearance And Dimensions

    SIGLENT Appearance and Dimensions 352mm Figure 1: Front View Figure 2:Top View SDS2000X User Manual 3...

  • Page 24: To Prepare The Oscilloscope For Use

    SIGLENT To Prepare the Oscilloscope for Use To Adjust the Supporting Legs Adjust the supporting legs properly to use them as stands to tilt the oscilloscope upwards for stable placement of the oscilloscope as well as better operation and observation.

  • Page 25: To Connect To Power Supply

    SIGLENT To Connect to Power Supply The oscilloscope will accept a 100~240V, 50/60Hz or 100~120V, 400Hz AC power supply. Please use the power cord provided with the accessories to connect the instrument to the power source as shown in the figure below.

  • Page 26: Power-On Inspection

    SIGLENT Power-on Inspection When the oscilloscope is energized, press the power key at the lower-left corner of the front panel to start the oscilloscope. During the start-up process, the oscilloscope performs a series of self-tests and you can hear the sound of relay switching. After the self-test is finished, the welcome screen is displayed.

  • Page 27: To Connect The Probe

    SIGLENT To Connect the Probe SIGLENT provides passive probes for the SDS2000X series oscilloscopes. For detailed technical information of the probes, please refer to the corresponding Probe User‘s Guide. Connect the Probe: 1. Connect the BNC terminal of the probe to one of the channel BNC connectors on the front panel.

  • Page 28: Functional Inspection

    SIGLENT Functional Inspection 1. Press the Default button on the front panel to restore the instrument to its factory default configuration. 2. Connect the ground alligator clip of the probe to the ―Ground Terminal‖ under the probe compensation signal output terminal.

  • Page 29: Probe Compensation

    SIGLENT Probe Compensation All oscilloscope probes should be properly compensated before their first use with the oscilloscope. Non-compensated or inadequate compensated probe may cause measurement inaccuracy or error. The probe compensation procedures are as follows. 1. Set the switch to 10X on the probe.

  • Page 30: Front Panel Overview

    SIGLENT Front Panel Overview Figure 6:Front Panel Overview NO. Description NO. Description Horizontal Control Function Menus Auto Setup WaveGen Control Run/Stop Vertical Control for Analog Channels Default Setup WaveGen Output Probe Compensation/ Ground Clear Sweeps Terminal Universal Knob USB Host...

  • Page 31: Rear Panel Overview

    SIGLENT Rear Panel Overview Figure 7: Rear panel Overview 1. Handle Pull up the handle vertically for easy carrying of the instrument. When you do not need the handle, press it down. 2. LAN The instrument can be connected to a user-network via this interface to perform remote control.

  • Page 32: Front Panel Overview

    SIGLENT Front Panel Overview Horizontal Quickly enter the roll mode. The timebase range is from 50ms/div to 50s/div. Press the button to open the Zoom function and press again to close the function. Horizontal Position Knob: Sets the horizontal location of the trigger event on the display.

  • Page 33: Vertical

    SIGLENT Vertical Analog input channels. The four channels are marked by different colors which are also used to mark both the waveforms on the screen and the channel input connectors. Press channel button to open the corresponding channel and press again to turn it off.
  • Page 34 SIGLENT Press this button to open decode menu. Decode is an optional function. SDS2000X supports two serial buses including 1 and 2 for analog signal decoding. The protocols include I2C,SPI, UART/RS232, CAN and LIN. Press the button to open the digital channel function menu (Optional function).

  • Page 35: Trigger

    SIGLENT Trigger : Pressthe button to open trigger menu. This oscilloscope provides various trigger types: Edge, Slope, Pulse, Video, Window, Interval, Dropout, Runt, Pattern and Serial Bus (I2C/SPI/UART/RS232/CAN/LIN). Press the button to set to Auto trigger mode. Press the button to set to Normal trigger mode.

  • Page 36: Run Control

    SIGLENT Run Control Press the button to enable the waveform auto setup function. The oscilloscope will automatically adjust the horizontal time base, vertical scale and trigger mode according to the input signal to provide a triggered stable display. Press the button to set the state of the instrument to ―RUN‖ or ―STOP‖. In the ―RUN‖...

  • Page 37: Universal Knob

    SIGLENT Universal Knob 1. Adjust the waveform intensity In non-menu-operation mode, (menu is hidden), turn this knob to adjust waveform intensity (0% ~ 100%). Turn clockwise to increase the brightness and counterclockwise to reduce. You can also press Display/Persist→Intensity and use the knob to do adjusting.

  • Page 38: Menu

    SIGLENT Menu Press the button to open the cursor function. It provides manual and tracking cursor modes. Press the button to enter the sampling menu. From here the acquisition mode can be set (Normal/Peak-Detect/Average/Eres), interpolation mode (Sinx/x or linear)and memory depth. The XY mode can be selected here as well as the Sequence function.

  • Page 39: Help

    SIGLENT Help The SDS2000X has an on line help function that supplies multi-language help information, and you can recall then to help you operate the oscilloscope when you need. Press any button for 2 seconds to enter the on line help. All submenus of every main menu have their help information.

  • Page 40: User Interface

    User Interface Figure 9: User Interface 1. Product Logo SIGLENT is the registered trademark of SIGLENT TECHNOLOGIES CO., LTD. 2. Channel Label/Waveform Different channels are marked by different colors and the color of the waveform matches with the color of the channel.
  • Page 41 SIGLENT 6. Trigger Position Label Display the trigger position of the waveform on the screen. 7. Frequency Counter Display the frequency of current waveform as trigger source. 8. Sampling Rate/ Memory Depth Display the current sample rate and memory depth of the oscilloscope. Use the Horizontal scale knob to modify the parameters.

  • Page 42: To Use The Security Lock

    SIGLENT To Use the Security Lock Provisions for a Kensington-style lock are provided on the rear panel of the SDS2000X (Lock is not included). To use, align the lock with the lock hole and insert, turn the key clockwise to lock the instrument and then remove the key from the lock.

  • Page 43: To Set The Vertical System

    SIGLENT To Set the Vertical System This chapter introduces how to set the vertical system of the oscilloscope. The contents of this chapter:  To Enable the Channel  To Adjust the Vertical Scale  To Adjust the Vertical Position ...

  • Page 44: To Enable The Channel

    SIGLENT To Enable the Channel SDS2000X provides 2/4analog input channels (CH1, CH2, CH3, CH4) and provides independent vertical control system for each channel. As the vertical system setting methods of both channels are the same, this chapter takes CH1 as an example to introduce the setting method of the vertical system.

  • Page 45: To Adjust The Vertical Scale

    SIGLENT To Adjust the Vertical Scale The vertical scale can be adjusted in Coarse or Fine mode.  Coarse adjustment (turning counterclockwise as an example): set the vertical scale in 1-2-5 step namely 1mv/div,2 mV/div, 5 mV/div, 10 mV/div …10 V/div.

  • Page 46: To Specify Channel Coupling

    SIGLENT To Specify Channel Coupling Set the coupling mode to filter out the undesired signals. For example, the signal under test is a square waveform with DC offset.  When the coupling mode set to DC: the DC and AC components of the signal under test can both pass the channel.

  • Page 47: To Specify Probe Attenuation Factor

    SIGLENT To Specify Probe Attenuation Factor Set the probe attenuation factor to match the type of the probe that you are using to ensure correct vertical readouts. Press theCH1 button on the front panel; then press the Probe softkey and turn the Universal Knob to select the desired value and push the knob to confirm.

  • Page 48: To Specify Amplitude Unit

    SIGLENT To Specify Amplitude Unit Select the amplitude display unit for the current channel. The available units are V and A. When the unit is changed, the unit displayed in the channel label will change accordingly. 1. Press CH1button on the front panel to enter the CH1 function menu.

  • Page 49: Set The Horizontal System

    SIGLENT Set the Horizontal System This chapter introduces how to set the horizontal system of the oscilloscope. The contents of this chapter:  Adjust the Horizontal Scale  Adjust the Trigger Delay  Set Roll Mode  Use the Zoom Function...

  • Page 50: Adjust The Horizontal Scale

    SIGLENT Adjust the Horizontal Scale Turn the HORIZONTAL Scale Knob on the front panel to adjust the horizontal time base. Turn clockwise to reduce the horizontal time base and turn counterclockwise to increase. The time base information at the upper left corner of the screen will change accordingly during the adjustment.

  • Page 51: Adjust Trigger Delay

    SIGLENT Adjust Trigger Delay Turn the Position Knob on the front panel to adjust the trigger delay of the waveform. During the modification, waveforms of all the channels will move left or right and the trigger delay message at the upper-right corner of the screen changes accordingly. Press down this knob to quickly reset the trigger delay.

  • Page 52: Set The Roll Mode

    SIGLENT Set the Roll mode Press the Roll button to enter the roll mode. In Roll mode the waveform moves slowly across the screen from right to left. It operates only on time base settings of 50 ms/div and slower. If the current time base setting is faster than the 50 ms/div limit, it will be set to 50 ms/div when Roll mode is entered.

  • Page 53: Use The Zoom Function

    SIGLENT Use the Zoom Function Zoom is a horizontally expanded version of the normal display. You can use Zoom to locate and horizontally expand part of the normal window for a more detailed (higher-resolution) analysis of signals. Press the HORIZONTAL Scale Knob on the front panel to turn on the zoom function, and press the button again to turn off the function.

  • Page 54: To Set The Sample System

    SIGLENT To Set the Sample System This chapter introduces how to use the run control and set the sampling system of the oscilloscope. The contents of this chapter:  Run Control  Overview of Sampling  To Specify Memory Depth ...

  • Page 55: Run Control

    SIGLENT Run Control Press the Run/Stop or Single button on the front panel to run or stop the sampling system of the scope.  When the Run/Stop is green, the oscilloscope is running, that is, acquiring data when trigger conditions are met. To stop acquiring data, press the Run/Stop button.

  • Page 56: Overview Of Sampling

    SIGLENT Overview of Sampling To understand the oscilloscope's sampling and acquisition modes, it is helpful to understand sampling theory, sample rate and oscilloscope bandwidth and sample rate. Sampling Theory The Nyquist sampling theorem states that for a limited bandwidth (band-limited) signal...

  • Page 57: Sample Rate

    SIGLENT Sample Rate The maximum sample rate of SDS2000X is 2GSa/s. The actual sample rate of the oscilloscope is determined by the horizontal scale. Turn the Horizontal Scale Knob to adjust the sample rate. The current sample rate is displayed in the information area at the upper-right corner of the screen.

  • Page 58: Oscilloscope Bandwidth And Sample Rate

    SIGLENT Oscilloscope Bandwidth and Sample Rate An oscilloscope's bandwidth is typically described as the lowest frequency at which input signal sine waves are attenuated by 3 dB (-30% amplitude error). At the oscilloscope bandwidth, sampling theory says the required sample rate is f...

  • Page 59: Select Memory Depth

    SIGLENT Select Memory Depth Memory depth refers to the number of waveform points that the oscilloscope can store in a single trigger sample and it reflects the storage ability of the sample memory. SDS2000X provides up to 140 Mpts memory depth.

  • Page 60: Select Sampling Mode

    SIGLENT Select Sampling Mode SDS2000Xonly supports real-time sampling. In this mode, the oscilloscope samples and displays waveform within a trigger event. The maximum real-time sample rate of SDS2000Xis 2GSa/s. Press the RUN/STOP button to stop the sample, the oscilloscope will hold the last display.

  • Page 61: Select Waveform Interpolation Method

    SIGLENT Select Waveform Interpolation Method Under real-time sampling, the oscilloscope acquires the discrete sample values of the waveform being displayed. In general, a waveform of dots display type is very difficult to observe. In order to increase the visibility of the signal, the digital oscilloscope usually uses the interpolation method to display a waveform.
  • Page 62 SIGLENT Figure 12: x Interpolation Figure 13:Sinx Interpolation 42 SDS2000X User Manual...

  • Page 63: Select Acquisition Mode

    SIGLENT Select Acquisition Mode The acquisition mode is used to control how to generate waveform points from sampled points.SDS2000X provides the following acquisition mode: Normal, Peak Detect, Average and Eres. 1. Press the Acquire button on the front panel to enter the ACQUIRE function menu;...

  • Page 64: Peak Detect

    SIGLENT Peak Detect In this mode, the oscilloscope acquires the maximum and minimum values of the signal within the sample interval to get the envelope of the signal or the narrow pulse of the signal that might be lost. In this mode, signal aliasing can be prevented but the noise displayed would be larger.

  • Page 65: Average

    SIGLENT Average In this mode, the oscilloscope averages the waveforms from multiple frames to reduce the random noise of the input signal and improve the vertical resolution. The greater the number of averages is, the lower the noise will be and the higher the vertical resolution will be but the slower the response of the displayed waveform to the waveform changes will The available range of averages is from 4 to1024 with a default value of16.

  • Page 66: Eres (Enhanced Resolution)

    SIGLENT Figure 18:With Random Noise, Average Mode Eres (Enhanced Resolution) This mode uses a digital filter to reduce the random noise on the input signal and generate much smoother waveforms on the screen. Eres can be used on both single-shot and repetitive signals and it does not slow down waveform update.

  • Page 67: Change The Horizontal Format

    SIGLENT Change the Horizontal Format Press the Acquire button on the front panel; then press the XY soft key to set the XY(On) or YT(Off) mode. The default setup is YT(Off). It is the normal viewing mode for the oscilloscope. In the Normal time mode, signal events occurring before the trigger are plotted to the left of the trigger point and signal events after the trigger plotted to the right of the trigger point.

  • Page 68: Use Sequence Mode

    SIGLENT Use Sequence Mode Sequence does not display the waveform during sampling process. It improves the waveform capture rate, and the maximal capture rate is about 500,000 wfm/s. So it can capture the small probability event effectively. The oscilloscope keeps running and filling data memory in segments for each trigger event, unit the memory is full, and then display all the waveforms on the screen.
  • Page 69 SIGLENT 4. Press the softkey to replay the waveform from the current frame to 1. 5. Press the softkey to pause the replay. 6. Press the softkey to replay the waveform from the current frame to the last frame. SDS2000X User Manual 49...

  • Page 70: To Trigger The Oscilloscope

    SIGLENT To Trigger the Oscilloscope To trigger an oscilloscope you set certain trigger condition according to the requirement and when a waveform in the waveform stream meets this condition, the oscilloscope captures this waveform as well as some amount of time before and/or after the event and displays it on the screen.
  • Page 71 SIGLENT The contents of this chapter:  Trigger Source  Trigger Mode  Trigger Level  Trigger Coupling  Trigger Holdoff  Noise Rejection  Trigger Type  Edge Trigger  Slope Trigger  Pulse Trigger  Video Trigger ...

  • Page 72: Trigger Source

    SIGLENT Trigger Source SDS2000X trigger source includes analog channels (CH1, CH2, CH3, CH4), EXT, EXT/5 and AC Line. Press the Setup button on the front panel to enter the TRIGGER function menu; press the Source softkey and then turn the Universal Knob to select the desired trigger source.

  • Page 73: Trigger Mode

    SIGLENT Trigger Mode SDS2000X trigger modes include Auto, Normal and Single. Trigger mode affects the way in which the oscilloscope searches for the trigger After the oscilloscope begins to capture data, the oscilloscope operates by first filling the pre-trigger buffer. It starts searching for a trigger after the pre-trigger buffer is filled and continues to flow data through this buffer while it searches for the trigger.

  • Page 74: Trigger Level

    SIGLENT Trigger Level Trigger level and slope define the trigger point, Positive Slope Negative Slope Trigger Level Trigger Point Trigger Point Input Signal The trigger level can be adjusted for a selected analog channel by turning the Trigger Level Knob.

  • Page 75: Trigger Coupling

    SIGLENT Trigger Coupling Press the Setup button on the front panel to enter the TRIGGER function menu, and then press the Coupling softkey and turn the Universal Knob or press the Coupling softkey continually to select the desired coupling mode.

  • Page 76: Trigger Holdoff

    SIGLENT Trigger Holdoff Trigger holdoff can be used to stabilize the triggering of complex waveforms (such as pulse series). Holdoff time is the amount of time that the oscilloscope waits before re-arming the trigger circuitry. The oscilloscope will not trigger until the holdoff time expires.

  • Page 77: Noise Rejection

    SIGLENT Noise Rejection Noise Reject adds additional hysteresis to the trigger circuitry. By increasing the trigger hysteresis band, you reduce the possibility of triggering on noise. However, this also decreases the trigger sensitivity so that a slightly larger signal is required to trigger the oscilloscope.

  • Page 78: Trigger Type

    SIGLENT If the signal you are probing is noisy, you can set up the oscilloscope to reduce the noise in the trigger path and on the displayed waveform. First, stabilize the displayed waveform by removing the noise from the trigger path. Second, reduce the noise on the displayed waveform.

  • Page 79: Edge Trigger

    SIGLENT Edge Trigger Edge trigger distinguishes the trigger points by seeking the specified edge (rising, falling, rising & falling) and trigger level. Rising Edge Falling Edge Trigger Level Trigger Point Trigger Point 1. Press the Setup button on the front panel to enter the Trigger system function menu.

  • Page 80: Slope Trigger

    SIGLENT Slope Trigger The slope trigger looks for a rising or falling transition from one level to another level in the specified time range. In SDS2000X, positive slope time is defined as the time difference between the two crossing points of trigger level line A and B with the positive edge as shown in the figure below.
  • Page 81 SIGLENT 5. Press the Limit Range softkey; then turn the Universal Knob to select the desired slope condition, and push down the knob to confirm.  < (less than a time value):trigger when the positive or negative slope time of the input signal is lower than the specified time value.

  • Page 82: Pulse Trigger

    SIGLENT Pulse Trigger Trigger on the positive or negative pulse with a specified width. Positive Pulse Width Trigger Level Negative Pulse Width 1. Press the Setup button on the front panel to enter the TRIGGER function menu. 2. Press the Type softkey; turn the Universal Knob to select Pulse and then push the knob to confirm.
  • Page 83 SIGLENT  [--,--](within a range of time value):trigger when the positive or negative pulse time of the input signal is greater than the specified lower limit of time and lower than the specified upper limit of time value. For example, for a positive pulse, if you set t (pulse real width) >100ns and t<300ns, the waveform will trigger.

  • Page 84: Video Trigger

    SIGLENT Video Trigger Video triggering can be used to capture the complicated waveforms of most standard analog video signals. The trigger circuitry detects the vertical and horizontal interval of the waveform and produces triggers based on the video trigger settings you have selected.SDS2000X supports standard video signal field or line of NTSC (National...
  • Page 85 SIGLENT The table below takes Of Lines as 800 as an example to explain the relation between Of Lines, Of Fields, Interlace, Trigger Line and Trigger Field. Of Lines Of Fields Interlace Trigger Line Trigger Field 1,2,4 or 8 1, 1~2, 1~4, 1~8...
  • Page 86 SIGLENT Figure 27: Video Trigger To Use Custom Video Trigger Custom video trigger supports frame rate of 25Hz, 30Hz, 50Hz and 60Hz, and the line range is available from 300 to 2000. The steps below show how to set custom trigger.

  • Page 87: Window Trigger

    SIGLENT Window Trigger Windows trigger provides a high trigger level and a low trigger level. The instrument triggers when the input signal passes through the high trigger level or the low trigger level. There are two kinds of window types; Absolute and Relative. They have different trigger level adjustment methods.
  • Page 88 SIGLENT Figure 28:Absolute Window Trigger To set window trigger via Relative window type: 1. Press the Setup button on the front panel to enter the TRIGGER system function menu. 2. Press the Type softkey; then use the Universal Knob to select Window and push down the knob to confirm.
  • Page 89 SIGLENT Figure 29: Relative Window Trigger SDS2000X User Manual 69...

  • Page 90: Interval Trigger

    SIGLENT Interval Trigger Trigger when the time difference between the neighboring rising or falling edges meets the time limit condition (<, >, [--,--], --][--). Trigger Trigger To set interval trigger: 1. Press the Setup button on the front panel to enter the TRIGGER system function menu.
  • Page 91 SIGLENT Figure 30: Interval Trigger SDS2000X User Manual 71...

  • Page 92: Dropout Trigger

    SIGLENT DropOut Trigger DropOut trigger includes two types: edge and state. Edge Trigger when the time interval (△T) from when the rising edge (or falling edge) of the input signal passes through the trigger level to when the neighboring rising edge (or falling edge) passes through the trigger level is greater than the timeout time set, as shown in the figure below.
  • Page 93 SIGLENT Figure 31:Edge DropOut Trigger To set state DropOut trigger: 1. Press the Setup button to enter the TRIGGER system function menu. 2. Press the Type softkey; then turn the Universal Knob to select DropOut and push down the knob to confirm.

  • Page 94: Runt Trigger

    SIGLENT Runt Trigger The Runt trigger looks for pulses that cross one threshold but not another as shown in the picture below. Positive runt pulse High level Low level Negative runt pulse  A positive runt pulse across through a lower threshold but not an upper threshold.
  • Page 95 SIGLENT Figure 33: Runt Trigger SDS2000X User Manual 75...

  • Page 96: Pattern Trigger

    SIGLENT Pattern Trigger The Pattern trigger identifies a trigger condition by looking for a specified pattern. The pattern trigger can be expanded to incorporate delays similar to other triggers. Pattern durations are evaluated using a timer. The timer starts on the last edge that makes the pattern ―true‖.
  • Page 97 SIGLENT  >(Greater Than) – when the pattern is present for greater than a time value. The trigger occurs  [--,--](In Range) – when the pattern is present for a time within a range of values.  --][-- (Out of Range) – when the pattern is present for a time outside of range of values.

  • Page 98: Serial Trigger And Decode

    SIGLENT Serial Trigger and Decode SDS2000X provides IIC, SPI, UART/RS232, CAN and LIN serial trigger and decode. This chapter introduces how to set every type of serial trigger and decode in details. The contents of this chapter:  IIC Trigger and Decoder ...

  • Page 99: Iic Trigger And Serial Decode

    SIGLENT IIC Trigger and Serial Decode Please take the order of ―Setup for IIC Signals‖, ―IIC Triggering‖ and ―IIC Decode‖ to trigger and decode the signals. Setup for IIC Signals IIC (Inter-IC bus) signals setup consists of connecting the oscilloscope to the serial data (SDA) line and the serial clock (SCL) line and then specifying the input signal threshold voltage levels.

  • Page 100: Iic Triggering

    SIGLENT IIC Triggering After the oscilloscope has been set up to capture IIC signals, you can trigger on a stop/start condition, a restart, a missing acknowledge, an EEPROM data read, a read/write frame with a specific device address and data value, or on a data length.
  • Page 101 SIGLENT  7-bit Address & Data Condition —The oscilloscope triggers on a read or write frame in 7-bit addressing mode on the 17th or the 26th clock edge if all bits in the pattern match. For triggering purposes, a restart is treated as a start condition...
  • Page 102 SIGLENT  Data Length — The oscilloscope triggers when the SDA data length is equal to the value set in the Byte Length softkey. 4. If you have set the oscilloscope to trigger on an EEPROM Data Read condition: Press the LimitRange softkey to set the oscilloscope to trigger when data is = (equal to), <...

  • Page 103: Iic Serial Decode

    SIGLENT IIC Serial Decode To set up IIC serial decode: 1. Press Decode to display the Decode function menu. Figure 37: IIC Decode Menu 2. Press the Address softkey to choose 7 bit or 10 bit address size. 3. Press the Display softkey and choose On to display the decode line on the display.
  • Page 104 SIGLENT Interpreting IIC Decode  Actived waveforms show an active bus (inside a packet/frame).  Mid-level blue lines show an idle bus.  In the decoded hexadecimal data:  Address values appear at the start of a frame.  Write addresses appear in dark-green along with the "W" character.

  • Page 105: Spi Triggering And Serial Decode

    SIGLENT SPI Triggering and Serial Decode Please note the order of ―Setup for SPISignals‖, ―SPITriggering‖and ―SPIDecode‖ to trigger and decode the signals. Setup for SPI Signals Serial Peripheral Interface (SPI) signals setup consists of connecting the oscilloscope to a clock, MOSI data, MISO data, and framing signal, then setting the threshold voltage level for each input channel, and finally specifying any other signal parameters.
  • Page 106 SIGLENT In the MISO menu: a. Press the MISO softkey; then, turn the Universal Knob to select the channel that is connected to a second SPI serial data line. (If the channel you selected is off, switch it on.) b. Press the Threshold softkey; then, turn the Universal Knob to select the MISO signal threshold voltage level.
  • Page 107 SIGLENT the Limit softkey and turn the Universal Knob to set the minimum time that the Clock signal must be idle (not transitioning) before the oscilloscope will search for the Data pattern on which to trigger. The Limit value can be set anywhere from 100 ns to 1 s.

  • Page 108: Spi Triggering

    SIGLENT SPI Triggering After the oscilloscope has been set up to capture SPI signals, you can then trigger on a data pattern that occurs at the start of a frame. The serial data string can be specified to be from 4 to 96 bits long.
  • Page 109 SIGLENT Figure 45: SPI Trigger SDS2000X User Manual 89...

  • Page 110: Spi Serial Decode

    SIGLENT SPI Serial Decode To set up SPI serial decode: 1. Press Decode to display the Decode function menu. Figure 46: SPI Decode function menu 2. Press the Data Length softkey, then, turn the Universal Knob to set the bit number of the SPI decoded data.
  • Page 111 SIGLENT Interpreting SPI Decode  Actived waveforms show an active bus (inside a packet/frame).  Mid-level blue lines show an idle bus.  The number of clocks in a frame appears in light-blue above the frame, to the right. ...

  • Page 112: Uart/Rs232 Triggering And Serial Decode

    SIGLENT UART/RS232 Triggering and Serial Decode Please note the order of ―Setup for UART/RS232 Signals”, “UART/RS232Triggering‖ and ―UART/RS232Decode‖ to trigger and decode the signals. Setup for UART/RS232 Signals To set up the oscilloscope to capture UART/RS232 signals: 1. Press Decode on the front panel to turn on the Decode function menu.

  • Page 113: Uart/Rs232 Triggering

    SIGLENT UART/RS232 Triggering To trigger on a UART (Universal Asynchronous Receiver/Transmitter) signal connect the oscilloscope to the RX and TX lines and set up a trigger condition. RS232 (Recommended Standard 232) is one example of a UART protocol. 1. Press Setup button on the front panel to enter the TRIGGER function menu.

  • Page 114: Uart/Rs232 Serial Decode

    SIGLENT UART/RS232 Serial Decode To set up UART/RS232 serial decode: 1. Press Decode button on the front panel to display the Decode function menu. Figure 52: UART/RE232 Decode Function Menu 2. Press the Display softkey and choose On to display the decode line on the display.
  • Page 115 SIGLENT Interpreting UART/RS232 Decode  Actived waveforms show an active bus (inside a packet/frame).  Mid-level blue lines show an idle bus.  Mid-level red lines show that the idle level is wrong.  The decoded data is displayed in white.

  • Page 116: Can Trigger And Serial Decode

    SIGLENT CAN Trigger and Serial Decode Please take the order of ―Setup for CAN Signals‖, ―CAN Triggering‖ and ―CAN Decode‖ to trigger and decode the signals. Setup for CAN Signals Setup consists of connecting the oscilloscope to a CAN signal, using the SINGAL menu to specify the signal source, threshold voltage level, baud rate, and sample point.

  • Page 117: Can Triggering

    SIGLENT CAN Triggering After setting up the oscilloscope to capture a CAN signal: 1. Press Setup button the front panel to enter the TRIGGER function menu. 2. Press the Type softkey; then, turn the Universal Knob to select the ―serial‖ and press the Protocol softkey to select ―CAN‖.
  • Page 118 SIGLENT Figure 55 CAN Trigger 98 SDS2000X User Manual...

  • Page 119: Can Serial Decode

    SIGLENT CAN Serial Decode To set up CAN serial decode: 1. Press Decode to display the DECODE function menu. 2. Press the Display softkey and choose On to display the decode line on the display. 3. Press the List softkey to enter the LIST function menu.
  • Page 120 SIGLENT Interpreting CAN Decode.  Data bytes appear in hex digits in white  Cyclic redundancy check (CRC) appears in hex digits in blue when valid, or in red to indicate that the oscilloscope's hardware decode calculated a CRC that is different from the incoming CRC data stream.

  • Page 121: Lin Triggering And Serial Decode

    SIGLENT LIN Triggering and Serial Decode Please take the order of ―Setup for LIN Signals‖, ―LIN Triggering‖ and ―LIN Decode‖ to trigger and decode the signals. Setup for LIN Signals LIN (Local Interconnect Network) signal setup consists of connecting the oscilloscope to a serial LIN signal, specifying the signal source, threshold voltage level, baud rate, sample point, and other LIN signal parameters.

  • Page 122: Lin Triggering

    SIGLENT LIN Triggering LIN triggering can trigger on the rising edge at the Sync Break exit of the LIN single-wire bus signal (that marks the beginning of the message frame), the Frame ID, or the Frame ID and Data. A LIN signal message frame is shown below: 1.

  • Page 123: Lin Serial Decode

    SIGLENT LIN Serial Decode To set up LIN serial decode: 1. Press Decode button on the front panel to display the DECODE function menu. Figure 59 LIN DECODE Function Menu 2. Press the Display softkey and choose On to display the decode line on the display.
  • Page 124 SIGLENT Interpreting LIN Decode  Angled waveforms show an active bus (inside a packet/frame).  Mid- level blue lines show an idle bus.  The hexadecimal ID and parity bits (if enabled) appear in yellow. If a parity error is detected the hexadecimal ID and parity bits (if enabled) appear in red.

  • Page 125: To Save Reference Waveform

    SIGLENT To Save Reference Waveform SDS2000X can save analog channel or math waveforms to one of four reference waveform locations in the oscilloscope. Then, a reference waveform can be displayed and compared against other waveforms. Four reference waveforms can be displayed at a time.

  • Page 126: To Save Ref Waveform To Internal Memory

    SIGLENT To Save REF Waveform to Internal Memory Do the following steps to save the REF waveform to internal memory: 1. Press the REF button on the front to enter the REF WAVE function menu. Note that when the time horizontal format is in X-Y mode, REF function cannot be enabled.

  • Page 127: To Adjust Ref Waveform Display

    SIGLENT To Adjust REF Waveform Display 1. Please refer to the ―To Display REF Waveform‖ above to display the desired reference waveform. 2. Use the Vertical Scale knob and Vertical Position knob for Math/Ref to adjust the vertical scale and position of the reference waveform. The vertical scale and position information displays at the middle of the screen.

  • Page 128: To Use The Math Operation

    SIGLENT To Use the Math Operation SDS2000X supports many math operations between analog channels and reference waveforms, including addition (+), subtraction (-), multiplication (*), division (/), differential (d/dt), integral (∫dt), square root (√). The resulting math waveform is displayed in white and labeled with ―M‖.

  • Page 129: Math Operators

    SIGLENT Math Operators SDS2000X supports math count operation (Addition, subtraction, multiplication, division), FFT (Fourier transform) operation and math function operation (differential, integral, square root). Addition or Subtraction Math operators perform arithmetic operations - add or subtract operation - on any two analog input channels.

  • Page 130: Multiplication And Division

    SIGLENT Multiplication and Division Math operators perform arithmetic operations multiplication or division operation on any two analog input channels. When you select multiplication or division, the Source A and Source B values are multiplied or divided point by point and the result is displayed.

  • Page 131: Fft Operation

    SIGLENT FFT Operation FFT is used to compute the fast Fourier transform using analog input channels or reference waveforms. FFT takes the digitized time record of the specified source and transforms it to the frequency domain. When the FFT function is selected, the FFT spectrum is plotted on the oscilloscope display as magnitude in dBV versus frequency.
  • Page 132 SIGLENT To display a FFT waveform: 1. Press the Math button on the front panel to open the MATH function menu. 2. Press the Operation softkey and then turn the Universal Knob to select FFT. The resulting math waveform is displayed in white and labeled with ―M‖.
  • Page 133 SIGLENT  Full Screen: the source channel and the FFT operation results are displayed in the same window to view the frequency spectrum more clearly and to perform more precise measurements. Figure 64: FFT Waveform In Split Mode Note: ...

  • Page 134: Math Function Operation

    SIGLENT Math Function Operation SDS2000X supports math function operation including differential (d/dt), integral (∫dt) and square root (√). Differentiate d/dt (differentiate) calculates the discrete time derivative of the selected source. Where:  d = differential waveform.  y = channel 1, 2, 3, or 4 data points.

  • Page 135: Integrate

    SIGLENT Integrate dt (integrate) calculates the integral of the selected source. You can use integrate to calculate the energy of a pulse in volt-seconds or measure the area under a waveform. dt plots the integral of the source using the "Trapezoidal Rule". The equation is: ...

  • Page 136: Square Root

    SIGLENT Figure 67: IntegralwithOffset Square Root Square root (√) calculates the square root of the selected source. Where the transform is undefined for a particular input, holes (zero values) appear in the function output. Figure 68:Square Root 116 SDS2000X User Manual...

  • Page 137: To Make Cursors Measurements

    SIGLENT To Make Cursors Measurements Cursors are horizontal and vertical markers that indicate X-axis values and Y-axis values on a selected waveform source. You can use cursors to make custom voltage, time measurements on oscilloscope signals. X Cursors X cursors are vertical dashed lines that adjust horizontally and can be used to measure time (when the source is FFT waveform, X cursors measure frequency) X1 cursor is the left (default position) vertical dotted line;...

  • Page 138: To Make Cursor Measurements

    SIGLENT To Make Cursor Measurements 1. Press the Cursors button on the front panel to enter the CURSOR function menu. 2. Press the Mode softkey and set the option to On. 3. Press the Source softkey, and then use the Universal Knob to select the desired source.

  • Page 139: To Make Measurements

    SIGLENT To Make Measurements SDS2000X provides measurements of 36 waveform parameters and the statistics. It contains voltage, time and delay parameters. Voltage and time parameters are under Type option. The results of the last five selected measurements are displayed at the bottom of screen and above the menu. Delay parameters are under the All Measure submenu.

  • Page 140: Type Of Measurement

    SIGLENT Type of Measurement Voltage Measurements Voltage measurements include 15 kinds of voltage parameter measurements. Figure 70:Voltage Measurements 1. Vpp: The peak-to-peak value is the difference between Maximum and Minimum values. 2. Vmax: Maximum is the highest value in the waveform display.
  • Page 141 SIGLENT Figure 71: Overshoot 14. Preshoot: Preshoot is distortion that precedes a major edge transition expressed as a percentage of Amplitude. The X cursors show which edge is being measured (edge closest to the trigger reference point). Figure 72: Preshoot 15.

  • Page 142: Time Measurements

    SIGLENT Time Measurements Time measurements include 9 kinds of time parameter measurements. Figure 73: Time Measurements 1. Period: defined as the time between the middle threshold points of two consecutive, like-polarity edges. 2. Frequency: defined as the reciprocal of period.

  • Page 143: Delay Measurements

    SIGLENT Delay Measurements Delay measurements measure the time different between arbitrary two channels, including 9 kinds of delay measurements. 1. Phase: The phase difference between two channels. 2. FRR: The time between the first rising edge of source 1 and the first rising edge of source 2 of 50 voltage level.

  • Page 144: To Make Automatic Measurements

    SIGLENT To Make Automatic Measurements Perform the steps below and select voltage or time parameters to make automatic measurements. 1. Press the Measure button on the front panel to enter the MEASURE function menu. At the same, the frequency and period are enabled with the current trigger channel, the statistics also was enabled.
  • Page 145 SIGLENT Figure 75: Added the Measurement Note: If the parameter does not match the measured condition, it will display as ―****‖. SDS2000X User Manual 125...

  • Page 146: To Clear Measurement Parameters

    SIGLENT To Clear Measurement Parameters Press the Clear softkey to clear all the measurement parameters that are displaying on the screen. To Make All Measurement All measurement could measure all the voltage, time and delay parameters of the current measurement source and display the results on the screen.

  • Page 147: Display Setting

    SIGLENT Display Setting The display type, color, persistence, grid type, waveform intensity, grid brightness and transparence are all adjustable. The contents of this chapter:  To Set Display Type  To Set Color Display  To Set and Clear Persistence ...

  • Page 148: To Set Display Type

    SIGLENT To Set Display Type Press the Display button on the front panel, and then press the Type softkey to select Vectors or Dots display type.  Vectors: the sample points are connected by lines and displayed. Normally, this mode can provide the most vivid waveform to view the steep edge of the waveform (such as square waveform).

  • Page 149: To Set Color Display

    SIGLENT To Set Color Display Color temperature mode uses the change of the waveforms‘ color to reflect the change of the waveforms‘ appearing probability. This mode uses a change in color instead of the more common change in intensity. The greater the probability that the waveform appears, the warmer the color is;...

  • Page 150: To Clear The Display

    SIGLENT Figure 80: Persist Set to Infinite 3. When the Persist is On, to erase the results of previous acquisitions from the display, press the Clear Persist softkey. The oscilloscope will start to accumulate acquisitions again. 4. To return to the normal display mode, turn off persist and the previous acquisitions will be clear at once.

  • Page 151: To Select Grid Type

    SIGLENT To Select Grid Type To select grid type 1. Press the Display/Persist button on the front panel to enter the DISPLAY function menu. 2. Press the Next Page softkey to go to the second page of the Display function menu.
  • Page 152 SIGLENT Figure 81: Intensity Set to 100% Figure 82: Intensity Set to 10% Note: Waveform intensity adjustment affects analog channel waveforms only (not math waveforms, reference waveforms, digital waveforms, etc.). 132 SDS2000X User Manual...

  • Page 153: To Adjust Grid Brightness

    SIGLENT To Adjust Grid Brightness Do the following steps to adjust the grid brightness: 1. Press the Display button on the front panel to enter the DISPLAY function menu. 2. Press the Next Page softkey to go to the second page of the Display function menu.

  • Page 154: Save And Recall

    SIGLENT Save and Recall Oscilloscope setups, waveforms, pictures, and CSV files can be saved to internal oscilloscope memory or to a USB storage device. The saved setups, waveforms can be recalled later.SDS2000X provides an USB Host interface on the front panel to connect an USB device for external storage.

  • Page 155: Save Type

    SIGLENT Save Type SDS2000X supports setups, waveforms, pictures and CSV files storage. The default save type is setups. 1. Setups It‘s the default storage type of SDS2000X. SDS2000X saves the settings of the oscilloscope in internal or external memory in ―*.SET‖ format. At most 20 setting files (from No.1～No.20) can be stored in internal memory.

  • Page 156: Internal Save And Recall

    SIGLENT Internal Save and Recall Internal save and recall support Setups in Save/Recall. In the following part, the save and recall method and procedures are introduced.  Save the specified oscilloscope setting in internal memory. 1. Connect the signal to the oscilloscope and obtain stable display.

  • Page 157: External Save And Recall

    SIGLENT External save and recall Before using external storage and recall, make sure that the USB flash device is connected correctly. External storage supports all the types of files in save, but in recall, Picture and CSV are not supported.
  • Page 158 SIGLENT  Figure 84:Select Save Location 5. After the save position is selected, press the New softkey to turn on the interface as shown in the figure below. Refer to the descriptions in ―To Create a new file or fold” to create a new file name.
  • Page 159 SIGLENT  Load the specified type of file in the external USB storage device. 7. Press the Save/Recall button on the front panel to enter the SAVE/RECALL function menu. 8. Press the Type softkey to select Waveforms or Setup 9. Press the Recall softkey to enter the SAVE/RECALL file system.

  • Page 160: Disk Management

    SIGLENT Disk Management Disk management is used in save and recall operations after the oscilloscope is connected with a USB storage device. Before using external disk, make sure that the USB storage device is connected correctly. Execute the following operations through the disk management menu: ...

  • Page 161: To Create A New File Or Folder

    SIGLENT To Create a New File or Folder This operation is only valid in external storage. SDS2000X supports English input method. The file name or folder name can contain letters, numbers, underscores and spaces. Let‘s use an example to introduce how to create a file or folder.

  • Page 162: To Delete A File Or Folder

    SIGLENT To delete a file or folder This operation is only valid in external storage. 1. Press the Save/Recall button on the front to enter the SAVE/RECALL function menu. 2. Press the Type softkey, and then turn the Universal Knob to select one of the type (if select Setups, please set the Save To option to External).

  • Page 163: System Function Setting

    SIGLENT System Function Setting This function module supports the oscilloscope‘s system-related function, such as system status, language, sound and other advanced settings, such as performing a self-calibration, update and remote interface configure The contents of this chapter:  To View the System Status ...

  • Page 164: To View The System Status

    SIGLENT To View the System Status Do the following steps to view the system status: 1. Press the Utility button on the front to enter the UTILITY function menu. 2. Press the System Status softkey to view the system status of the oscilloscope. The system status includes the information below: ...

  • Page 165: To Do Self Calibration

    SIGLENT To Do Self Calibration The self-calibration program quickly enables the oscilloscope to utilize the best working state and to provide the most precise measurement values. You can perform self-calibration at any time, especially when there has been a change in the external ambient temperature of 5 ℃or more.

  • Page 166: To Enable Or Disable The Sound

    SIGLENT To Enable or Disable the Sound When the sound is enabled, the sound of the beeper will be heard when a function key or a menu softkey is pressed or when the prompt message pops up. Press the Utility button on the front panel to enter the UTILITY function menu; then press Sound softkey to select to turn on or off the sound.

  • Page 167: To Enable The Pass/Fail Test

    SIGLENT To Enable the Pass/Fail Test One way to verify a waveform's compliance to a particular set of parameters is to use pass/fail testing. A pass/fail defines a region of the oscilloscope's display in which the waveform must remain in order to comply with chosen parameters. Compliance to the mask is verified point-by-point across the display.

  • Page 168: To Set And Perform Pass/Fail Test

    SIGLENT To Set and Perform Pass/Fail Test Do the following steps to set and perform pass/fail test: 1. Press the Utility button on the front panel to enter the UTILITY function menu. 2. Press the Next Page softkey to go to the second page of the UTILITY function menu.

  • Page 169: To Save And Recall Test Mask

    SIGLENT To Save and Recall Test Mask Users can save the current test mask to the internal Flash memory or external USB flash device. The file format of the test mask file is ―*.RGU‖.  Save Test Mask to Internal Memory 1.
  • Page 170 SIGLENT  Save Test Mask to External Memory Do the following steps to save the test mask to external memory: 1. Press the Utility button on the front panel to enter the UTILITY function menu. 2. Press the Next Page softkey to go to the second page of the UTILITY function menu.

  • Page 171: I/O Set

    SIGLENT I/O Set SDS2000Xprovides abundant I/O interfaces, including: USB Device, LAN and Aux Output. To Set the USB Device Do the following steps to set the oscilloscope to communicate with PC via USB: 1. Install the USBTMC device driver on PC. Suggest you install NI Visa.

  • Page 172: To Set The Lan

    SIGLENT To Set the LAN Do the following steps to set the oscilloscope to communicate with PC via LAN: 1. Connect the oscilloscope to your local area network using the network cable. 2. Press the Utility button on the front panel to enter the UTILITY function menu.

  • Page 173: To Set Aux Output

    SIGLENT To Set Aux Output Users can set the type of the signal output from the [Trigger Out] connector at the rear panel. 1. Press the Utility button on the front panel to enter the UTILITY function menu. 2. Press the I/O Set softkey to enter the I/O SET function menu.

  • Page 174: To Enable Quick-Cal

    SIGLENT To Enable Quick-Cal Quick-Cal can automatically calibrate the SDS2000X when ambient temperature variations are affecting the measurement accuracy. If the temperature environment that the SDS2000X is working in is not stable, do the following steps: 1. Press the Utility button on the front panel to enter the UTILITY function menu.

  • Page 175: To Update Firmware And Configuration

    SIGLENT To Update Firmware and Configuration The firmware and configuration can be updated directly via the USB flash drive. Do the following steps to update the firmware: 1. Insert the USB flash drive containing the firmware and the configure files into the USB host interface on the front panel of the oscilloscope.

  • Page 176: Do Self Test

    SIGLENT Do Self Test Self tests include screen test, keyboard test, control knobs and LED test. Screen Test 1. Press the Utility button on the front panel to enter the UTILITY function menu. 2. Press the Next Page softkey to go to the second page of the UTILITY function menu.

  • Page 177: Keyboard Test

    SIGLENT Keyboard Test Keyboard test is used to test that the keys or the knobs are working correctly. Do the following steps to do keyboard test: 1. Press the Utility button on the front panel to enter the UTILITY function menu.

  • Page 178: Led Test

    SIGLENT LED Test LED test is used to test that if the button lights work well. 1. Press the Utility button on the front panel to enter the UTILITY function menu. 2. Press the Next Page softkey to go to the second page of the UTILITY function menu.

  • Page 179: To Specify Screen Saver Time

    SIGLENT To specify Screen Saver Time When the oscilloscope enters the idle state and holds for a certain period of time, the screen saver program will be enabled. Do the following steps to set the screen saver time: 1. Press the Utility button on the front panel to enter the UTILITY function menu.

  • Page 180: Option Management

    Option Management The SDS2000Xprovides multiple options to fulfill your measurement requirements. Please contact your SIGLENT sales representative or SIGLENT technical support to order the corresponding options. You can view the options currently installed on the oscilloscope or activate the newly purchased option license codes through this menu.
  • Page 181 SIGLENT  Turn the Universal Knob or press the ← softkey and the →softkey to select character;  Push down the Universal Knob or press the Enter softkey to confirm the characters and the oscilloscope will activate the corresponding option using the license key currently input.

  • Page 182: To Use The History Function

    SIGLENT To Use the History Function The history function can record the waveforms of the input channels before pressing the Run/Stop button. In the run state, the oscilloscope records input waveform continually; when the memory becomes full (reaches the maximal frame), the new frames will cover the old frames and keep the latest frames.
  • Page 183 SIGLENT 4. Press the softkey to replay the waveform from the current frame to 1. 5. Press the softkey to stop replay. 6. Press the softkey to replay the waveform from the current frame to the last frame. SDS2000X User Manual 163...

  • Page 184: Arbitrary Waveform Generator

    SIGLENT Arbitrary Waveform Generator SDS2000X supports a built-in Arbitrary waveform generator. SDS2000X built-in Arbitrary waveform generator provides sine, square, ramp, pulse, DC, noise, cardiac, Gauss pulse, exp rise, exp fall and Arbitrary waveforms. The contents of this chapter:  To Set Wave Type and Parameters ...

  • Page 185: To Set Wave Type And Parameters

    SIGLENT To Set Wave Type and Parameters 1. Press the WaveGen button on the front panel to open the built-in Arbitrary waveform generator function. The first press lights up the backlight of the button, opens the output and enters the WAVEFORM function menu. A second press of the WaveGen button will turn off the backlight and the output.
  • Page 186 SIGLENT Offset/Offset Fine/ Low-Level/ Low-Level-Fine/ Width/ Width Fine value. Use the Universal Knob to ± 3.0V adjust the Offset value. Use the Universal Knob to Noise adjust the Stdev/ Mean value. Use the Universal Knob to adjust the Frequency/ Frequency...

  • Page 187: To Output Arbitrary Waveform

    SIGLENT To Output Arbitrary Waveform 1. Press the Wave Gen button on the front panel to enable the AWG function and enter the WAVEFORM function menu. 2. Connect the SDS2000X with PC which has installed the EasyWave software using a USB cable.

  • Page 188: To Set Output Load

    SIGLENT To Set Output Load 11. Press the Wave Gen button on the front panel to enter the WAVEFORM function menu. 12. Press the Setting softkey to enter the SETTING function menu. 13. Press the OutputLoad softkey to select High-Z or 50Ω.

  • Page 189: Awg Self Cal

    SIGLENT AWG Self Cal If the ambient operating temperature changes more than 5°and the instrument runs more than more 30 minutes, run the AWG self cal routine to reduce the environmental thermal change effects 1. Press the Wave Gen button on the front panel to enter the WAVEFORM function menu.
  • Page 190 SIGLENT Default Setup Press the Default button on the front to set the SDS2000X to the recall the factory setup. The details show as below. Horizontal 1μs/div T/div Delay Zoom Format Vertical Channel on/off V/div 1 V/div Offset Coupling BW Limit...
  • Page 191 SIGLENT Persist Grid Intensity Brightness Transparence Cursor Mode Type Source -3.5μs 3.5μs Save/Recall Type Setups Save To Internal Setup NO.1 Utility IO Set USB Device USBTMC Aux Output Trig Out Sound Sound Pass/Fail Enable Test Source Operate Mes Display X Mask...
  • Page 192 SIGLENT Operate Source A Source B Invert V/div 1.00 V/div offset Source A Source B Invert V/div 1.00 V/div offset Source A Source B Invert V/div 1.00 V^2/div offset 0 V^2 Source A Source B Invert V/div 1.0/div offset Source...
  • Page 193 SIGLENT Vertical Scale 1.00 eve/div Vertical Offset √ Source Vertical Scale 1.00 V /div Vertical Offset Source Location REF A Display Decode Serial 1 Serial Display List Serial 2 Serial Display List Threshold 1.60V Threshold 1.60V 7 位 Address Threshold 1.60V...
  • Page 194 SIGLENT UART/RS232 Threshold 1.60V Threshold 1.60V Bound 9600 Parity Check None Stop Bit Idle Level Data Length CAN-H Threshold 1.60V CAN-L Threshold 1.60V Bound 100kb/S Decode Source CAN_H Source Threshold 1.60V Baud 2400 Wave Gen Function Wave Type Sine Output Load...
  • Page 195 SIGLENT Pulse Frequency 1 KHz Amplitude 4 Vpp Offset 0 Vdc 200μs Width Offset 0.0mVdc Noise Stdev Mean 0 mV Cardiac Frequency 1 KHz Amplitude 4 Vpp Offset 0 Vdc Gauss Pulse Frequency 1 KHz Amplitude 4 Vpp Offset 0 Vdc...
  • Page 196 SIGLENT. Restart the instrument after completing the steps listed above. If these steps do not solve the problem, please contact SIGLENT. After the signal is sampled, there is no corresponding waveform displaying Check to make certain the probe is correctly connected to the signal connecting cord.
  • Page 197 Make sure the USB disk being used is of the flash type, the instrument does not support USB of hard disk type. Make sure the system format of used USB disk is FAT32. Restart the instrument and then insert the USB to verify operation. If a problem persists, please contact SIGLENT. SDS2000X User Manual 177...

This manual is also suitable for:

Sds2000x seriesSds2204xSds2104xSds2074xSds2302xSds2202x ... Show all

Table of Contents
